2009 Pup and Lightning - Floor Panel

2009 Pup and Lightning - Floor Panel

The Bad Boy Mower parts diagram for the 2009 Pup and Lightning Floor Panel is shown below. You may select the item you need by clicking on the Bad Boy Parts item number in the diagram or by finding it in the list below the diagram. BadBoyMowerParts.com has the parts diagrams for the 2009 Pup and Lightning models. Find all of your Bad Boy mowers 2009 Pup and Lightning parts here. We are your BadBoy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. The Bad Boy parts diagram below is for the 2009 Pup and Lightning Floor Panel. If you are not able to find the Bad Boy parts for your 2009 Pup and Lightning please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.

Bad Boy Mower Parts Lookup

2009 Pup and Lightning - Floor Panel
  Position Number SKU Product Title Price
1A 088-3500-00 088-3500-00 - Mount Assist Handle
$58.84
1 071-3000-00 071-3000-00 - Milsco Suspension Seat-AOS/Lig OBSOLETE use 071-4050-17 (obsolete)
use part #071-4050-17
$813.99
2 071-2010-00 071-2010-00 - Wise Seat - ZT - WM1976 OBSOLETE use 071-2040-00 (obsolete)
use part #071-2040-17
$599.99
3 014-2006-00 014-2006-00 - Cooler Cover (See Models Used On For Details)
$126.20
4 081-2006-00 081-2006-00 - Floor Mat - Pup Models
$66.76
5 064-2005-00 064-2005-00 - Floorboard Cable USE 064-2006-00!!!!!!!! (obsolete)
use part #064-2006-00
$15.55
6 026-2006-00 026-2006-00 - Seat Plate (See Models Used On For Details)
$99.32
7 079-5340-00 079-5340-00 - 2007-2010 Pup/Lightning Floor Panel
$106.99
9 014-9000-00 014-9000-00 - Frame Plug 2x2
$2.99
10 058-2000-00 058-2000-00 - 2006-Present Floor Panel Stop
$7.34
11 040-6060-00 040-6060-00 - Seat Latch Pin
$2.99
12 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
13 030-7040-00 030-7040-00 - 1/4 x 1 Hex Head Tek Screw
$2.99
14 018-8064-00 018-8064-00 - 1/4-20 X 5/8 BS C/S 18-8 SS
$2.99
15 030-3050-00 030-3050-00 - 10 X 1/2 Pan Phil a T/S Zinc
$2.99
16 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
17 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
18 013-8039-00 013-8039-00 - 1/4-20 Hex Nuts Zinc
$2.99
19 019-4008-00 019-4008-00 - 1/4 Lockwasher Zinc
$2.99
20 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
