2009 Pup and Lightning - Front Wheel w/ Suspension

2009 Pup and Lightning - Front Wheel w/ Suspension

The 2009 Pup and Lightning Front Wheel w/ Suspension plays a crucial role in providing a smoother ride and better handling for your Bad Boy Mower. At BadBoyMowerParts.com, we offer high-quality Bad Boy Mower Parts, including front wheels with suspension, to improve the performance of your mower. Whether you’re replacing a worn-out wheel or upgrading your mower’s ride quality, we have the right parts for the job. Our Bad Boy Mower Part Diagrams make it easy to find the correct front wheel assembly and ensure a perfect fit. With a vast inventory of Bad Boy Lawn Mower Parts, you can trust us to have what you need for repairs and maintenance. Shopping for Bad Boy Parts Online is fast and convenient, and with Free Shipping On Orders Over $100, you can save money while keeping your mower in peak condition. Order today and enjoy smoother mowing with a properly functioning suspension system.

Bad Boy Mower Parts Lookup

2009 Pup and Lightning - Front Wheel w/ Suspension
  Position Number SKU Product Title Price
1 022-3060-00 022-3060-00 - 13 x 6.50 - 6 LARGE BORE, Orange Front Assembly
$122.99
2 032-9002-00 032-9002-00 - Isolator - Red Dot
$70.97
3A 010-7003-98 010-7003-98 - Front Caster Bearing, Race, and seal kit (See Models Used On For Details)
$30.99
3 010-7001-00 010-7001-00 - Tapered Roller Bearing - Caster- Race not included (See Models Used On For Details)
$6.26
4 014-7005-00 014-7005-00 - Dust Cover - Yellow Zinc
$9.34
5 022-7010-00 022-7010-00 - 1 3/4" Bearing - Large Bore Front Wheel
$20.32
6 020-7022-00 020-7022-00 - 1/8 X 2-1/4 Cotter Pins Zinc
$2.99
7 018-3001-00 018-3001-00 - 5/8 x 5/8 Shoulder Bolt
$15.61
8 018-3003-00 018-3003-00 - 1/2 x 1 1/4 Carriage Bolt
$2.99
9 013-5300-00 013-5300-00 - 1/2-13 Hex Fange Nuts Zinc w/ Serrations
$2.99
10 018-5006-00 018-5006-00 - 1/2-13 X 1-1/2 Hex Bolt, Coarse Thread Bolt (For Use On Spindles Please Refer To Item Details)
$2.99
11 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
12 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
13 013-7004-00 013-7004-00 - 1-14 Hex Castle Nut Plain (Slotted Nut)
$8.35
14 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
15 025-5202-00 025-5202-00 - Front Wheel Spanner-All Models Except MZ
$10.44
16 018-3002-00 018-3002-00 - 1/2 x 10 Bolt
$8.02
17 032-5052-00 032-5052-00 - Bronze Bushing
$4.81
18 011-7002-00 011-7002-00 - Race (44610) Front Caster (See Models Used On For Details)
$4.39
