2015 Diesels - Seat Frame

2015 Diesels - Seat Frame

The 2015 Diesels Seat Frame is an important component that provides support and comfort for the operator during mowing. At BadBoyMowerParts.com, we understand the importance of having a sturdy and reliable seat frame, which is why we offer only the best Bad Boy Mower Parts. Whether you need a replacement seat frame due to wear or damage, or you're upgrading for extra comfort, we have a variety of Bad Boy Lawn Mower Parts to fit your 2015 Diesels model. Our Bad Boy Mower Part diagrams make it easy to find the right seat frame and other related components. You can easily shop Bad Boy Parts Online and have your parts delivered to your door. Plus, with Free Shipping On Orders Over $100, you save money while getting the highest-quality parts. Keep your 2015 Diesels mower in top shape with a new seat frame and other parts from BadBoyMowerParts.com.

Bad Boy Mower Parts Lookup

2015 Diesels - Seat Frame
  Position Number SKU Product Title Price
1A 085-4052-00 085-4052-00 - Pump/Wheel Motor Hydro Service Pack
$133.30
1 069-8054-00 069-8054-00 - Brake Handle Kit
$119.41
2 062-8013-00 062-8013-00 - Filter Head-Hydraulic Filter
$24.92
3 063-8014-00 063-8014-00 - Hydraulic Filter For Units with Pumps and Wheel Motors
$31.17
4 024-5050-00 024-5050-00 - Filter Head Fitting, 1/2 x 1/2 , 208-108
$8.01
5 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
6 018-8059-00 018-8059-00 - 5/16-18x1-3/4 Hex Bolt
$2.99
7 080-7000-00 080-7000-00 - 2007 Diesel Seat Frame
$399.99
9 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
10 019-4008-00 019-4008-00 - 1/4 Lockwasher Zinc
$2.99
11 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
12 025-6041-00 025-6041-00 - Switch Block Plastic
$2.99
13 064-8055-00 064-8055-00 - Short Brake Cable
$51.47
14 018-8056-00 018-8056-00 - 10-24x1/2 Buttonhead SCS 18-8
$2.99
16 066-8050-00 066-8050-00 - Hydraulic Tank Cap w/Dipstick (See Models Used On For Details)
$31.22
17 064-8056-00 064-8056-00 - Long Brake Cable
$53.49
18 051-8063-00 051-8063-00 - 3/8 Clear Hose PRICED PER FOOT
$2.99
19 051-8064-00 051-8064-00 - 1/2 Clear Braided Hose PRICED/ FOOT
$2.99
21 055-8018-75 055-8018-75 - Diesel Thottle Cable ONLY
$32.09
22 034-1000-00 034-1000-00 - Spring Cushion (See Models Used On For Detail)
$28.39
23 077-6000-00 077-6000-00 - Momentary Start Switch Preheat Button for Diesel
$21.39
24 014-6000-00 014-6000-00 - Start Switch Boot - Diesel
$6.59
25 021-8059-00 021-8059-00 - Heat Warning Piezo Buzzer
$36.37
26 015-0015-00 015-0015-00 - Auto Shut Down for Cat Diesels
$699.99
27 013-5019-00 013-5019-00 - 10-24 Nylon Insert Locknut Zinc
$2.99
28 018-5200-00 018-5200-00 - 10-24 X 5/8 BS C/S 18-8 SS
$2.99
29 013-8039-00 013-8039-00 - 1/4-20 Hex Nut
$2.99
30 072-8066-00 072-8066-00 - 1/2" Hose Clamp
$2.99
31 072-8065-00 072-8065-00 - 3/8" Hose Clamp - CTB-16-STFS
$2.99
32 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
33 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
34 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
35 043-8929-00 043-8929-00 - Battery Hold Down Kit
$17.49
36 064-4001-00 064-4001-00 - Black Battery Cable (See Models Used On For Details)
$22.31
37 064-4000-00 064-4000-00 - Red Battery Cable (See Models Used On For Details)
$23.53
38 026-2006-00 026-2006-00 - Seat Plate (See Models Used On For Details)
$99.32
39 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
40 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
41 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
42 071-4050-00 071-4050-00 - Grammer Suspension Seat Use w/o ROPS - Obsolete - USE PART #071-4050-17 (obsolete)
use part #071-4050-17
$759.99
45 034-1075-00 034-1075-00 - Torsion Spring-Seat Latch
$5.49
47 031-0200-00 031-0200-00 - Seat Latch Lever
$2.99
48 018-0012-00 018-0012-00 - 5/16-18 X 2 HEX C/S (GR.5)
$2.99
49 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
50 018-4702-00 018-4702-00 - 1/4-20 X 1-1/4 Hex Bolt
$2.99
51 014-2009-00 014-2009-00 - Cooler Cover (See Models Used On For Details)
$117.94
52 030-7042-00 030-7042-00 - 5/16 x 3/4 Hex Washer Type F Thread Cutting Screw
$2.99
53 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
54 013-5300-00 013-5300-00 - 1/2-13 Hex Fange Nuts Zinc w/ Serrations
$2.99
55 036-5300-00 036-5300-00 - Seat Switch Adaptor
$15.55
56 018-4007-00 018-4007-00 - 1/4-20 X 1 Hex Bolts Zinc
$2.99
57 025-2000-00 025-2000-00 -.380x.735x.470 Nylon Spacer
$2.99
