2018 Diesel - 1500cc - 72" Deck Assembly

2018 Diesel - 1500cc - 72" Deck Assembly

For maximum cutting power, the 2018 Diesel - 1500cc 72" Deck Assembly needs quality replacement parts from BadBoyMowerParts.com. We carry a full range of Bad Boy Mower Parts, including blades, belts, spindles, and more. Our Bad Boy Mower Part diagrams make finding and replacing damaged components easy. Using genuine Bad Boy Lawn Mower Parts ensures that your 72" deck continues delivering a clean, even cut. Shopping for Bad Boy Parts Online allows you to find the exact parts required without searching through multiple suppliers. A properly maintained 2018 Diesel - 1500cc 72" Deck Assembly extends the life of your mower and enhances performance. Our experts can assist with installation guidance and troubleshooting tips. Plus, enjoy Free Shipping On Orders Over $100, making deck maintenance more affordable. Keep your 72" deck performing like new with high-quality parts from BadBoyMowerParts.com.

Bad Boy Mower Parts Lookup

2018 Diesel - 1500cc - 72" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6000-00 088-6000-00 - Advanced Chute System for Select 2007-2025 Models with 60", 61", and 72" Decks & 2014-Newer ZT/CZT/Maverick 54" Decks (Will Not Work on 54" Outlaw)
$249.00
1B 210-0272-50 210-0272-50 - 2017-2020 72" Mulch Kit Assembly w/Blades (See Models Used On)
$318.45
1 060-7201-00 060-7201-00 - 72" Deck Shell W/O Front Gates (See Models Used On For Detail)
$1594.22
2 047-5000-00 047-5000-00 - 5 Link Adjustable Deck Hanger (See Models Used On For Details)
$28.39
3 060-7211-00 060-7211-00 - 72" Deck Adjustable Front (Right Gate) (See Models Used On For Detail)
$103.99
4 060-7210-00 060-7210-00 - 72" Deck Adjustable Front (Left Gate) (See Models Used On For Detail)
$103.99
5 018-3003-00 018-3003-00 - 1/2 x 1 1/4 Carriage Bolt
$2.99
6 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
7A 022-1000-98 022-1000-98 - Deck Wheel Assembly
$25.99
7 022-1000-00 022-1000-00 - Deck Wheel Only
$17.11
8 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
9 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
10 033-5000-00 033-5000-00 - 5 3/4" Double Bearing Flat Idler Pulley (See Description For Details)
$56.77
11 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
12 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
13 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
14 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
15 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
16 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
17 034-2020-00 034-2020-00 - Idler Spring (See Models Used On For Detail)
$17.11
18 018-1050-00 018-1050-00 - 1/2 x 2 Carriage Bolt
$2.99
19 019-0007-00 019-0007-00 -.517 Square Hole Round Washer
$2.99
20 018-1090-00 018-1090-00 - 1/2-13x5 1/2 Hex Bolt
$3.29
21 018-0015-00 018-0015-00 - 1/2-13 x 2 1/2 Hex Bolt
$2.99
22 014-7204-00 014-7204-00 - 72" Spindle Cover (See Models Used On For Details)
$42.58
23 041-2525-00 041-2525-00 - B252.50 Deck Belt for 72" AOS Diesel (35hp/1500cc)
$131.30
24 032-5056-00 032-5056-00 - Flange Bushing-Deck Arms EF081108 - Frame Mounted
$5.82
25 032-5057-00 032-5057-00 - Flange for Lower Deck Arm SF-1622-5
$9.89
27 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
28 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
30 033-7201-25 033-7201-25 - 5 3/4 Idler Pulley
$35.48
31 018-0022-00 018-0022-00 - 1/2-13 x 2 Grade 8 Hex Bolt
$2.99
32 018-0010-00 018-0010-00 - Deck Wheel Bolt
$6.48
33 019-6050-00 019-6050-00 -.360 ID Black Plastic Washer
$2.99
34 058-6000-00 058-6000-00 - Black, Round Stick-On Rubber
$2.99
35 013-0004-00 013-0004-00 - Acorn Nut-Pulley Cover
$3.29
36 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
37 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
38 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
39 031-6020-00 031-6020-00 - Deck Hanger-Black
$132.68
40 048-6056-00 048-6056-00 - Toplink/Turnbuckle-Deck Adjust (See Models Used On For Details)
$53.49
41 018-6059-00 018-6059-00 - 5/8-11 X 2-1/2 Hex Bolts
$2.99
42 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
44 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
45 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
46 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
47.1 038-5400-00 038-5400-00 - 72" Gator Mulching Blade
$24.99
47 038-7230-00 038-7230-00 - 72" High Lift Fusion Blade
$24.99
48 033-7203-00 033-7203-00 - 7" Spindle Deck Pulley 72" Decks
$35.48
49 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
50 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
51 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
52 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
53 037-4000-00 037-4000-00 - Commercial Spindle Assembly (See Models Used On For Details)
$291.91
54 206-6017-00 206-6017-00 - Discharge Chute Hanger-Deck (See Models Used On For Detail)
$39.03
55 039-4864-00 039-4864-00 - Discharge Chute Upper Hanger Plate (See Models Used On For Detail)
$42.52
56.1 210-6005-98 210-6005-98 - Chute Assembly (See Models Used On For Detail)
$149.99
56 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
57 039-4863-00 039-4863-00 - Discharge Lower Bracket Rubber Chute (See Models Used On For Detail)
$32.65
58 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
59 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
60 018-2007-00 018-2007-00 - 5/16-18 X 1 Hex Bolt Zinc
$2.99
61 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
62 028-6060-00 028-6060-00 - Panhard Linkage Bar Outlaw and Diesel Decks (See Models Used On For Detail)
$12.77
63 019-8054-00 019-8054-00 -.505 ID X 1 OD X.128 THK Flat Washer Nylon
$2.99
64 013-5300-00 013-5300-00 - 1/2-13 Hex Fange Nuts Zinc w/ Serrations
$2.99
65 019-5702-00 019-5702-00 - 1/2 SAE Flat Washer GR 8
$2.99
66 039-6945-05 039-6945-05 - Deck Idler Assembly
$68.47
