2017 Outlaw XP - Deck Lift Assembly

2017 Outlaw XP - Deck Lift Assembly

The 2017 Outlaw XP Deck Lift Assembly allows for precise height adjustments, ensuring optimal cutting performance. At BadBoyMowerParts.com, we provide premium Bad Boy Mower Parts, including lift arms, hydraulic actuators, deck height controls, and mounting brackets to keep your deck operating smoothly. Our Bad Boy Lawn Mower Parts inventory ensures factory-grade replacements built for durability. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the correct deck lift components for seamless installation. Routine maintenance prevents misalignment, improves cutting accuracy, and prolongs the life of deck components. We also stock Bad Boy Parts Online, making it easy to order replacement parts when needed. Plus, with Free Shipping On Orders Over $100, maintaining your 2017 Outlaw XP Deck Lift Assembly is now more cost-effective. Order today to ensure smooth deck height adjustments and superior mowing precision.

Bad Boy Mower Parts Lookup

2017 Outlaw XP - Deck Lift Assembly
  Position Number SKU Product Title Price
1 040-6080-00 040-6080-00 - Ratchet Fastener - Floorboard
$2.99
2 018-8064-00 018-8064-00 - 1/4-20 X 5/8 BS C/S 18-8 SS
$2.99
3 064-2006-00 064-2006-00 - Floorboard Cable
$15.55
4 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
6 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
7 030-3050-00 030-3050-00 - 10 X 1/2 Pan Phil a T/S Zinc
$2.99
8 029-4010-00 029-4010-00 - Button Bumper
$2.99
9 029-8000-00 029-8000-00 - Front Bumper (See Models Used On For Details)
$31.17
10 030-7039-00 030-7039-00 - 14 X 1-1/2 HWA A T/S Zinc
$2.99
11 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
12 013-9001-00 013-9001-00 - 1/4-20 Hex Flange Nuts Zinc w/Serrations
$2.99
13 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
14 064-5300-00 064-5300-00 - 24" Red Battery Cable
$21.85
16 103-5400-00 103-5400-00 - Black Cable Boot
$4.37
17 103-5300-00 103-5300-00 - Red Lug Boot
$5.82
18 043-8929-00 043-8929-00 - Battery Hold Down Kit
$17.49
19 018-8050-00 018-8050-00 - 1/4-20 X 8 Carriage Bolts Zinc Bolt for Battery Hold Down
$2.99
20 086-0005-00 086-0005-00 - Cable - Starter to Chassis (See Models Used On For Details)
$10.21
21 089-0002-00 089-0002-00 - 2x2 Folding ROPS, Fits 2011 Pup & Lightning, 2010-2018 Outlaw & Outlaw XP
$796.75
22 070-5380-17 070-5380-17 - 2017-2018 Outlaw XP Frame
$1299.99
23 028-6030-00 028-6030-00 - Actuator Bar (Front) (See Models Used On For Detail)
$189.99
24 028-6040-00 028-6040-00 - Actuator Bar (Rear) (See Models Used On For Detail)
$175.99
25 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
26 032-3000-00 032-3000-00 - Actuator Bar Bushing
$2.99
27 018-0008-00 018-0008-00 - 1/2 x 1 1/2 Carriage Bolt
$2.99
28 017-9000-00 017-9000-00 - Two Piece Pillow Block-Male
$10.99
29 017-9050-00 017-9050-00 - Two Piece Pillow Block-Female
$10.99
30A 017-9075-00 017-9075-00 - Pillow Block Assembly (See Models Used On For Details)
$38.51
30 017-9025-00 017-9025-00 - Two Piece Pillow Block-Plate
$32.09
31 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
32 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
33 018-0009-00 018-0009-00 - 3/8 x 1 3/4 Carriage Bolt
$2.99
34 040-4000-00 040-4000-00 - MZ, Diesel & Outlaw Deck Height Lever Pin
$17.16
35 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
36 031-0100-00 031-0100-00 - Deck Lever Lock (See Models Used On For Details)
$18.45
37 026-2100-00 026-2100-00 - Diesel & Outlaw Height Indicator Plate (Outer)
$12.83
38 019-2003-00 019-2003-00 - .390 x .750 x .062 Nylon Washer
$2.99
40 040-5000-00 040-5000-00 - Pull Pin - Foot Assist w/Ring
$21.39
41 030-0010-00 030-0010-00 - 5/16-18 x 1 Thumb Screw Zinc (No Shoulder)
$3.29
42 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
43 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
44 087-5400-00 087-5400-00 - 200lb Gas Spring - 54" Outlaw Deck Damper
$62.40
45 018-2055-00 018-2055-00 - 10mm Damper Stud-XP Linkage
$2.99
46 028-6055-00 028-6055-00 - Linkage Bar Suspension Frame (See Models Used On For Detail)
$28.39
47 039-5944-00 039-5944-00 - Pump Idler Bracket
$42.58
48 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
49 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
50 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
51 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
52 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
53 018-2004-00 018-2004-00 - All Thread-Pump Idler Tensioner
$12.94
54 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
55 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
56 035-7033-00 035-7033-00 - Actuator
$408.75
57 018-0022-00 018-0022-00 - 1/2-13 x 2 Grade 8 Hex Bolt
$2.99
58 019-5702-00 019-5702-00 - 1/2 SAE Flat Washer GR 8
$2.99
59 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknut Zinc Orange Nylon
$2.99
60 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
61 019-8054-00 019-8054-00 -.505 ID X 1 OD X.128 THK Flat Washer Nylon
$2.99
62 018-0050-00 018-0050-00 - 1/2-13 X 3.25 Hex Bolt-
$2.99
63 013-0005-00 013-0005-00 - 1/2" Center Lock Nut
$2.99
64 079-3150-00 079-3150-00 - 2017-2018 Outlaw XP Floor Panel Welded Assembly
$109.99
65 081-2050-00 081-2050-00 - 2016-2018 Outlaw/Outlaw XP Floor Mat
$47.03
66 013-8051-00 013-8051-00 - 1/4-20 Wing Nuts Zinc
$2.99
67 013-8039-00 013-8039-00 - 1/4-20 Hex Nut
$2.99
68 087-6100-00 087-6100-00 - 250lb Gas Spring - 61" Outlaw Deck Damper
$78.01
69 087-7200-00 087-7200-00 - 300 lb Gas Spring -72" Deck Damper
$62.40
70 018-2049-00 018-2049-00 - 13mm Ball Stud for 72" Deck Damper (See Models Used On For Details)
$4.83
