2009 Diesel - 60" Deck Assembly

2009 Diesel - 60" Deck Assembly

At BadBoyMowerParts.com, we offer the perfect replacement for your 2009 Diesel 60" Deck Assembly, designed to keep your mower cutting smoothly. A well-maintained deck is crucial for your mower’s efficiency, and we provide high-quality Bad Boy Mower Parts that ensure durability and performance. Our comprehensive Bad Boy Mower Part Diagrams help you easily find the deck assembly and related components you need for your mower. Whether you’re looking for a full deck replacement or specific Bad Boy Lawn Mower Parts like pulleys, spindles, or blades, we have everything you need. Ordering Bad Boy Parts Online is fast and straightforward on our website, where you can quickly browse for the parts that fit your model. Plus, enjoy Free Shipping On Orders Over $100 to get your parts delivered without extra cost, making it even easier to keep your 2009 Diesel Bad Boy Mower running at its best.

Bad Boy Mower Parts Lookup

2009 Diesel - 60" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6000-00 088-6000-00 - Advanced Chute System for Select 2007-2025 Models with 60", 61", and 72" Decks & 2014-Newer ZT/CZT/Maverick 54" Decks (Will Not Work on 54" Outlaw)
$249.00
1 041-0222-00 041-0222-00 - B222 Deck Belt for 60" 28hp/1100cc Diesels (Not AOS Diesels) & 61" Renegade Gas/Diesel
$122.06
2.1 038-6003-00 038-6003-00 - 60" Gator Mulching Blade & 2023-2025 Revolt SD 42"
$22.99
2 038-6060-00 038-6060-00 - 60" High Lift Fusion Blade & 2023-2025 Revolt SD 42"
$22.99
5 014-6004-00 014-6004-00 - Metal Spindle Cover (See Models Used On For Details)
$42.58
6 037-8000-00 037-8000-00 - Spindle - Obsolete - Use 037-4000-00 (obsolete)
use part #037-4000-00
$291.91
8 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
9 033-6004-00 033-6004-00 - 6 1/4" Spindle Deck Pulley (without set screw) (See Models Used On For Detail)
$35.48
10 033-5001-00 033-5001-00 - 5 3/4" Flat Idler Double Width Pulley (See Description for Details)
$56.77
11 025-5337-00 025-5337-00 -.502x.750x1.125 Length Spacer
$4.39
12 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
13 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
14 048-6056-00 048-6056-00 - Toplink/Turnbuckle-Deck Adjust (See Models Used On For Details)
$53.49
15 013-6058-00 013-6058-00 - 3/4-10 Left Hand Hex Nut
$3.52
16 031-6027-00 031-6027-00 - OBSOLETE use 031-6020-00 Deck Arm (left) (obsolete)
use part #031-6020-00
$132.68
17 031-6028-00 031-6028-00 - OBSOLETE use 031-6020-00 Deck Arm (Right) (obsolete)
use part #031-6020-00
$132.68
18A 022-1000-98 022-1000-98 - Deck Wheel Assembly
$25.99
20 013-5300-00 013-5300-00 - 1/2-13 Hex Fange Nuts Zinc w/ Serrations
$2.99
21 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
22 045-6043-00 045-6043-00 - Black Plastic Knob Spindle Cover
$4.39
23 046-6044-00 046-6044-00 - Female Yoke (See Models Used On For Details)
$10.77
24 046-6048-00 046-6048-00 - Male Yoke
$15.60
25 047-6047-00 047-6047-00 - 3 Chain (See Models Used On For Details)
$2.99
26 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
27 032-6033-00 032-6033-00 - Brass Bushing - SS-2024-18 Pump Idler Arms
$3.84
28 018-6049-00 018-6049-00 - 3/8-16 X 1 Hex Bolts Zinc
$2.99
29 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
30 018-6021-00 018-6021-00 - OBSOLETE - Use Part 018-6020-00 (obsolete)
use part #018-6020-00
$2.99
31 018-5006-00 018-5006-00 - 1/2-13 X 1-1/2 Hex Bolt, Coarse Thread Bolt (For Use On Spindles Please Refer To Item Details)
$2.99
32 030-6029-00 030-6029-00 - 3/8-16x1/2 Set Screw
$2.99
33 019-4807-00 019-4807-00 - 5/8" Lockwasher Zinc
$2.99
34 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
35 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
36 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
37 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
38 018-5015-00 018-5015-00 - 5/16-18 X 1 Button Head Bolt
$2.99
39 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
40 018-6059-00 018-6059-00 - 5/8-11 X 2-1/2 Hex Bolts
$2.99
44 018-7050-00 018-7050-00 - 1/2-13 X 4-1/2 Hex Bolts
$2.99
45 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
46 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
47 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
48 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
49 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
50 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
52 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
54 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
56 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
57 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
59 039-6936-00 039-6936-00 - Deck Idler Bracket
$39.74
