2012 Outlaw XP - 72" Deck Assembly

2012 Outlaw XP - 72" Deck Assembly

For larger properties, the 72" Deck Assembly of the 2012 Outlaw XP provides a wide cutting path for quicker, more efficient mowing. If you need to replace or maintain your deck assembly, BadBoyMowerParts.com offers a full range of Bad Boy Mower Parts to keep your mower in optimal working condition. Our Bad Boy Mower Part diagrams help you identify the exact parts you need, including spindles, pulleys, and belts. All our Bad Boy Lawn Mower Parts are crafted for durability and performance, so you can rely on them for extended use. Shopping Bad Boy Parts Online ensures that you get exactly what you need, quickly and securely. Plus, with Free Shipping On Orders Over $100, you can save on delivery costs. Whether you need a complete replacement or just a few parts for maintenance, BadBoyMowerParts.com has everything to keep your 2012 Outlaw XP running smoothly. Shop today!

Bad Boy Mower Parts Lookup

2012 Outlaw XP - 72" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6000-00 088-6000-00 - Advanced Chute System for Select 2007-2025 Models with 60", 61", and 72" Decks & 2014-Newer ZT/CZT/Maverick 54" Decks (Will Not Work on 54" Outlaw)
$249.00
1 060-7230-00 060-7230-00 - 2010-2014 Outlaw/Outlaw XP 72" Deck Shell
$1461.53
2 037-8000-50 037-8000-50 - Double Bearing Spindle - Aluminum Housing (obsolete)
use part #037-4000-00
$291.91
3 019-4807-00 019-4807-00 - 5/8" Lockwasher Zinc
$2.99
4 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
5 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
6 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
7 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
9.1 038-5400-00 038-5400-00 - 72" Gator Mulching Blade
$24.99
9 038-7230-00 038-7230-00 - 72" High Lift Fusion Blade
$24.99
10 033-7203-00 033-7203-00 - 7" Spindle Deck Pulley 72" Decks
$35.48
11 030-6029-00 030-6029-00 - 3/8-16x1/2 Set Screw
$2.99
12 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
13 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
14 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
15 206-6017-00 206-6017-00 - Discharge Chute Hanger-Deck (See Models Used On For Detail)
$39.03
16 039-4864-00 039-4864-00 - Discharge Chute Upper Hanger Plate (See Models Used On For Detail)
$42.52
17.1 210-6005-98 210-6005-98 - Chute Assembly (See Models Used On For Detail)
$149.99
17 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
18 039-4863-00 039-4863-00 - Discharge Lower Bracket Rubber Chute (See Models Used On For Detail)
$32.65
19 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
20 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
21 018-2007-00 018-2007-00 - 5/16-18 X 1 Hex Bolt Zinc
$2.99
22 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
23 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
24 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
25 047-6047-98 047-6047-98 - 3-Link Adjustable Deck Hanger (obsolete)
use part #046-6048-98
$32.09
26 060-7211-00 060-7211-00 - 72" Deck Adjustable Front (Right Gate) (See Models Used On For Detail)
$103.99
27 060-7210-00 060-7210-00 - 72" Deck Adjustable Front (Left Gate) (See Models Used On For Detail)
$103.99
28 018-3003-00 018-3003-00 - 1/2 x 1 1/4 Carriage Bolt
$2.99
29 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
30A 022-1000-98 022-1000-98 - Deck Wheel Assembly
$25.99
30 022-1000-00 022-1000-00 - Deck Wheel Only
$17.11
31 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
32 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
33 033-7201-00 033-7201-00 - 5 3/4 Idler Pulley
$35.48
34 033-5001-00 033-5001-00 - 5 3/4" Flat Idler Double Width Pulley (See Description for Details)
$56.77
35 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
36 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
37 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
38 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
39 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
40 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
41 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
42 018-1050-00 018-1050-00 - 1/2 x 2 Carriage Bolt
$2.99
43 019-2040-00 019-2040-00 - 1/2 Flat Washer
$2.99
44 018-5049-00 018-5049-00 - 1/2-13 X 2 Hex Bolts Zinc
$2.99
45 028-6060-00 028-6060-00 - Panhard Linkage Bar Outlaw and Diesel Decks (See Models Used On For Detail)
$12.77
46 019-8054-00 019-8054-00 -.505 ID X 1 OD X.128 THK Flat Washer Nylon
$2.99
47 013-5300-00 013-5300-00 - 1/2-13 Hex Fange Nuts Zinc w/ Serrations
$2.99
48 031-6010-00 031-6010-00 - Deck Hanger (One Piece) (obsolete)
use part #031-6020-00
$132.68
49 018-1090-00 018-1090-00 - 1/2-13x5 1/2 Hex Bolt
$3.29
50 018-6037-00 018-6037-00 - 1/2-13 X 2-1/4 Hex Bolt
$2.99
51 014-7204-00 014-7204-00 - 72" Spindle Cover (See Models Used On For Details)
$42.58
52 045-6043-00 045-6043-00 - Black Plastic Knob Spindle Cover
$4.39
53 041-0202-00 041-0202-00 - B202 Deck Belt for 72" (See Models Used On for Details)
$109.40
54 032-5056-00 032-5056-00 - Flange Bushing-Deck Arms EF081108 - Frame Mounted
$5.82
55 032-5057-00 032-5057-00 - Flange for Lower Deck Arm SF-1622-5
$9.89
56 039-6945-98 039-6945-98 - Deck Idler Assy
$78.08
59 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
