2012 CZT - 50" Deck Assembly

2012 CZT - 50" Deck Assembly

Introducing the 2012 CZT 50" Deck Assembly, a precisely engineered component designed to provide an even, precise cut over a 50-inch width. This deck assembly is constructed from durable materials using advanced production techniques, ensuring optimal blade alignment and minimal vibration during operation. Its robust design enhances efficiency in grass collection and promotes a smooth mowing experience for both residential and commercial applications. Comprehensive installation instructions and maintenance guidelines are included to guarantee secure attachment and long service life. The assembly integrates flawlessly with the 2012 CZT’s overall structure, improving performance and cutting quality. For detailed schematics, verified components, and expert technical support, please consult Bad Boy Mower Part diagrams, Bad Boy Mower Parts, Bad Boy Lawn Mower Parts, Bad Boy Parts Online and Free Shipping On Orders Over $100 available on our website. Visit BadBoyMowerParts.com for guidance and professional advice. Upgrade your mower with this deck assembly to achieve superior cutting efficiency and results every time. Enjoy performance today.

Bad Boy Mower Parts Lookup

2012 CZT - 50" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6006-00 088-6006-00 - Advanced Chute System For Select 42", 48", 50", 52" Mowers & select 54", 2022 - 2024 Maverick HD 42", Will Not Fit MZ
$249.00
1 060-4800-00 060-4800-00 - Deck Shell Only (obsolete)
use part #060-6048-00
$1196.14
2 037-6015-00 037-6015-00 - Short Shaft Spindle (obsolete)
use part #037-6015-50
$199.99
3 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
4 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
5 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
6 033-6003-00 033-6003-00 - 5" Spindle Deck Pulley - DB-80 (without set screw) (See Models Used On For Details)
$42.58
7 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
8 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
9 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
10 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
11 030-6029-00 030-6029-00 - 3/8-16x1/2 Set Screw
$2.99
12.1 038-5000-00 038-5000-00 - 48"/50" Gator Mulching Blade
$22.99
12 038-5350-00 038-5350-00 - 48"/50" High Lift Fusion Blade
$22.99
13 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
14 019-4807-00 019-4807-00 - 5/8" Lockwasher Zinc
$2.99
15 037-6023-00 037-6023-00 - Spindle Bearing (See Models Used On For Details) (obsolete)
use part #037-6029-00
$42.58
16 048-6056-00 048-6056-00 - Toplink/Turnbuckle-Deck Adjust (See Models Used On For Details)
$53.49
17 031-6010-00 031-6010-00 - Deck Hanger (One Piece) (obsolete)
use part #031-6020-00
$132.68
18 018-1090-00 018-1090-00 - 1/2-13x5 1/2 Hex Bolt
$3.29
19 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
20 018-6059-00 018-6059-00 - 5/8-11 X 2-1/2 Hex Bolts
$2.99
21 033-5001-00 033-5001-00 - 5 3/4" Flat Idler Double Width Pulley (See Description for Details)
$56.77
22 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
23 034-9035-00 034-9035-00 - Deck Idler Spring
$17.11
24 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
25 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
26 018-4706-00 018-4706-00 - 3/8 x 1 1/2 Carriage Bolt
$2.99
27 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
28 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
29 018-6037-00 018-6037-00 - 1/2-13 X 2-1/4 Hex Bolt
$2.99
30 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
31 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
32 041-1470-00 041-1470-00 - B147 Deck Belt (See Models Used On For Details)
$87.39
33 039-6936-98 039-6936-98 - Deck Idler Assembly (See Models Used On For Details)
$86.66
34 039-6936-00 039-6936-00 - Deck Idler Bracket
$39.74
37 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
38 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
39 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
40 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
41 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
42 047-6050-00 047-6050-00 - CZT/ZT Deck Hanger Chain Assembly (See Models Used On For Details)
$8.74
43A 022-1000-98 022-1000-98 - Deck Wheel Assembly
$25.99
43 022-1000-00 022-1000-00 - Deck Wheel Only
$17.11
44 014-4801-00 014-4801-00 - 1/2 Metal Spindle Cover - Right (See Models Used On For Details)
$42.58
45 014-6004-00 014-6004-00 - Metal Spindle Cover (See Models Used On For Details)
$42.58
46 045-6043-00 045-6043-00 - Black Plastic Knob Spindle Cover
$4.39
47 032-5057-00 032-5057-00 - Flange for Lower Deck Arm SF-1622-5
$9.89
48 032-5056-00 032-5056-00 - Flange Bushing-Deck Arms EF081108 - Frame Mounted
$5.82
