2015 Diesels - 72" Deck Assembly

2015 Diesels - 72" Deck Assembly

The 2015 Diesels 72" Deck Assembly is an essential component for ensuring a smooth and even cut. At BadBoyMowerParts.com, we offer a wide selection of Bad Boy Mower Parts specifically designed for your mower. From replacement blades to spindles and pulleys, our extensive range of Bad Boy Lawn Mower Parts has everything you need for the 2015 Diesels 72" Deck Assembly. Using Bad Boy Mower Part diagrams, it’s easier than ever to identify and replace the parts required to keep your deck assembly in prime condition. By shopping Bad Boy Parts Online, you can conveniently place an order for high-quality parts from the comfort of your home. We also offer Free Shipping On Orders Over $100, ensuring you save money while getting your mower back into top shape. Whether you’re performing routine maintenance or making repairs, BadBoyMowerParts.com provides the best parts and customer service for your 2015 Diesels 72" Deck Assembly needs.

Bad Boy Mower Parts Lookup

2015 Diesels - 72" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6000-00 088-6000-00 - Advanced Chute System for Select 2007-2025 Models with 60", 61", and 72" Decks & 2014-Newer ZT/CZT/Maverick 54" Decks (Will Not Work on 54" Outlaw)
$249.00
1 060-7201-00 060-7201-00 - 72" Deck Shell W/O Front Gates (See Models Used On For Detail)
$1594.22
2 037-4000-50 037-4000-50 - Outlaw/XP/Diesel Spindle (obsolete)
use part #037-4000-00
$291.91
3 019-4807-00 019-4807-00 - 5/8" Lockwasher Zinc
$2.99
4 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
5 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
6 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
7.1 038-5400-00 038-5400-00 - 72" Gator Mulching Blade
$24.99
7 038-7230-00 038-7230-00 - 72" High Lift Fusion Blade
$24.99
8 033-7203-00 033-7203-00 - 7" Spindle Deck Pulley 72" Decks
$35.48
9 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
10 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
11 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
12 206-6017-00 206-6017-00 - Discharge Chute Hanger-Deck (See Models Used On For Detail)
$39.03
13 039-4864-00 039-4864-00 - Discharge Chute Upper Hanger Plate (See Models Used On For Detail)
$42.52
14.1 210-6005-98 210-6005-98 - Chute Assembly (See Models Used On For Detail)
$149.99
14 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
15 039-4863-00 039-4863-00 - Discharge Lower Bracket Rubber Chute (See Models Used On For Detail)
$32.65
16 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
17 018-2007-00 018-2007-00 - 5/16-18 X 1 Hex Bolt Zinc
$2.99
18 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
19 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
20 047-5000-00 047-5000-00 - 5 Link Adjustable Deck Hanger (See Models Used On For Details)
$28.39
21 060-7211-00 060-7211-00 - 72" Deck Adjustable Front (Right Gate) (See Models Used On For Detail)
$103.99
22 060-7210-00 060-7210-00 - 72" Deck Adjustable Front (Left Gate) (See Models Used On For Detail)
$103.99
23 018-3003-00 018-3003-00 - 1/2 x 1 1/4 Carriage Bolt
$2.99
24 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
25A 022-1000-98 022-1000-98 - Deck Wheel Assembly
$25.99
25 022-1000-00 022-1000-00 - Deck Wheel Only
$17.11
26 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
27 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
28 033-5000-00 033-5000-00 - 5 3/4" Double Bearing Flat Idler Pulley (See Description For Details)
$56.77
29 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
30 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
31 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
32 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
33 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
34 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
35 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
36 018-1050-00 018-1050-00 - 1/2 x 2 Carriage Bolt
$2.99
37 019-0007-00 019-0007-00 -.517 Square Hole Round Washer
$2.99
38 031-6010-00 031-6010-00 - Deck Hanger (One Piece) (obsolete)
use part #031-6020-00
$132.68
39 018-1090-00 018-1090-00 - 1/2-13x5 1/2 Hex Bolt
$3.29
40 018-6037-00 018-6037-00 - 1/2-13 X 2-1/4 Hex Bolt
$2.99
41 014-7204-00 014-7204-00 - 72" Spindle Cover (See Models Used On For Details)
$42.58
42 041-2525-00 041-2525-00 - B252.50 Deck Belt for 72" AOS Diesel (35hp/1500cc)
$131.30
43 032-5056-00 032-5056-00 - Flange Bushing-Deck Arms EF081108 - Frame Mounted
$5.82
44 032-5057-00 032-5057-00 - Flange for Lower Deck Arm SF-1622-5
$9.89
45 039-6945-98 039-6945-98 - Deck Idler Assy
$78.08
46 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
47 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
48 033-7201-00 033-7201-00 - 5 3/4 Idler Pulley
$35.48
49 019-6050-00 019-6050-00 -.360 ID Black Plastic Washer
$2.99
50 058-6000-00 058-6000-00 - Black, Round Stick-On Rubber
$2.99
51 013-0004-00 013-0004-00 - Acorn Nut-Pulley Cover
$3.29
52 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
53 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
54 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
