2015 Compact Diesel - Frame Assembly

2015 Compact Diesel - Frame Assembly

The 2015 Compact Diesel Frame Assembly provides structural integrity and support to your mower, ensuring durability and stability in tough mowing conditions. If your frame assembly has sustained damage or needs reinforcement, BadBoyMowerParts.com is your trusted source for genuine Bad Boy Mower Parts. Our Bad Boy Mower Part Diagrams make finding replacement frame components simple and efficient. Maintaining high-quality Bad Boy Lawn Mower Parts like the frame assembly is essential to prevent further mechanical issues. Whether you need a complete frame replacement or just specific reinforcements, you’ll find what you need in our Bad Boy Parts Online catalog. Made from heavy-duty materials, these parts ensure long-lasting durability. Plus, enjoy the benefit of Free Shipping On Orders Over $100, making your repair process cost-effective. Visit BadBoyMowerParts.com for top-quality frame assemblies that restore your mower’s strength and stability.

Bad Boy Mower Parts Lookup

2015 Compact Diesel - Frame Assembly
  Position Number SKU Product Title Price
1 070-5580-00 070-5580-00 - 2015-2018 Compact Outlaw Diesel
$1399.99
3 081-2008-00 081-2008-00 - Foot Assist Floor Mat (See Models Used On For Details)
$66.76
4 040-6080-00 040-6080-00 - Ratchet Fastener - Floorboard
$2.99
5 018-8064-00 018-8064-00 - 1/4-20 X 5/8 BS C/S 18-8 SS
$2.99
6 064-2006-00 064-2006-00 - Floorboard Cable
$15.55
7 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
8 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
9 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
10 030-3050-00 030-3050-00 - 10 X 1/2 Pan Phil a T/S Zinc
$2.99
11 029-4010-00 029-4010-00 - Button Bumper
$2.99
12 028-6030-00 028-6030-00 - Actuator Bar (Front) (See Models Used On For Detail)
$189.99
13 028-6040-00 028-6040-00 - Actuator Bar (Rear) (See Models Used On For Detail)
$175.99
14 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
15 032-3000-00 032-3000-00 - Actuator Bar Bushing
$2.99
16 018-0008-00 018-0008-00 - 1/2 x 1 1/2 Carriage Bolt
$2.99
17 017-9000-00 017-9000-00 - Two Piece Pillow Block-Male
$10.99
19 017-9025-00 017-9025-00 - Two Piece Pillow Block-Plate
$32.09
20 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
21 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
22 018-0009-00 018-0009-00 - 3/8 x 1 3/4 Carriage Bolt
$2.99
23 040-4000-00 040-4000-00 - MZ, Diesel & Outlaw Deck Height Lever Pin
$17.16
24 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
25 031-0100-00 031-0100-00 - Deck Lever Lock (See Models Used On For Details)
$18.45
26 026-2100-00 026-2100-00 - Diesel & Outlaw Height Indicator Plate (Outer)
$12.83
27 019-2003-00 019-2003-00 - .390 x .750 x .062 Nylon Washer
$2.99
28 026-0013-00 026-0013-00 - 2010-2018 Outlaw & 2012-2018 Compact Diesel Deck Lift Pedal
$21.28
29 040-5000-00 040-5000-00 - Pull Pin - Foot Assist w/Ring
$21.39
30 030-0010-00 030-0010-00 - 5/16-18 x 1 Thumb Screw Zinc (No Shoulder)
$3.29
31 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
32 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
33 087-6100-00 087-6100-00 - 250lb Gas Spring - 61" Outlaw Deck Damper
$78.01
34 018-2050-00 018-2050-00 - 10mm Damper Ball Stud-Steering Damper, Outlaw Deck Damper
$2.99
35 028-6055-00 028-6055-00 - Linkage Bar Suspension Frame (See Models Used On For Detail)
$28.39
36 035-7033-00 035-7033-00 - Actuator
$408.75
37 018-0022-00 018-0022-00 - 1/2-13 x 2 Grade 8 Hex Bolt
$2.99
38 019-5702-00 019-5702-00 - 1/2 SAE Flat Washer GR 8
$2.99
39 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknut Zinc Orange Nylon
$2.99
40 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
41 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
42 019-8054-00 019-8054-00 -.505 ID X 1 OD X.128 THK Flat Washer Nylon
$2.99
43 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
44 013-9001-00 013-9001-00 - 1/4-20 Hex Flange Nuts Zinc w/Serrations
$2.99
45 089-3050-00 089-3050-00 - 2 x 3 ROPS 2014-2015 - Diesel
$829.99
46 018-7050-00 018-7050-00 - 1/2-13 X 4-1/2 Hex Bolts
$2.99
47 013-0005-00 013-0005-00 - 1/2" Center Lock Nut
$2.99
48 015-4000-00 015-4000-00 - Fuel Pump for 1100cc Diesel
$331.72
49 029-7037-00 029-7037-00 - 14" Bumper
$42.79
50 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
51 030-7039-00 030-7039-00 - 14 X 1-1/2 HWA A T/S Zinc
$2.99
52 030-7040-00 030-7040-00 - 1/4 x 1 Hex Head Tek Screw
$2.99
