2010 CZT - 50" Deck Assembly

2010 CZT - 50" Deck Assembly

The 2010 CZT 50" Deck Assembly is designed for high-performance cutting with enhanced durability. At BadBoyMowerParts.com, we supply premium Bad Boy Mower Parts, including spindles, cutting blades, belts, and pulleys to keep your deck operating efficiently. Our Bad Boy Lawn Mower Parts inventory ensures factory-grade replacements built for superior performance. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the correct deck assembly components for easy installation. Routine deck maintenance improves blade sharpness, prevents excessive belt wear, and extends mower lifespan. We also stock Bad Boy Parts Online, making ordering deck components fast and simple. Plus, with Free Shipping On Orders Over $100, maintaining your 2010 CZT 50" Deck Assembly is now more budget-friendly. Order today to keep your mower’s deck in peak condition, ensuring precision cutting and extended durability for professional-grade results.

Bad Boy Mower Parts Lookup

2010 CZT - 50" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6006-00 088-6006-00 - Advanced Chute System For Select 42", 48", 50", 52" Mowers & select 54", 2022 - 2024 Maverick HD 42", Will Not Fit MZ
$249.00
1 041-1470-00 041-1470-00 - B147 Deck Belt (See Models Used On For Details)
$87.39
2.1 038-5000-00 038-5000-00 - 48"/50" Gator Mulching Blade
$22.99
2 038-5350-00 038-5350-00 - 48"/50" High Lift Fusion Blade
$22.99
3 060-4800-00 060-4800-00 - Deck Shell Only (obsolete)
use part #060-6048-00
$1196.14
5 037-6015-00 037-6015-00 - Short Shaft Spindle (obsolete)
use part #037-6015-50
$199.99
6 014-6004-00 014-6004-00 - Metal Spindle Cover (See Models Used On For Details)
$42.58
7 014-4801-00 014-4801-00 - 1/2 Metal Spindle Cover - Right (See Models Used On For Details)
$42.58
8 039-6936-00 039-6936-00 - Deck Idler Bracket
$39.74
9 206-6017-00 206-6017-00 - Discharge Chute Hanger-Deck (See Models Used On For Detail)
$39.03
10 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
11 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
12 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
13 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
14 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
15 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
16 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
17 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
18 033-6003-00 033-6003-00 - 5" Spindle Deck Pulley - DB-80 (without set screw) (See Models Used On For Details)
$42.58
19 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
20 033-5001-00 033-5001-00 - 5 3/4" Flat Idler Double Width Pulley (See Description for Details)
$56.77
21 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
22 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
23 018-6059-00 018-6059-00 - 5/8-11 X 2-1/2 Hex Bolts
$2.99
24 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
25 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
26 039-4864-00 039-4864-00 - Discharge Chute Upper Hanger Plate (See Models Used On For Detail)
$42.52
27 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
28.1 210-6005-48 210-6005-48 - Chute Assembly (See Models Used On For Detail)
$169.99
28 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
29 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
30 018-5015-00 018-5015-00 - 5/16-18 X 1 Button Head Bolt
$2.99
31 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zinc
$2.99
33A 022-1000-98 022-1000-98 - Deck Wheel Assembly
$25.99
35 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
37 019-4807-00 019-4807-00 - 5/8" Lockwasher Zinc
$2.99
38 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
39 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
40 045-6043-00 045-6043-00 - Black Plastic Knob Spindle Cover
$4.39
41 032-6033-00 032-6033-00 - Brass Bushing - SS-2024-18 Pump Idler Arms
$3.84
42 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
43 025-5337-00 025-5337-00 -.502x.750x1.125 Length Spacer
$4.39
44 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
45 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
46 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
47 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
48 013-6058-00 013-6058-00 - 3/4-10 Left Hand Hex Nut
$3.52
49 048-6056-00 048-6056-00 - Toplink/Turnbuckle-Deck Adjust (See Models Used On For Details)
$53.49
50 034-9035-00 034-9035-00 - Deck Idler Spring
$17.11
51 031-6020-00 031-6020-00 - Deck Hanger-Black
$132.68
53 047-6050-00 047-6050-00 - CZT/ZT Deck Hanger Chain Assembly (See Models Used On For Details)
$8.74
54 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
55 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
56 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
