2016 ZT Elite - 54" Deck Assembly

2016 ZT Elite - 54" Deck Assembly

Presenting the 2016 ZT Elite 54" Deck Assembly, a high-performance component engineered to deliver exceptional cutting consistency across a 54-inch width. Manufactured with premium materials and state-of-the-art techniques, this deck assembly ensures precise blade engagement and a uniformly clean cut, reducing clippings and enhancing mowing efficiency. Its robust design minimizes operational vibrations and improves stability, making it ideal for both professional landscaping and home maintenance. This assembly seamlessly integrates with the 2016 ZT Elite’s advanced framework, providing reliable durability and optimal performance. Comprehensive installation guidelines and maintenance recommendations are included to guarantee correct alignment and long service life. For accurate schematics, verified components, and expert technical support, please refer to Bad Boy Mower Part diagrams, Bad Boy Mower Parts, Bad Boy Lawn Mower Parts, Bad Boy Parts Online and Free Shipping On Orders Over $100 available on our website. Visit BadBoyMowerParts.com for details and expert advice. Enhance your mower’s efficiency and achieve a flawless cut with this deck assembly.

Bad Boy Mower Parts Lookup

2016 ZT Elite - 54" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6000-00 088-6000-00 - Advanced Chute System for Select 2007-2025 Models with 60", 61", and 72" Decks & 2014-Newer ZT/CZT/Maverick 54" Decks (Will Not Work on 54" Outlaw)
$249.00
1 060-6054-00 060-6054-00 - 2013-2015 CZT, 2014-2016 ZT, 2016-2017 Maverick 54" Deck Shell
$1196.14
2 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
3 018-6059-00 018-6059-00 - 5/8-11 X 2-1/2 Hex Bolts
$2.99
4 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
5 031-6020-00 031-6020-00 - Deck Hanger-Black
$132.68
6 032-5057-00 032-5057-00 - Flange for Lower Deck Arm SF-1622-5
$9.89
7 032-5056-00 032-5056-00 - Flange Bushing-Deck Arms EF081108 - Frame Mounted
$5.82
8 018-1090-00 018-1090-00 - 1/2-13x5 1/2 Hex Bolt
$3.29
9 047-6050-00 047-6050-00 - CZT/ZT Deck Hanger Chain Assembly (See Models Used On For Details)
$8.74
10 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
11 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
12 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
13 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
14 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
15 018-1050-00 018-1050-00 - 1/2 x 2 Carriage Bolt
$2.99
16 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
17 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
18 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
19 041-1560-00 041-1560-00 - Deck Belt (See Models Used On For Details)
$88.80
20 014-5000-00 014-5000-00 - Pulley Cover (See Models Used On For Details)
$15.60
21 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
22 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
23 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
24 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
25 033-7201-25 033-7201-25 - 5 3/4 Idler Pulley
$35.48
26.1 210-6005-98 210-6005-98 - Chute Assembly (See Models Used On For Detail)
$149.99
26 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
27 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
28 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
29 206-6017-00 206-6017-00 - Discharge Chute Hanger-Deck (See Models Used On For Detail)
$39.03
30 018-2007-00 018-2007-00 - 5/16-18 X 1 Hex Bolt Zinc
$2.99
31 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
32 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
33 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
34 039-4864-00 039-4864-00 - Discharge Chute Upper Hanger Plate (See Models Used On For Detail)
$42.52
35 039-4863-00 039-4863-00 - Discharge Lower Bracket Rubber Chute (See Models Used On For Detail)
$32.65
36 013-0004-00 013-0004-00 - Acorn Nut-Pulley Cover
$3.29
37 019-6050-00 019-6050-00 -.360 ID Black Plastic Washer
$2.99
38 048-6060-00 048-6060-00 - CZT/ZT/Maverick/Stand-On Toplink/Turnbuckle (See Models Used On For Details)
$56.77
39 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
40 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
41 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
42 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
43 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
44 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
45 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
46 019-4807-00 019-4807-00 - 5/8" Lockwasher Zinc
$2.99
47 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
48.1 038-0003-00 038-0003-00 - 54" & 2024 Raider 36" Deck Gator Mulching Blade
$22.99
48 038-0001-00 038-0001-00 - 54" & 2024 Raider 36" High Lift Fusion Blade
$22.99
49 033-6003-00 033-6003-00 - 5" Spindle Deck Pulley - DB-80 (without set screw) (See Models Used On For Details)
$42.58
50 037-6015-50 037-6015-50 - Spindle Assembly (See Models Used On For Detail)
$199.99
51A 022-1000-98 022-1000-98 - Deck Wheel Assembly
$25.99
51 022-1000-00 022-1000-00 - Deck Wheel Only
$17.11
52 018-0010-00 018-0010-00 - Deck Wheel Bolt
$6.48
53 019-0007-00 019-0007-00 -.517 Square Hole Round Washer
$2.99
54 039-6945-01 039-6945-01 - Deck Idler Assembly
$40.65
55 018-0015-00 018-0015-00 - 1/2-13 x 2 1/2 Hex Bolt
$2.99
56 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
