2015 CZT Elite - 54" Deck Assembly

2015 CZT Elite - 54" Deck Assembly

The 2015 CZT Elite 54" Deck Assembly is designed to handle demanding mowing conditions, but regular maintenance is essential for peak performance. If you need spindles, belts, blades, or pulleys, turn to BadBoyMowerParts.com for high-quality Bad Boy Mower Parts. Our detailed Bad Boy Mower Part Diagrams make it easy to locate the correct components for your deck assembly. Keeping Bad Boy Lawn Mower Parts in top shape ensures your mower delivers the precision cutting performance you expect. Ordering Bad Boy Parts Online allows you to conveniently find everything you need in one place. Plus, enjoy Free Shipping On Orders Over $100 on your order, making it more affordable to maintain your CZT Elite. Keep your deck assembly operating at its best by shopping at BadBoyMowerParts.com today.

Bad Boy Mower Parts Lookup

2015 CZT Elite - 54" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6000-00 088-6000-00 - Advanced Chute System for Select 2007-2025 Models with 60", 61", and 72" Decks & 2014-Newer ZT/CZT/Maverick 54" Decks (Will Not Work on 54" Outlaw)
$249.00
1 060-6054-00 060-6054-00 - 2013-2015 CZT, 2014-2016 ZT, 2016-2017 Maverick 54" Deck Shell
$1196.14
2 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
3 018-6059-00 018-6059-00 - 5/8-11 X 2-1/2 Hex Bolts
$2.99
4 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
5 031-6020-00 031-6020-00 - Deck Hanger-Black
$132.68
6 032-5057-00 032-5057-00 - Flange for Lower Deck Arm SF-1622-5
$9.89
7 032-5056-00 032-5056-00 - Flange Bushing-Deck Arms EF081108 - Frame Mounted
$5.82
8 018-1090-00 018-1090-00 - 1/2-13x5 1/2 Hex Bolt
$3.29
9 018-6037-00 018-6037-00 - 1/2-13 X 2-1/4 Hex Bolt
$2.99
10 047-7000-00 047-7000-00 - 2015 CZT Deck Hanger Chain
$8.74
11 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
12 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
13 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
14 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
15 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
16 018-1050-00 018-1050-00 - 1/2 x 2 Carriage Bolt
$2.99
17 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
18 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
19 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
20 041-1560-00 041-1560-00 - Deck Belt (See Models Used On For Details)
$88.80
21 014-5000-00 014-5000-00 - Pulley Cover (See Models Used On For Details)
$15.60
22 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
23 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
24 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
25 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
26 033-7201-00 033-7201-00 - 5 3/4 Idler Pulley
$35.48
27.1 210-6005-98 210-6005-98 - Chute Assembly (See Models Used On For Detail)
$149.99
27 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
28 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
29 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
30 206-6017-00 206-6017-00 - Discharge Chute Hanger-Deck (See Models Used On For Detail)
$39.03
31 018-2007-00 018-2007-00 - 5/16-18 X 1 Hex Bolt Zinc
$2.99
32 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
33 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
34 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
35 039-4864-00 039-4864-00 - Discharge Chute Upper Hanger Plate (See Models Used On For Detail)
$42.52
36 039-4863-00 039-4863-00 - Discharge Lower Bracket Rubber Chute (See Models Used On For Detail)
$32.65
37 013-0004-00 013-0004-00 - Acorn Nut-Pulley Cover
$3.29
38 019-6050-00 019-6050-00 -.360 ID Black Plastic Washer
$2.99
39 048-6060-00 048-6060-00 - CZT/ZT/Maverick/Stand-On Toplink/Turnbuckle (See Models Used On For Details)
$56.77
40 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
41 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
42 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
43 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
44 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
45 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
46 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
47 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
48 019-4807-00 019-4807-00 - 5/8" Lockwasher Zinc
$2.99
49 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
50.1 038-0003-00 038-0003-00 - 54" & 2024 Raider 36" Deck Gator Mulching Blade
$22.99
50 038-0001-00 038-0001-00 - 54" & 2024 Raider 36" High Lift Fusion Blade
$22.99
51 033-6003-00 033-6003-00 - 5" Spindle Deck Pulley - DB-80 (without set screw) (See Models Used On For Details)
$42.58
52 037-6015-50 037-6015-50 - Spindle Assembly (See Models Used On For Detail)
$199.99
53 018-0010-00 018-0010-00 - Deck Wheel Bolt
$6.48
54A 022-1000-98 022-1000-98 - Deck Wheel Assembly
$25.99
54 022-1000-00 022-1000-00 - Deck Wheel Only
$17.11
55 019-0007-00 019-0007-00 -.517 Square Hole Round Washer
$2.99
56 033-5000-00 033-5000-00 - 5 3/4" Double Bearing Flat Idler Pulley (See Description For Details)
$56.77
57 026-0025-00 026-0025-00 - Deck Spindle Support Plate
$14.19
58 039-6945-01 039-6945-01 - Deck Idler Assembly
$40.65
