2015 Outlaw XP - Frame Assembly

2015 Outlaw XP - Frame Assembly

The 2015 Outlaw XP Frame Assembly is essential to the overall durability and structure of your mower. At BadBoyMowerParts.com, we carry a variety of Bad Boy Mower Parts designed to keep your frame in top condition. Whether you need a full frame replacement or specific components like braces and supports, we have you covered. Our Bad Boy Mower Part Diagrams help you quickly find the parts you need for a perfect fit. In addition to frame parts, we offer a full selection of Bad Boy Lawn Mower Parts to ensure your mower stays in excellent working order. You can easily order Bad Boy Parts Online, and with Free Shipping On Orders Over $100, you won’t have to worry about extra shipping costs.

Bad Boy Mower Parts Lookup

2015 Outlaw XP - Frame Assembly
  Position Number SKU Product Title Price
1A 088-3500-00 088-3500-00 - Mount Assist Handle
$58.84
1 079-3100-00 079-3100-00 - 2010-2015 Outlaw Floor Panel
$139.99
2 081-2008-00 081-2008-00 - Foot Assist Floor Mat (See Models Used On For Details)
$66.76
3 040-6080-00 040-6080-00 - Ratchet Fastener - Floorboard
$2.99
4 018-8064-00 018-8064-00 - 1/4-20 X 5/8 BS C/S 18-8 SS
$2.99
5 064-2006-00 064-2006-00 - Floorboard Cable
$15.55
6 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
7 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
8 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
9 030-3050-00 030-3050-00 - 10 X 1/2 Pan Phil a T/S Zinc
$2.99
10 029-4010-00 029-4010-00 - Button Bumper
$2.99
11 029-7038-00 029-7038-00 - 8 Bumper
$28.32
12 030-7039-00 030-7039-00 - 14 X 1-1/2 HWA A T/S Zinc
$2.99
13 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
14 108-5349-00 108-5349-00 - Solenoid (See Models Used On For Detail)
$29.41
15 013-9001-00 013-9001-00 - 1/4-20 Hex Flange Nuts Zinc w/Serrations
$2.99
16 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
17 086-0003-00 086-0003-00 - Alternator to Starter Cable
$7.79
18 064-5301-00 064-5301-00 - 12" Red Battery Cable
$17.16
20 103-5400-00 103-5400-00 - Black Cable Boot
$4.37
21 103-5300-00 103-5300-00 - Red Lug Boot
$5.82
22 043-8929-00 043-8929-00 - Battery Hold Down Kit
$17.49
23 018-8050-00 018-8050-00 - 1/4-20 X 8 Carriage Bolts Zinc Bolt for Battery Hold Down
$2.99
24 013-8039-00 013-8039-00 - 1/4-20 Hex Nut
$2.99
25 086-0005-00 086-0005-00 - Cable - Starter to Chassis (See Models Used On For Details)
$10.21
26 089-0002-00 089-0002-00 - 2x2 Folding ROPS, Fits 2011 Pup & Lightning, 2010-2018 Outlaw & Outlaw XP
$796.75
27 070-5380-00 070-5380-00 - 2015-2016 Outlaw XP Frame
$1299.99
28 028-6030-00 028-6030-00 - Actuator Bar (Front) (See Models Used On For Detail)
$189.99
29 028-6040-00 028-6040-00 - Actuator Bar (Rear) (See Models Used On For Detail)
$175.99
30 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
31 032-3000-00 032-3000-00 - Actuator Bar Bushing
$2.99
32 018-0008-00 018-0008-00 - 1/2 x 1 1/2 Carriage Bolt
$2.99
33 017-9000-00 017-9000-00 - Two Piece Pillow Block-Male
$10.99
34 017-9050-00 017-9050-00 - Two Piece Pillow Block-Female
$10.99
35A 017-9075-00 017-9075-00 - Pillow Block Assembly (See Models Used On For Details)
$38.51
35 017-9025-00 017-9025-00 - Two Piece Pillow Block-Plate
$32.09
36 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
37 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
38 018-0009-00 018-0009-00 - 3/8 x 1 3/4 Carriage Bolt
$2.99
39 040-4000-00 040-4000-00 - MZ, Diesel & Outlaw Deck Height Lever Pin
$17.16
40 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
41 031-0100-00 031-0100-00 - Deck Lever Lock (See Models Used On For Details)
$18.45
42 026-2100-00 026-2100-00 - Diesel & Outlaw Height Indicator Plate (Outer)
$12.83
43 019-2003-00 019-2003-00 - .390 x .750 x .062 Nylon Washer
$2.99
44 026-0013-00 026-0013-00 - 2010-2018 Outlaw & 2012-2018 Compact Diesel Deck Lift Pedal
$21.28
45 040-5000-00 040-5000-00 - Pull Pin - Foot Assist w/Ring
$21.39
46 030-0010-00 030-0010-00 - 5/16-18 x 1 Thumb Screw Zinc (No Shoulder)
$3.29
47 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
48 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
49 087-5400-00 087-5400-00 - 200lb Gas Spring - 54" Outlaw Deck Damper
$62.40
50 018-2055-00 018-2055-00 - 10mm Damper Stud-XP Linkage
$2.99
51 028-6055-00 028-6055-00 - Linkage Bar Suspension Frame (See Models Used On For Detail)
$28.39
52 039-5944-00 039-5944-00 - Pump Idler Bracket
$42.58
53 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
54 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
55 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
56 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
57 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
58 018-2004-00 018-2004-00 - All Thread-Pump Idler Tensioner
$12.94
59 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
60 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
61 035-7033-00 035-7033-00 - Actuator
$408.75
62 018-0022-00 018-0022-00 - 1/2-13 x 2 Grade 8 Hex Bolt
$2.99
63 019-5702-00 019-5702-00 - 1/2 SAE Flat Washer GR 8
$2.99
64 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknut Zinc Orange Nylon
$2.99
65 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
66 019-8054-00 019-8054-00 -.505 ID X 1 OD X.128 THK Flat Washer Nylon
$2.99
67 018-0050-00 018-0050-00 - 1/2-13 X 3.25 Hex Bolt-
$2.99
68 013-0005-00 013-0005-00 - 1/2" Center Lock Nut
$2.99
69 087-6100-00 087-6100-00 - 250lb Gas Spring - 61" Outlaw Deck Damper
$78.01
70 087-7200-00 087-7200-00 - 300 lb Gas Spring -72" Deck Damper
$62.40
71 018-2049-00 018-2049-00 - 13mm Ball Stud for 72" Deck Damper (See Models Used On For Details)
$4.83
