2015 CZT Elite - Transaxle

2015 CZT Elite - Transaxle

The 2015 CZT Elite Transaxle is an essential part of the drivetrain system that transfers power from the engine to the wheels, ensuring smooth movement and effective cutting. If you experience issues with your transaxle, it’s important to replace it with high-quality Bad Boy Mower Parts to maintain optimal performance. BadBoyMowerParts.com has a full selection of transaxles and related components, supported by our helpful Bad Boy Mower Part Diagrams to guide you through your repair process. Our Bad Boy Lawn Mower Parts are designed for durability and reliability, so you can trust they’ll withstand tough mowing conditions. By ordering Bad Boy Parts Online, you can easily find the exact parts you need for your 2015 CZT Elite. Plus, enjoy the benefit of Free Shipping On Orders Over $100, which makes maintaining your mower even more affordable. Don’t let transaxle issues slow you down—order from BadBoyMowerParts.com today to keep your mower running like new.

Bad Boy Mower Parts Lookup

2015 CZT Elite - Transaxle
  Position Number SKU Product Title Price
1A 085-4051-00 085-4051-00 - Hydro Service Package for 2020 and Older Models with Expansion Tanks - ZT2800, ZT3100, ZT3200, and all ZT3400
$104.74
1 050-6000-00 050-6000-00 - ZT3400 Transaxle - Left (obsolete)
use part #050-6000-02
$819.99
2 050-6001-00 050-6001-00 - ZT3400 Transaxle - Right (obsolete)
use part #050-6001-02
$819.99
3 028-4801-00 028-4801-00 - Crossover Bar (See Models Used On For Detail)
$28.10
4 018-3000-00 018-3000-00 - 3/8-16 X 2 Hex Bolts Zinc
$2.99
5 050-2072-00 050-2072-00 - Fan/Pulley Kit
$63.96
6 018-4701-00 018-4701-00 - 5/16-18 X 3 Hex Bolt Zinc
$2.99
7 019-8044-00 019-8044-00 - 5/16 USS Flat Washer Zinc
$2.99
8 025-5340-00 025-5340-00 - .365 ID X .752 OD X 3.313 Length Spacer Zinc
$8.74
9 018-5355-00 018-5355-00 - 5/16-18 X 6 Hex Bolt Zinc
$2.99
10 039-0053-00 039-0053-00 - Crossover Brake Bracket
$14.19
11 064-3000-00 064-3000-00 - 44" Brake Cable
$31.22
12 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
13 013-8073-00 013-8073-00 - 1/4-20 Nylon Insert Locknut Zinc
$2.99
14 063-1050-00 063-1050-00 - ZT Hydraulic Filter
$22.71
15 022-5460-00 022-5460-00 - 23 x 10.50 -12 Assembly w/Negative Offset Wheel 54"CZT (One Tire & Rim Assy)
$248.99
16 022-7061-00 022-7061-00 - 12x8.5 Orange Wheel - Solid (One Rim Only)
$182.99
17 022-5351-00 022-5351-00 - 23 x 10.50 - 12 Tire (One Tire Only)
$182.99
18 013-3000-00 013-3000-00 - Acorn Lug Nut
$3.29
19 041-6400-00 041-6400-00 - Pump Belt (See Models Used On For Details)
$58.84
20 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zinc
$2.99
21 018-4007-00 018-4007-00 - 1/4-20 X 1 Hex Bolts Zinc
$2.99
22 018-5344-00 018-5344-00 - 5/16 x 2 1/2 Bolt
$2.99
23 034-9000-00 034-9000-00 - SPRING (See Models Used On For Details)
$15.55
24 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
25 034-9080-00 034-9080-00 - Gold Transaxle Spring
$14.89
26 092-8000-00 092-8000-00 - Transaxle Brake Lever
$21.28
27 050-2012-00 050-2012-00 - Transaxle Wheel Studs/ Drum Brake Studs
$5.61
28 050-2077-00 050-2077-00 - 5 Bolt Hub Kit (See Models Used On For Details)
$102.71
29 024-1200-00 024-1200-00 - Fitting, 3/8 x 3/8 45 Degree, 4603-6-6 (See Models Used On For Details)
$19.93
