2012 Stand-On - 54" Deck Assembly

2012 Stand-On - 54" Deck Assembly

For larger lawns, the 54" Deck Assembly for the 2012 Stand-On offers greater coverage and efficiency. If you're in need of replacement parts or an entire deck assembly, BadBoyMowerParts.com provides high-quality Bad Boy Mower Parts specifically designed for your mower. Our extensive range of Bad Boy Lawn Mower Parts includes everything from cutting blades to pulleys, ensuring your deck operates like new. We provide detailed Bad Boy Mower Part diagrams, allowing you to easily identify and order the components you need. Whether you’re replacing a damaged part or performing regular upkeep, we’ve got you covered. Shopping Bad Boy Parts Online is convenient, and our secure online ordering system ensures a smooth purchasing experience. Don’t forget to take advantage of Free Shipping On Orders Over $100, saving you money while getting your parts delivered right to your door. Visit BadBoyMowerParts.com today for your 2012 Stand-On 54" Deck Assembly needs.

Bad Boy Mower Parts Lookup

2012 Stand-On - 54" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6050-00 088-6050-00 - Cable Advanced Chute System Assembly (See Models Used On For Detail)
$249.00
2 030-6029-00 030-6029-00 - 3/8-16x1/2 Set Screw
$2.99
3 033-6003-00 033-6003-00 - 5" Spindle Deck Pulley - DB-80 (without set screw) (See Models Used On For Details)
$42.58
4 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
5 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
6 037-8000-50 037-8000-50 - Double Bearing Spindle - Aluminum Housing (obsolete)
use part #037-4000-00
$291.91
7 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
8 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
9 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
10.1 038-0003-00 038-0003-00 - 54" & 2024 Raider 36" Deck Gator Mulching Blade
$22.99
10 038-0001-00 038-0001-00 - 54" & 2024 Raider 36" High Lift Fusion Blade
$22.99
11 019-4807-00 019-4807-00 - 5/8" Lockwasher Zinc
$2.99
12 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
13 037-8001-00 037-8001-00 - Double Bearing for Spindle (See Models Used On For Details)
$46.78
14 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
15 018-6059-00 018-6059-00 - 5/8-11 X 2-1/2 Hex Bolts
$2.99
16 048-6056-00 048-6056-00 - Toplink/Turnbuckle-Deck Adjust (See Models Used On For Details)
$53.49
17 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
18 060-5530-00 060-5530-00 - Adjustable Deck Front Right (See Models Used On For Details)
$85.99
19A 022-1000-98 022-1000-98 - Deck Wheel Assembly
$25.99
19 022-1000-00 022-1000-00 - Deck Wheel Only
$17.11
20 060-5520-00 060-5520-00 - Adjustable Deck Front Left (See Models Used On For Details)
$85.99
21 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
22 014-6010-00 014-6010-00 - Plastic Pulley Cover (See Models Used On For Details) (obsolete)
use part #014-4000-00
$28.39
23 045-6043-00 045-6043-00 - Black Plastic Knob Spindle Cover
$4.39
24 018-3003-00 018-3003-00 - 1/2 x 1 1/4 Carriage Bolt
$2.99
25 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
26 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
27 033-5001-00 033-5001-00 - 5 3/4" Flat Idler Double Width Pulley (See Description for Details)
$56.77
28 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
29 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
30 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
31 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
32 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
33 018-6037-00 018-6037-00 - 1/2-13 X 2-1/4 Hex Bolt
$2.99
34 031-6010-00 031-6010-00 - Deck Hanger (One Piece) (obsolete)
use part #031-6020-00
$132.68
35 018-1090-00 018-1090-00 - 1/2-13x5 1/2 Hex Bolt
$3.29
36.1 210-6005-98 210-6005-98 - Chute Assembly (See Models Used On For Detail)
$149.99
36 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
37 039-4864-00 039-4864-00 - Discharge Chute Upper Hanger Plate (See Models Used On For Detail)
$42.52
38 039-4863-00 039-4863-00 - Discharge Lower Bracket Rubber Chute (See Models Used On For Detail)
$32.65
39 206-6017-00 206-6017-00 - Discharge Chute Hanger-Deck (See Models Used On For Detail)
$39.03
40 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
41 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
42 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
43 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
44 018-2007-00 018-2007-00 - 5/16-18 X 1 Hex Bolt Zinc
$2.99
45 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
46 047-4000-00 047-4000-00 - 4 - Link Adjustable Deck Hanger - Pup Models (obsolete)
use part #046-6048-98
$32.09
47 041-0120-00 041-0120-00 - Deck Belt (See Models Used On For More Details - Not for 54" MZ)
$88.80
48 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
49 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
50 032-5057-00 032-5057-00 - Flange for Lower Deck Arm SF-1622-5
$9.89
51 032-5056-00 032-5056-00 - Flange Bushing-Deck Arms EF081108 - Frame Mounted
$5.82
52 018-2004-00 018-2004-00 - All Thread-Pump Idler Tensioner
$12.94
53 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
54 039-6945-98 039-6945-98 - Deck Idler Assy
$78.08
55 033-7201-00 033-7201-00 - 5 3/4 Idler Pulley
$35.48
