2007 ZT - 60" Deck Assembly

2007 ZT - 60" Deck Assembly

The 2007 ZT 60" Deck Assembly offers a wide cutting area, perfect for those with larger lawns. To ensure it operates at peak efficiency, BadBoyMowerParts.com provides a full range of Bad Boy Mower Parts specifically designed for the 60-inch deck. Whether you’re replacing the blades or upgrading components, you’ll find detailed Bad Boy Mower Part diagrams to help you select the correct parts for your mower. The Bad Boy Lawn Mower Parts collection covers everything you need to maintain or repair your 2007 ZT. By shopping Bad Boy Parts Online, you can easily find what you need and have it shipped directly to you. With Free Shipping On Orders Over $100, maintaining your 60-inch deck has never been more convenient or cost-effective.

Bad Boy Mower Parts Lookup

2007 ZT - 60" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6000-00 088-6000-00 - Advanced Chute System for Select 2007-2025 Models with 60", 61", and 72" Decks & 2014-Newer ZT/CZT/Maverick 54" Decks (Will Not Work on 54" Outlaw)
$249.00
1 041-1650-00 041-1650-00 - B165 Deck Belt (See Models Used On For More Details, Not For 54" ZT/CZT/Maverick)
$90.94
2 038-6060-00 038-6060-00 - 60" High Lift Fusion Blade & 2023-2025 Revolt SD 42"
$22.99
3 060-6005-00 060-6005-00 - 2007-2013 60" ZT Deck - Shell Only (See Models Used On For Details)
$1328.83
5 014-6004-00 014-6004-00 - Metal Spindle Cover (See Models Used On For Details)
$42.58
6 037-6015-00 037-6015-00 - Short Shaft Spindle (obsolete)
use part #037-6015-50
$199.99
7 039-6936-00 039-6936-00 - Deck Idler Bracket
$39.74
9 033-6004-00 033-6004-00 - 6 1/4" Spindle Deck Pulley (without set screw) (See Models Used On For Detail)
$35.48
10 033-5001-00 033-5001-00 - 5 3/4" Flat Idler Double Width Pulley (See Description for Details)
$56.77
11 025-5337-00 025-5337-00 -.502x.750x1.125 Length Spacer
$4.39
12 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
13 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
14 048-6056-00 048-6056-00 - Toplink/Turnbuckle-Deck Adjust (See Models Used On For Details)
$53.49
15 013-6058-00 013-6058-00 - 3/4-10 Left Hand Hex Nut
$3.52
16 031-6027-00 031-6027-00 - OBSOLETE use 031-6020-00 Deck Arm (left) (obsolete)
use part #031-6020-00
$132.68
17 031-6028-00 031-6028-00 - OBSOLETE use 031-6020-00 Deck Arm (Right) (obsolete)
use part #031-6020-00
$132.68
18A 022-1000-98 022-1000-98 - Deck Wheel Assembly
$25.99
20 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
21 034-2008-00 034-2008-00 - Deck Idler Spring (See Models Used On For Detail)
$17.11
22 045-6043-00 045-6043-00 - Black Plastic Knob Spindle Cover
$4.39
23 046-6044-00 046-6044-00 - Female Yoke (See Models Used On For Details)
$10.77
24 046-6048-00 046-6048-00 - Male Yoke
$15.60
25 047-6047-00 047-6047-00 - 3 Chain (See Models Used On For Details)
$2.99
26 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
27 032-6033-00 032-6033-00 - Brass Bushing - SS-2024-18 Pump Idler Arms
$3.84
28 018-6049-00 018-6049-00 - 3/8-16 X 1 Hex Bolts Zinc
$2.99
29 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
30 018-6021-00 018-6021-00 - OBSOLETE - Use Part 018-6020-00 (obsolete)
use part #018-6020-00
$2.99
31 018-5006-00 018-5006-00 - 1/2-13 X 1-1/2 Hex Bolt, Coarse Thread Bolt (For Use On Spindles Please Refer To Item Details)
$2.99
32 030-6029-00 030-6029-00 - 3/8-16x1/2 Set Screw
$2.99
33 019-4807-00 019-4807-00 - 5/8" Lockwasher Zinc
$2.99
34 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
35 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
36 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
37 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
38 018-5015-00 018-5015-00 - 5/16-18 X 1 Button Head Bolt
$2.99
39 013-8047-00 013-8047-00 - 5/16-18 Nylon Insert Locknut - Zinc
$2.99
40 018-6059-00 018-6059-00 - 5/8-11 X 2-1/2 Hex Bolts
$2.99
41 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
42 018-6054-00 018-6054-00 - 1/2-13 X 3-1/2 Hex Bolts
$2.99
43 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zinc
$2.99
44 019-5010-00 019-5010-00 -.565x1.25x.095 Washer Brass
$2.99
45 018-7050-00 018-7050-00 - 1/2-13 X 4-1/2 Hex Bolts
$2.99
46 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
47 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
48 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
49 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
50 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
51 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
54 039-4864-00 039-4864-00 - Discharge Chute Upper Hanger Plate (See Models Used On For Detail)
$42.52
55 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
56 018-5020-00 018-5020-00 - 5/16-18 X 1-1/2 Carriage Bolt
$2.99
57 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
