The Bad Boy Mower parts diagram for the 2009 Pup and Lightning Deck Spindle is shown below. You may select the item you need by clicking on the Bad Boy Parts item number in the diagram or by finding it in the list below the diagram. BadBoyMowerParts.com has the parts diagrams for the 2009 Pup and Lightning models. Find all of your Bad Boy mowers 2009 Pup and Lightning parts here. We are your BadBoy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. The Bad Boy parts diagram below is for the 2009 Pup and Lightning Deck Spindle. If you are not able to find the Bad Boy parts for your 2009 Pup and Lightning please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.
Position Number | SKU | Product Title | Price | ||
---|---|---|---|---|---|
1 | 037-8005-00 |
037-8005-00 - Spindle Housing - Obsolete - Use 037-4000-00 (obsolete) use part #037-4000-00 |
$312.34
|
||
2 | 037-8003-00 | 037-8003-00 - Tube Spacer-Double Bearing Spi ndle-2009 Lightning, Pup, AOS |
$11.34
|
||
3 | 037-9050-00 | 037-9050-00 - Collar Spacer - Top of Spindle (See Models Used On For Details) |
$7.28
|
||
4 | 037-6019-00 | 037-6019-00 - Spindle Shaft, Grooved - Diamond |
$99.37
|
||
5 | 037-8002-00 | 037-8002-00 - Dust Cover (Used on 037-4000-00 & 037-6015-50) |
$11.76
|
||
6 | 037-8001-00 | 037-8001-00 - Double Bearing for Spindle (See Models Used On For Details) |
$46.78
|
