2011 CZT - 42" Deck Assembly

2011 CZT - 42" Deck Assembly

The 2011 CZT 42" Deck Assembly is a crucial component for achieving a precise and clean cut on your mower. If you're in need of a replacement or repair, look no further than BadBoyMowerParts.com. We provide top-quality Bad Boy Mower Parts to ensure your 42" deck is functioning at its best. Using our detailed Bad Boy Mower Part diagrams, you can easily identify and order the correct components for your 2011 CZT mower’s deck. Whether you need spindles, pulleys, or blades, we carry everything to keep your deck running smoothly. Our website offers a wide range of Bad Boy Lawn Mower Parts that are built to last. Shop Bad Boy Parts Online and take advantage of Free Shipping On Orders Over $100. With our high-quality parts and excellent service, you can keep your 2011 CZT 42" Deck Assembly in top shape, ensuring a perfect cut every time.

Bad Boy Mower Parts Lookup

2011 CZT - 42" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6006-00 088-6006-00 - Advanced Chute System For Select 42", 48", 50", 52" Mowers & select 54", 2022 - 2024 Maverick HD 42", Will Not Fit MZ
$249.00
1 060-4200-00 060-4200-00 - 2010-2012 42" CZT Deck - Shell Only
$1299.99
3 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
4 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
5 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
6 033-6003-00 033-6003-00 - 5" Spindle Deck Pulley - DB-80 (without set screw) (See Models Used On For Details)
$42.58
7 030-6029-00 030-6029-00 - 3/8-16x1/2 Set Screw
$2.99
8 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
9 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
10 048-6056-00 048-6056-00 - Toplink/Turnbuckle-Deck Adjust (See Models Used On For Details)
$53.49
11 018-6059-00 018-6059-00 - 5/8-11 X 2-1/2 Hex Bolts
$2.99
12 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
15 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
16 022-1000-98 022-1000-98 - Deck Wheel Assembly
$25.99
17 018-7050-00 018-7050-00 - 1/2-13 X 4-1/2 Hex Bolts
$2.99
18 019-5010-00 019-5010-00 -.565x1.25x.095 Washer Brass
$2.99
19 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
20 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
21 033-5001-00 033-5001-00 - 5 3/4" Flat Idler Double Width Pulley (See Description for Details)
$56.77
22 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
23 032-6033-00 032-6033-00 - Brass Bushing - SS-2024-18 Pump Idler Arms
$3.84
24 039-6936-00 039-6936-00 - Deck Idler Bracket
$39.74
25 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
26 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
27 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
28 025-5337-00 025-5337-00 -.502x.750x1.125 Length Spacer
$4.39
29 210-6015-98 210-6015-98 - Discharge Chute Assembly (See Models Used On For Detail)
$145.95
30.1 210-6005-48 210-6005-48 - Chute Assembly (See Models Used On For Detail)
$169.99
30 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
31 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
32 013-9001-00 013-9001-00 - 1/4-20 Hex Flange Nuts Zinc w/Serrations
$2.99
33 206-6017-00 206-6017-00 - Discharge Chute Hanger-Deck (See Models Used On For Detail)
$39.03
34 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
35 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
36 018-5015-00 018-5015-00 - 5/16-18 X 1 Button Head Bolt
$2.99
37 047-6050-00 047-6050-00 - CZT/ZT Deck Hanger Chain Assembly (See Models Used On For Details)
$8.74
38 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
39 014-4200-00 014-4200-00 - 42" Deck Pulley Cover (See Models Used On For Details)
$28.39
40 045-6043-00 045-6043-00 - Black Plastic Knob Spindle Cover
$4.39
41 018-4706-00 018-4706-00 - 3/8 x 1 1/2 Carriage Bolt
$2.99
42 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
43 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
44 034-9035-00 034-9035-00 - Deck Idler Spring
$17.11
45 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
46 019-4807-00 019-4807-00 - 5/8" Lockwasher Zinc
$2.99
47.1 038-4227-00 038-4227-00 - 42" Gator Blade
$21.99
47 038-4226-00 038-4226-00 - 42" High Lift Blade-Outlaw
$21.99
48 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
49 041-4022-00 041-4022-00 - B138 Deck Belt (See Models Used On For More Details, Not For 54" CZT/Stand-On)
$78.01
50 031-6020-00 031-6020-00 - Deck Hanger-Black
$132.68
