2017 Diesel - 1500cc - Rear Suspension & Wheel Motors

2017 Diesel - 1500cc - Rear Suspension & Wheel Motors

The 2017 Diesel - 1500cc Rear Suspension & Wheel Motors provide essential support for smooth operation and precise control. At BadBoyMowerParts.com, we stock premium Bad Boy Mower Parts, including wheel motors, rear suspension arms, shock absorbers, and mounting brackets for maximum performance. Our Bad Boy Lawn Mower Parts inventory guarantees factory-grade replacements designed for durability and efficiency. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the correct wheel motor and suspension components for easy installation. Routine maintenance improves mower handling, prevents suspension wear, and extends the lifespan of critical components. We also offer Bad Boy Parts Online, making it easy to order replacement parts when needed. Plus, with Free Shipping On Orders Over $100, maintaining your 2017 Diesel - 1500cc Rear Suspension & Wheel Motors is now more affordable. Order today to ensure smooth rides, precise control, and long-lasting durability.

Bad Boy Mower Parts Lookup

2017 Diesel - 1500cc - Rear Suspension & Wheel Motors
  Position Number SKU Product Title Price
19 018-2051-00 018-2051-00 - 5/8 x 10 Bolt Grade 8
$15.61
20 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
21 019-5702-00 019-5702-00 - 1/2 SAE Flat Washer GR 8
$2.99
22 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
23 018-2030-00 018-2030-00 - 1/2 x 1 Bolt
$2.99
24 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
25 070-8000-00 070-8000-00 - Suspension Kit Wheel Motor (See Models Used On For Details)
$291.91
26 032-8999-00 032-8999-00 - Vibration Mount - Blue Dot Rear Mount for Diesel Models
$64.22
27A 072-1000-98 072-1000-98 - Isolator Clamp Assembly
$28.39
27 072-1000-00 072-1000-00 - Isolator Band Clamp
$7.28
28 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
29 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
30 020-7022-00 020-7022-00 - 1/8 X 2-1/4 Cotter Pins Zinc
$2.99
31 042-7041-00 042-7041-00 - Woodruff Key-Wheel Motor
$14.19
32 013-7050-00 013-7050-00 - 1" Castle Nut for Wheel Motor (obsolete)
use part #013-7055-00
$18.18
33 013-5300-00 013-5300-00 - 1/2-13 Hex Fange Nuts Zinc w/ Serrations
$2.99
34 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
35 013-8047-00 013-8047-00 - 5/16-18 Nylon Insert Locknut - Zinc
$2.99
36 015-4600-00 015-4600-00 - 18cc Parker Wheel Motor-Right (See Models Used On for Detail)
$599.99
37 024-2050-00 024-2050-00 - 45 Degree Wheel Motor Fitting
$17.02
38 092-7000-00 092-7000-00 - 2014-2018 Right Brake Caliper Outlaw XP/Diesel, 2019-2024 Renegade/Rogue Left Brake Caliper w/bracket
$99.32
39 092-5201-00 092-5201-00 - 2007-2008 AOS/Diesel, 2014-2020 Diesel/Outlaw XP, 2019-2025 Renegade/Rogue Brake Disc 8
$119.36
40 018-6049-00 018-6049-00 - 3/8-16 X 1 Hex Bolts Zinc
$2.99
41 015-4601-00 015-4601-00 - 18cc Parker Wheel Motor
$599.99
42 092-7001-00 092-7001-00 - 2014-2018 Left Brake Caliper Outlaw XP/Diesel, 2019-2025 Renegade/Rogue
$99.32
43 051-2080-00 051-2080-00 - 26" Hydraulic Hose Assembly w/Adaptors
$145.95
50 018-7033-00 018-7033-00 - 1/2-20 X 1-1/2 Lug Bolts Zinc
$2.99
51 022-7031-00 022-7031-00 - 26x12.00-12 Orange Wheel and Tire Assembly
$428.99
52 022-7032-00 022-7032-00 - 26x12.00-12 Tire (One Tire Only)
$309.99
53 022-7034-00 022-7034-00 - 12 x 10.5 Wheel - AOS/Diesel Rear
$219.99
54 070-8001-00 070-8001-00 - 72 Suspension Kit Wheel Motor
$265.37
55 018-2080-00 018-2080-00 - 1/2-13 X 1-1/4 Hex Bolt
$2.99
56 051-6085-00 051-6085-00 - 26" Hydro Hose Only
$40.53
57 032-6033-00 032-6033-00 - Brass Bushing - SS-2024-18 Pump Idler Arms
$3.84
