2013 MZ - Drive Arm

2013 MZ - Drive Arm

The 2013 MZ Drive Arm is crucial for the transmission system of your mower, providing the power necessary for movement. If you need to replace or repair your drive arm, BadBoyMowerParts.com has a full range of high-quality parts. Our Bad Boy Mower Part diagrams make it easy to find the exact drive arm components for your 2013 MZ, ensuring proper fit and function. We carry a wide selection of Bad Boy Mower Parts, from belts to gears, to maintain the performance of your mower. Our Bad Boy Lawn Mower Parts are designed to be durable and long-lasting, offering great value. Plus, with Free Shipping On Orders Over $100, you can save on shipping costs while getting the parts you need. Browse Bad Boy Parts Online for a seamless shopping experience and quick delivery.

Bad Boy Mower Parts Lookup

2013 MZ - Drive Arm
  Position Number SKU Product Title Price
1A 031-9060-18 031-9060-18 - Adjustable Steering Arm Kit
$178.99
1 069-4010-00 069-4010-00 - Black Steering Grip
$8.12
2 039-1125-00 039-1125-00 - MZ Switch Bracket
$5.22
3 019-8027-00 019-8027-00 -.515 ID Plastic Shoulder Washer
$2.99
4 034-8025-00 034-8025-00 - Drive Lever Housing Spring
$4.07
5 032-8024-00 032-8024-00 -.502x.618x.500 Spacer Nylon Drive Arm Block
$2.99
6 013-8043-00 013-8043-00 - 5/16-18 Hex Nut
$2.99
7 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
8 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
9 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
10 018-8063-00 018-8063-00 - 5/16-18 X 3/4 Hex Bolt
$2.99
11 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
12 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
13 019-7000-00 019-7000-00 -.505x1x.125 Oil Impregnated Washer for 2012 Drive Arm Blocks
$4.83
14 032-5055-00 032-5055-00 - Drive Arm Bushing (See Models Used On For Detail)
$6.41
15 018-1080-00 018-1080-00 - 12-24 x 1/2 HWH Bolt - Safety Switch
$2.99
16 018-2020-00 018-2020-00 - 5/16-18 x 1/2 HWH Bolt - Steering Arms
$2.99
17 031-9025-00 031-9025-00 - Right Steering Arm Gold Elbow (See Models Used On For Details)
$85.17
18 031-9020-00 031-9020-00 - Left Steering Arm Elbow
$85.17
19 013-0085-00 013-0085-00 - 1/2-13 Hex Flange Nut Zinc
$2.99
