2010 ZT - Actuator Bar

2010 ZT - Actuator Bar

The 2010 ZT Actuator Bar is a critical component for adjusting deck height with precision and ease, ensuring optimal cutting performance. At BadBoyMowerParts.com, we offer premium Bad Boy Mower Parts, including actuator bars, brackets, bushings, and mounting hardware for seamless deck adjustments. Our Bad Boy Lawn Mower Parts inventory ensures factory-quality replacements designed for durability and efficiency. Using our Bad Boy Mower Part diagrams, you can easily locate and order the correct actuator bar components for hassle-free installation. Routine maintenance prevents excessive wear, ensures smooth operation, and extends the lifespan of your mower’s deck adjustment system. With access to Bad Boy Parts Online, ordering necessary actuator components is quick and simple. Plus, with Free Shipping On Orders Over $100, maintaining your 2010 ZT Actuator Bar is now more cost-effective. Order today to ensure effortless deck adjustments, improved cutting precision, and a mower that operates at peak performance.

Bad Boy Mower Parts Lookup

2010 ZT - Actuator Bar
  Position Number SKU Product Title Price
1A 088-3500-00 088-3500-00 - Mount Assist Handle
$58.84
1 032-6033-00 032-6033-00 - Brass Bushing - SS-2024-18 Pump Idler Arms
$3.84
2 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
3 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
4 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
5 018-2004-00 018-2004-00 - All Thread-Pump Idler Tensioner
$12.94
6 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
7 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
8 034-5039-00 034-5039-00 - OBSOLETE USE 034-2009-00 (obsolete)
use part #034-2009-00
$18.18
9 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
10 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
11 039-5944-00 039-5944-00 - Pump Idler Bracket
$42.58
12 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
14 031-7000-00 031-7000-00 - Height Indicator Tab and Collar (See Models Used On For Details)
$11.29
15 028-4020-00 028-4020-00 - Actuator Bar (See Models Used On For Detail)
$66.29
16 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zinc
$2.99
17 017-7008-00 017-7008-00 - 1" Pillow Block Bearing (See Models Used On For Details)
$21.29
18 018-5006-00 018-5006-00 - 1/2-13 X 1-1/2 Hex Bolt, Coarse Thread Bolt (For Use On Spindles Please Refer To Item Details)
$2.99
19 047-6050-00 047-6050-00 - CZT/ZT Deck Hanger Chain Assembly (See Models Used On For Details)
$8.74
21 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
22 013-6037-00 013-6037-00 - 1/2-13 Nylon Insert Locknut Zinc
$2.99
23 031-0052-00 031-0052-00 - 2007-2011 ZT/CZT Transaxle Neutral Lever
$11.34
24 041-6400-00 041-6400-00 - Pump Belt (See Models Used On For Details)
$58.84
