2007 AOS 60" Deck Assembly

60" Deck Assembly

The Bad Boy Mower parts diagram for the 2007 AOS 60" Deck is shown below. You may select the item you need by clicking on the Bad Boy Parts item number in the diagram or by finding it in the list below the diagram. BadBoyMowerParts.com has the badboy mowers parts diagrams for the 2007 AOS models. Find all of your Bad Boy mowers 2007 AOS parts here. We are your BadBoy mower parts source. Thanks for shopping with us for all of your Bad Boy parts needs. The Bad Boy parts diagram below is for the 2007 AOS 60" Deck. If you are not able to find the Bad Boy parts for your 2007 AOS please contact us using our Bad Boy parts live chat or toll free at 318.654.8520.

Bad Boy Mower Parts Lookup

2007 AOS 60" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6000-00 088-6000-00 - Advanced Chute System for Select 2007-2024 Models with 60", 61", and 72" Decks & 2014-Newer ZT/CZT/Maverick 54" Decks (Will Not Work on 54" Outlaw)
$266.99
1A 041-2375-00 041-2375-00 - B237.50 Deck Belt for 60" AOS Diesel & 72" AOS Gas Models (NOT FOR 72" DIESEL)
$140.49
1 041-0219-00 041-0219-00 - B219 Deck Belt for 60" AOS w/ Gas Engine
$117.06
2 038-6060-00 038-6060-00 - 60" High Lift Fusion Blade & 2023-2025 Revolt SD 42"
$22.99
4 206-6017-00 206-6017-00 - Discharge Chute Hanger-Deck (See Models Used On For Detail)
$39.03
5 014-6004-00 014-6004-00 - Metal Spindle Cover (See Models Used On For Details)
$42.58
6 037-6015-00 037-6015-00 - Short Shaft Spindle (obsolete)
use part #037-6015-50
$213.99
8 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
9 033-6004-00 033-6004-00 - 6 1/4 Spindle Deck Pulley 60 & 61 Decks DDB-100 (without set screw)
$35.48
10 033-5001-00 033-5001-00 - 5 3/4" Flat Idler Double Width Pulley (See Description for Details)
$56.77
11 025-5337-00 025-5337-00 -.502x.750x1.125 Length Spacer
$2.99
12 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500 Leng th Spacer Zinc
$3.62
13 025-5339-00 025-5339-00 -.502 ID X 1.00 OD X 1.750 Leng th Spacer Zinc
$5.36
14 048-6056-00 048-6056-00 - Toplink/Turnbuckle-Deck Adjust (See Models Used On For Details)
$53.49
16 031-6027-00 031-6027-00 - OBSOLETE use 031-6020-00 Deck Arm (left) (obsolete)
use part #031-6020-00
$141.97
17 031-6028-00 031-6028-00 - OBSOLETE use 031-6020-00 Deck Arm (Right) (obsolete)
use part #031-6020-00
$141.97
18A 022-1000-98 022-1000-98 - Deck Wheel Assembly
$25.99
20 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
21 034-9035-00 034-9035-00 - Deck Idler Spring
$17.11
22 045-6043-00 045-6043-00 - 5/16 Black Plastic Knob Spindle Cover
$4.39
23 046-6044-00 046-6044-00 - Female Yoke (See Models Used On For Details)
$10.77
24 046-6048-00 046-6048-00 - Male Yoke
$15.60
25 047-6047-00 047-6047-00 - 3 Chain
$2.99
26 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
27 032-6033-00 032-6033-00 - Brass Bushing - SS-2024-18 Pump Idler Arms
$3.84
28 018-6049-00 018-6049-00 - 3/8-16 X 1 GR 5 Hex Bolts Zinc
$2.99
29 019-5037-00 019-5037-00 - 3/8 Lockwasher Zinc
$2.99
30 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
31 018-5006-00 018-5006-00 - 1/2-13 X 1-1/2 GR 5 Hex Bolt, Coarse Thread Bolt (For Use On Spindles Please Refer To Item Details)
$2.99
32 030-6029-00 030-6029-00 - 3/8-16x1/2 Socket Set Cup Poin
$2.99
33 019-4807-00 019-4807-00 - 5/8 Lockwasher Zinc
$2.99
34 018-5250-00 018-5250-00 - 3/8-16 X 3/4 GR 5 Hex Bolts
$2.99
35 018-5311-00 018-5311-00 - 5/8-11 X 4 GR 5 Hex Bolts Zinc
$4.06
36 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
37 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
38 018-5015-00 018-5015-00 - 5/16-18 X 1 Button Head Bolt
$2.99
39 013-8047-00 013-8047-00 - 5/16-18 Nylon Insert Locknut Z inc Orange Nylon
$2.99
40 018-6059-00 018-6059-00 - 5/8-11 X 2-1/2 GR 5 Hex Bolts
$2.99
41 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zi nc Orange Nylon
$2.99
42 018-6054-00 018-6054-00 - 1/2-13 X 3-1/2 GR 5 Hex Bolts
$2.99
43 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zi nc Orange Nylon
$2.99
44 019-5010-00 019-5010-00 -.565x1.25x.095 Washer Brass
$2.99
45 018-7050-00 018-7050-00 - 1/2-13 X 4-1/2 GR 5 Hex Bolts
$2.99
46 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 GR 5 Hex Bolt
$2.99
47 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
48 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
49 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 GR 5 Bolt Zinc
$2.99
50 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
51 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
54 039-4864-00 039-4864-00 - Discharge Chute Upper Hanger Plate (See Models Used On For Detail)
$42.52
55 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
56 018-5020-00 018-5020-00 - 5/16-18 X 1-1/2 Carriage Bolt
$2.99
57 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
58 018-7016-00 018-7016-00 - 1/2-13 X 3 GR 5 Hex Bolts Zinc
$2.99
59 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
59 039-6936-00 039-6936-00 - Deck Idler Bracket
$39.74
60 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
