2009 Pup and Lightning - Hydraulic Pump

2009 Pup and Lightning - Hydraulic Pump

If you have a Lightning Unit be aware that the pumps used were different then what was used on the Pup Models. This is also the case for the Pump Fan Covers Pup Pumps - Item # 7,8 Lightning Pumps - Items # 32, 32A The Bad Boy Mower parts diagram for the 2009 Pup and Lightning Hydraulic Pump is shown below. You may select the item you need by clicking on the Bad Boy Parts item number in the diagram or by finding it in the list below the diagram. BadBoyMowerParts.com has the parts diagrams for the 2009 Pup and Lightning models. Find all of your Bad Boy mowers 2009 Pup and Lightning parts here. We are your BadBoy mower parts source.

Bad Boy Mower Parts Lookup

2009 Pup and Lightning - Hydraulic Pump
  Position Number SKU Product Title Price
1A 063-2000-03 063-2000-03 - Briggs Vanguard 23hp Service Kit
$114.99
1B 063-2000-09 063-2000-09 - Kohler Command (Non-EFI Models)
$121.25
1C 063-2000-02 063-2000-02 - Kawasaki FX850 Engine Service Kit
$124.74
1D 063-2000-10 063-2000-10 - Briggs Vanguard 810/993/999cc (Non-EFI Models Only) Engine Service Kit
$127.15
1E 015-2708-00 015-2708-00 - Exhaust Gasket - 36hp Vanguard
$16.04
1F 015-2709-00 015-2709-00 - Exhaust Gasket (See Models Used On For Detail)
$8.01
1G 015-2751-00 015-2751-00 - Exhaust Gasket for 27,30 hp Kohler Engines
$6.56
1H 063-6000-00 063-6000-00 - Universal Inline Fuel Filter
$14.19
1 041-5048-00 041-5048-00 - Pump Belt (See Models Used On For Details)
$60.98
3 015-0033-00 015-0033-00 - Exhaust - 23hp Vanguard Engine
$220.06
4 033-5003-00 033-5003-00 - 5" Cast Pump Pulley - 15mm
$56.77
5 039-5944-00 039-5944-00 - Pump Idler Bracket
$42.58
6 026-5321-00 026-5321-00 - Pup Rear Plate
$212.99
7 050-5303-00 050-5303-00 - Right Pump, 10cc - Pup Models
$855.99
8 050-5302-00 050-5302-00 - Left Pump, 10cc - Pup Models
$855.99
9 031-5333-00 031-5333-00 - XP/Pup/Lightning Pump Arm
$22.75
10 015-9999-00 015-9999-00 - Hydro Fan - Light/Pup/OutlawXP
$26.74
11A 014-5600-00 014-5600-00 - Fan Guard 6.5" - Fits Wheel Motor Pumps
$39.81
11 014-5500-00 014-5500-00 - Fan Guard 7"
$39.03
12 051-5341-00 051-5341-00 - 17" Hydraulic Hose-Pup/Lightni ng (obsolete)
use part #051-2000-00
$49.63
13A 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
13 057-5906-00 057-5906-00 - PTO Engager Holder-Clutch Pup/Lightning/Outlaws
$20.67
15 018-2004-00 018-2004-00 - All Thread-Pump Idler Tensione
$12.94
16 024-5343-00 024-5343-00 - Hydraulic Pump Fitting 6400-10 -8
$7.95
17 018-5005-00 018-5005-00 - 1/4-20 X 1-1/2 GR 5 Hex Bolt
$2.99
18 013-8073-00 013-8073-00 - 1/4-20 Nylon Insert Locknut Zi nc Orange Nylon
$2.99
19 024-5206-00 024-5206-00 - 90 Degree Fitting, 3/8 x 9/16, 4601-6-6
$12.42
20 042-5301-00 042-5301-00 - 5MM X 1 Square Key Stock
$2.99
21 033-5034-00 033-5034-00 - 4 3/4 Motor Pulley - DB74-601 Comes with set screw only. Key way IS NOT included. (See Models Used On For Details)
$35.48
22 018-6049-00 018-6049-00 - 3/8-16 X 1 GR 5 Hex Bolts Zinc
$2.99
23 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
24 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
25 018-5311-00 018-5311-00 - 5/8-11 X 4 GR 5 Hex Bolts Zinc
$4.06
26 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
27 019-5037-00 019-5037-00 - 3/8 Lockwasher Zinc
$2.99
28 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
29 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
30 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
31 013-8047-00 013-8047-00 - 5/16-18 Nylon Insert Locknut Z inc Orange Nylon
$2.99
32A 050-3000-00 050-3000-00 - Left Pump 12cc - Lightning PK-3KCC-GY1C-XXXX
$909.49
32 050-3050-00 050-3050-00 - Right Pump 12cc - Lightning PK-3HCC-GY1C-XXXX
$888.09
33 015-0006-00 015-0006-00 - Exhaust-26hp Kawasaki Engine Liquid Cooled Lightning
$227.15
34 015-0034-00 015-0034-00 - Exhaust-32/36hp Vanguard Engine
$198.76
35 015-0035-00 015-0035-00 - Exhaust for 31hp Kawasaki
$218.63
36 015-0039-00 015-0039-00 - Exhaust 30 Kohler
$641.99
