2017 Diesel - 1500cc - 61" Deck Assembly

2017 Diesel - 1500cc - 61" Deck Assembly

The 2017 Diesel - 1500cc 61" Deck Assembly is built for precision cutting and durability, making it a crucial component for high-performance mowing. At BadBoyMowerParts.com, we provide premium Bad Boy Mower Parts, including reinforced spindles, cutting blades, deck belts, pulleys, and hardware to maintain peak efficiency. Our Bad Boy Lawn Mower Parts inventory ensures factory-grade replacements designed for longevity and smooth operation. With our Bad Boy Mower Part diagrams, you can quickly locate and order the correct deck components for easy installation. Routine maintenance prevents belt wear, ensures even cutting, and improves overall efficiency. We also offer Bad Boy Parts Online, allowing you to conveniently order all necessary parts. Plus, with Free Shipping On Orders Over $100, maintaining your 2017 Diesel - 1500cc 61" Deck Assembly is now more affordable. Order today to ensure your deck provides high-quality performance and precision cutting for years to come.

Bad Boy Mower Parts Lookup

2017 Diesel - 1500cc - 61" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6000-00 088-6000-00 - Advanced Chute System for Select 2007-2025 Models with 60", 61", and 72" Decks & 2014-Newer ZT/CZT/Maverick 54" Decks (Will Not Work on 54" Outlaw)
$249.00
1B 210-0261-50 210-0261-50 - 2017-2018 61" Mulch Kit w/Blades (obsolete)
use part #210-0361-00
$318.45
1 060-6130-00 060-6130-00 - 2012-2018 61" AOS Diesel (35hp, 1500CC) Deck Shell
$1199.99
2 033-5000-00 033-5000-00 - 5 3/4" Double Bearing Flat Idler Pulley (See Description For Details)
$56.77
3 033-6004-00 033-6004-00 - 6 1/4" Spindle Deck Pulley (without set screw) (See Models Used On For Detail)
$35.48
4 034-2020-00 034-2020-00 - Idler Spring (See Models Used On For Detail)
$17.11
5 039-4863-00 039-4863-00 - Discharge Lower Bracket Rubber Chute (See Models Used On For Detail)
$32.65
6 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
7 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
8 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
9 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
10 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
11 060-6220-00 060-6220-00 - 61 Adjustable Deck Front (Left Gate) (See Models Used On For Detail)
$103.99
12 060-6210-00 060-6210-00 - 61 Adjustable Deck Front (Right Gate) (See Models Used On For Detail)
$103.99
13 206-6017-00 206-6017-00 - Discharge Chute Hanger-Deck (See Models Used On For Detail)
$39.03
14 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
15 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
16 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
17 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
18 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
19 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
20 018-2007-00 018-2007-00 - 5/16-18 X 1 Hex Bolt Zinc
$2.99
21A 022-1000-98 022-1000-98 - Deck Wheel Assembly
$25.99
21 022-1000-00 022-1000-00 - Deck Wheel Only
$17.11
22 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
23 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
24 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
25 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
26 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
27 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
28 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
29 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
30 018-3003-00 018-3003-00 - 1/2 x 1 1/4 Carriage Bolt
$2.99
31 018-1050-00 018-1050-00 - 1/2 x 2 Carriage Bolt
$2.99
32 019-0007-00 019-0007-00 -.517 Square Hole Round Washer
$2.99
33 018-1090-00 018-1090-00 - 1/2-13x5 1/2 Hex Bolt
$3.29
34 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
35 047-4000-00 047-4000-00 - 4 - Link Adjustable Deck Hanger - Pup Models (obsolete)
use part #046-6048-98
$32.09
36 041-0236-00 041-0236-00 - B236 Deck Belt for 61" 35hp Diesel (2012-2020 Only)
$109.99
37 014-6010-00 014-6010-00 - Plastic Pulley Cover (See Models Used On For Details) (obsolete)
use part #014-4000-00
$28.39
38 037-4000-50 037-4000-50 - Outlaw/XP/Diesel Spindle (obsolete)
use part #037-4000-00
$291.91
39.1 038-6081-00 038-6081-00 - 61" Gator Blade for Outlaw
$22.99
39 038-6080-00 038-6080-00 - 61" High Lift Fusion Blade
$22.99
40 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
41 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
42 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
43 039-4864-00 039-4864-00 - Discharge Chute Upper Hanger Plate (See Models Used On For Detail)
$42.52
44 048-6056-00 048-6056-00 - Toplink/Turnbuckle-Deck Adjust (See Models Used On For Details)
$53.49
45 018-6059-00 018-6059-00 - 5/8-11 X 2-1/2 Hex Bolts
$2.99
46 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
47 032-5056-00 032-5056-00 - Flange Bushing-Deck Arms EF081108 - Frame Mounted
$5.82
48 032-5057-00 032-5057-00 - Flange for Lower Deck Arm SF-1622-5
$9.89
49 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
50 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
51 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
52 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
53 018-0010-00 018-0010-00 - Deck Wheel Bolt
$6.48
54 013-0004-00 013-0004-00 - Acorn Nut-Pulley Cover
$3.29
55 019-6050-00 019-6050-00 -.360 ID Black Plastic Washer
$2.99
56 031-6020-00 031-6020-00 - Deck Hanger-Black
$132.68
57 018-0015-00 018-0015-00 - 1/2-13 x 2 1/2 Hex Bolt
$2.99
58 033-7201-25 033-7201-25 - 5 3/4 Idler Pulley
$35.48
59 039-6945-98 039-6945-98 - Deck Idler Assy
$78.08
60 019-5702-00 019-5702-00 - 1/2 SAE Flat Washer GR 8
$2.99
