2012 Outlaw XP - 61" Deck Assembly

2012 Outlaw XP - 61" Deck Assembly

The 61" Deck Assembly on the 2012 Outlaw XP is designed for precision and efficiency, offering a wider cutting path for larger properties. If you need replacement parts, BadBoyMowerParts.com has everything you need, including spindles, pulleys, and belts. Our extensive selection of Bad Boy Mower Parts is made to keep your deck performing at its best. The Bad Boy Mower Part diagrams on our site make it easy to locate the right parts, ensuring a smooth and stress-free repair process. Whether you're replacing worn-out components or performing routine maintenance, our Bad Boy Lawn Mower Parts are built to last. Shopping Bad Boy Parts Online is quick and simple, and our fast processing ensures you get your parts without delay. Plus, with Free Shipping On Orders Over $100, you can save on delivery costs while keeping your mower in top working condition. Visit BadBoyMowerParts.com for all your deck assembly parts.

Bad Boy Mower Parts Lookup

2012 Outlaw XP - 61" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6000-00 088-6000-00 - Advanced Chute System for Select 2007-2025 Models with 60", 61", and 72" Decks & 2014-Newer ZT/CZT/Maverick 54" Decks (Will Not Work on 54" Outlaw)
$249.00
1 060-6100-00 060-6100-00 - 61" Deck Shell (See Models Used On For Details)
$1461.53
2 031-6010-00 031-6010-00 - Deck Hanger (One Piece) (obsolete)
use part #031-6020-00
$132.68
3 033-5001-00 033-5001-00 - 5 3/4" Flat Idler Double Width Pulley (See Description for Details)
$56.77
4 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
5 033-6004-00 033-6004-00 - 6 1/4" Spindle Deck Pulley (without set screw) (See Models Used On For Detail)
$35.48
6 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
7 039-4863-00 039-4863-00 - Discharge Lower Bracket Rubber Chute (See Models Used On For Detail)
$32.65
8 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
9 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
10 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
11 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
12.1 210-6005-98 210-6005-98 - Chute Assembly (See Models Used On For Detail)
$149.99
12 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
13 060-6220-00 060-6220-00 - 61 Adjustable Deck Front (Left Gate) (See Models Used On For Detail)
$103.99
14 060-6210-00 060-6210-00 - 61 Adjustable Deck Front (Right Gate) (See Models Used On For Detail)
$103.99
15 206-6017-00 206-6017-00 - Discharge Chute Hanger-Deck (See Models Used On For Detail)
$39.03
16 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
17 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
18 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
19 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
20 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
21 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
22 018-2007-00 018-2007-00 - 5/16-18 X 1 Hex Bolt Zinc
$2.99
23 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
24 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
25 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
26 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
27 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
28 019-4807-00 019-4807-00 - 5/8" Lockwasher Zinc
$2.99
29 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
30 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
31 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
32 018-3003-00 018-3003-00 - 1/2 x 1 1/4 Carriage Bolt
$2.99
33 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
34 018-1050-00 018-1050-00 - 1/2 x 2 Carriage Bolt
$2.99
35 019-2040-00 019-2040-00 - 1/2 Flat Washer
$2.99
36 018-1090-00 018-1090-00 - 1/2-13x5 1/2 Hex Bolt
$3.29
37 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
38 047-6047-98 047-6047-98 - 3-Link Adjustable Deck Hanger (obsolete)
use part #046-6048-98
$32.09
39A 022-1000-98 022-1000-98 - Deck Wheel Assembly
$25.99
39 022-1000-00 022-1000-00 - Deck Wheel Only
$17.11
40 041-0178-00 041-0178-00 - B178 Deck Belt For 61" Decks (See Models Used On For Details)
$96.29
41 014-6010-00 014-6010-00 - Plastic Pulley Cover (See Models Used On For Details) (obsolete)
use part #014-4000-00
$28.39
42 045-6043-00 045-6043-00 - Black Plastic Knob Spindle Cover
$4.39
43 037-8000-50 037-8000-50 - Double Bearing Spindle - Aluminum Housing (obsolete)
use part #037-4000-00
$291.91
44.1 038-6081-00 038-6081-00 - 61" Gator Blade for Outlaw
$22.99
44 038-6080-00 038-6080-00 - 61" High Lift Fusion Blade
$22.99
45 018-6037-00 018-6037-00 - 1/2-13 X 2-1/4 Hex Bolt
$2.99
46 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
47 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
48 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
49 039-4864-00 039-4864-00 - Discharge Chute Upper Hanger Plate (See Models Used On For Detail)
$42.52
50 039-6945-98 039-6945-98 - Deck Idler Assy
$78.08
51 018-5049-00 018-5049-00 - 1/2-13 X 2 Hex Bolts Zinc
$2.99
52 028-6060-00 028-6060-00 - Panhard Linkage Bar Outlaw and Diesel Decks (See Models Used On For Detail)
$12.77
53 019-8054-00 019-8054-00 -.505 ID X 1 OD X.128 THK Flat Washer Nylon
$2.99
54 013-5300-00 013-5300-00 - 1/2-13 Hex Fange Nuts Zinc w/ Serrations
$2.99
55 032-5056-00 032-5056-00 - Flange Bushing-Deck Arms EF081108 - Frame Mounted
$5.82
56 032-5057-00 032-5057-00 - Flange for Lower Deck Arm SF-1622-5
$9.89
57 037-8001-00 037-8001-00 - Double Bearing for Spindle (See Models Used On For Details)
$46.78
