2013 Diesels - 72" Deck Assembly

2013 Diesels - 72" Deck Assembly

For those using a 2013 Diesels 72" Deck Assembly, maintaining peak performance is essential for achieving professional-quality cuts. At BadBoyMowerParts.com, we provide high-quality Bad Boy Mower Parts to keep your mower running smoothly. From blades and spindles to belts and tensioners, our Bad Boy Mower Part diagrams help you quickly identify the exact part you need. Our stock of Bad Boy Lawn Mower Parts includes everything required to keep your 72" deck in excellent condition. Ordering Bad Boy Parts Online is fast and convenient, ensuring minimal downtime for your mower. Additionally, with Free Shipping On Orders Over $100, you can get the parts you need without extra cost. Whether you're replacing worn-out components or upgrading your mower, we have you covered. Visit our site today and find the right parts to maintain your 2013 Diesels deck assembly.

Bad Boy Mower Parts Lookup

2013 Diesels - 72" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6000-00 088-6000-00 - Advanced Chute System for Select 2007-2025 Models with 60", 61", and 72" Decks & 2014-Newer ZT/CZT/Maverick 54" Decks (Will Not Work on 54" Outlaw)
$249.00
1 060-7201-00 060-7201-00 - 72" Deck Shell W/O Front Gates (See Models Used On For Detail)
$1594.22
2 037-8000-00 037-8000-00 - Spindle - Obsolete - Use 037-4000-00 (obsolete)
use part #037-4000-00
$291.91
3 019-4807-00 019-4807-00 - 5/8" Lockwasher Zinc
$2.99
4 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
5 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
6 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
7 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
8 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
9.1 038-5400-00 038-5400-00 - 72" Gator Mulching Blade
$24.99
9 038-7230-00 038-7230-00 - 72" High Lift Fusion Blade
$24.99
10 033-7203-00 033-7203-00 - 7" Spindle Deck Pulley 72" Decks
$35.48
11 030-6029-00 030-6029-00 - 3/8-16x1/2 Set Screw
$2.99
12 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
13 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
14 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
15 206-6017-00 206-6017-00 - Discharge Chute Hanger-Deck (See Models Used On For Detail)
$39.03
16 039-4864-00 039-4864-00 - Discharge Chute Upper Hanger Plate (See Models Used On For Detail)
$42.52
17.1 210-6005-98 210-6005-98 - Chute Assembly (See Models Used On For Detail)
$149.99
17 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
18 039-4863-00 039-4863-00 - Discharge Lower Bracket Rubber Chute (See Models Used On For Detail)
$32.65
19 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
20 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
21 018-2007-00 018-2007-00 - 5/16-18 X 1 Hex Bolt Zinc
$2.99
22 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
23 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
24 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
25 047-5000-00 047-5000-00 - 5 Link Adjustable Deck Hanger (See Models Used On For Details)
$28.39
26 060-7211-00 060-7211-00 - 72" Deck Adjustable Front (Right Gate) (See Models Used On For Detail)
$103.99
27 060-7210-00 060-7210-00 - 72" Deck Adjustable Front (Left Gate) (See Models Used On For Detail)
$103.99
28 018-3003-00 018-3003-00 - 1/2 x 1 1/4 Carriage Bolt
$2.99
29 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
30A 022-1000-98 022-1000-98 - Deck Wheel Assembly
$25.99
30 022-1000-00 022-1000-00 - Deck Wheel Only
$17.11
31 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
32 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
33 033-7201-00 033-7201-00 - 5 3/4 Idler Pulley
$35.48
34 033-5001-00 033-5001-00 - 5 3/4" Flat Idler Double Width Pulley (See Description for Details)
$56.77
35 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
36 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
37 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
38 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
39 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
41 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
42 018-1050-00 018-1050-00 - 1/2 x 2 Carriage Bolt
$2.99
43 019-2040-00 019-2040-00 - 1/2 Flat Washer
$2.99
44 031-6010-00 031-6010-00 - Deck Hanger (One Piece) (obsolete)
use part #031-6020-00
$132.68
45 018-1090-00 018-1090-00 - 1/2-13x5 1/2 Hex Bolt
$3.29
46 018-6037-00 018-6037-00 - 1/2-13 X 2-1/4 Hex Bolt
$2.99
47 014-7204-00 014-7204-00 - 72" Spindle Cover (See Models Used On For Details)
$42.58
48 045-6043-00 045-6043-00 - Black Plastic Knob Spindle Cover
$4.39
49 041-2525-00 041-2525-00 - B252.50 Deck Belt for 72" AOS Diesel (35hp/1500cc)
$131.30
50 032-5056-00 032-5056-00 - Flange Bushing-Deck Arms EF081108 - Frame Mounted
$5.82
51 032-5057-00 032-5057-00 - Flange for Lower Deck Arm SF-1622-5
$9.89
52 039-6945-98 039-6945-98 - Deck Idler Assy
$78.08
53 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
54 018-6059-00 018-6059-00 - 5/8-11 X 2-1/2 Hex Bolts
$2.99
55 048-6056-00 048-6056-00 - Toplink/Turnbuckle-Deck Adjust (See Models Used On For Details)
$53.49
56 037-8001-00 037-8001-00 - Double Bearing for Spindle (See Models Used On For Details)
$46.78
57 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
58 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
