2018 Outlaw & Outlaw Extreme - Actuator Bar and Rear Cover

2018 Outlaw & Outlaw Extreme - Actuator Bar and Rear Cover

The 2018 Outlaw & Outlaw Extreme Actuator Bar and Rear Cover are essential for the structural integrity and functionality of your mower. At BadBoyMowerParts.com, we provide top-quality Bad Boy Mower Parts to keep your mower properly maintained. Whether you need actuator bars, rear covers, or mounting hardware, we have everything required for repairs and upgrades. Using our Bad Boy Mower Part Diagrams, you can easily find the right parts for your model. In addition to actuator bars and covers, we offer a vast selection of Bad Boy Lawn Mower Parts to maintain your mower’s performance. Ordering Bad Boy Parts Online is simple, and with Free Shipping On Orders Over $100, you get the parts you need at no extra cost. Keep your 2018 Outlaw & Outlaw Extreme Actuator Bar and Rear Cover in excellent condition with premium parts from BadBoyMowerParts.com.

Bad Boy Mower Parts Lookup

2018 Outlaw & Outlaw Extreme - Actuator Bar and Rear Cover
  Position Number SKU Product Title Price
1A 088-3500-00 088-3500-00 - Mount Assist Handle
$58.84
1 070-5370-17 070-5370-17 - 2017-2018 Outlaw/Outlaw Extreme Frame
$1299.99
2 028-6030-00 028-6030-00 - Actuator Bar (Front) (See Models Used On For Detail)
$189.99
3 028-6040-00 028-6040-00 - Actuator Bar (Rear) (See Models Used On For Detail)
$175.99
4 028-6050-00 028-6050-00 - Outlaw Deck Linkage Rod
$28.39
5 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
6 032-3000-00 032-3000-00 - Actuator Bar Bushing
$2.99
7 018-0008-00 018-0008-00 - 1/2 x 1 1/2 Carriage Bolt
$2.99
8 017-9000-00 017-9000-00 - Two Piece Pillow Block-Male
$10.99
9 017-9050-00 017-9050-00 - Two Piece Pillow Block-Female
$10.99
10A 017-9075-00 017-9075-00 - Pillow Block Assembly (See Models Used On For Details)
$38.51
10 017-9025-00 017-9025-00 - Two Piece Pillow Block-Plate
$32.09
11 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
12 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
13 018-0009-00 018-0009-00 - 3/8 x 1 3/4 Carriage Bolt
$2.99
14 040-4000-00 040-4000-00 - MZ, Diesel & Outlaw Deck Height Lever Pin
$17.16
15 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
16 031-0100-00 031-0100-00 - Deck Lever Lock (See Models Used On For Details)
$18.45
17 026-2100-00 026-2100-00 - Diesel & Outlaw Height Indicator Plate (Outer)
$12.83
18 019-2003-00 019-2003-00 - .390 x .750 x .062 Nylon Washer
$2.99
19 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
20 087-5400-00 087-5400-00 - 200lb Gas Spring - 54" Outlaw Deck Damper
$62.40
21 018-2050-00 018-2050-00 - 10mm Damper Ball Stud-Steering Damper, Outlaw Deck Damper
$2.99
22 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
23 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
24 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zinc
$2.99
25 018-4702-00 018-4702-00 - 1/4-20 X 1-1/4 Hex Bolt
$2.99
26 029-7037-00 029-7037-00 - 14" Bumper
$42.79
27 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
28 026-2190-00 026-2190-00 - Outlaw/XP Rear Cover 36 Hp Vanguard (See Models Used On For Details)
$209.99
29 067-8085-00 067-8085-00 - Expansion Tank for Outlaw (See Models Used On For Details)
$31.22
30 072-8074-00 072-8074-00 - 5/8" Wire Clamp - Outlaw & Rebel
$4.81
31 051-9000-00 051-9000-00 - 5/8 Braided Hose Priced per Foot
$4.81
32 066-5050-00 066-5050-00 - Hydraulic Tank Cap (See Models Used On For Details)
$15.60
33 019-8040-00 019-8040-00 - 1/4 x 3/4 Carriage Bolt
$2.99
34 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
35 026-0013-00 026-0013-00 - 2010-2018 Outlaw & 2012-2018 Compact Diesel Deck Lift Pedal
$21.28
36 040-5000-00 040-5000-00 - Pull Pin - Foot Assist w/Ring
$21.39
37 014-9000-00 014-9000-00 - Frame Plug 2x2
$2.99
38 030-0010-00 030-0010-00 - 5/16-18 x 1 Thumb Screw Zinc (No Shoulder)
$3.29
39 087-6100-00 087-6100-00 - 250lb Gas Spring - 61" Outlaw Deck Damper
$78.01
40 087-7200-00 087-7200-00 - 300 lb Gas Spring -72" Deck Damper
$62.40
41 018-2049-00 018-2049-00 - 13mm Ball Stud for 72" Deck Damper (See Models Used On For Details)
$4.83
42 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
43 018-2004-00 018-2004-00 - All Thread-Pump Idler Tensioner
$12.94
44 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
46 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
47 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
48 018-0015-00 018-0015-00 - 1/2-13 x 2 1/2 Hex Bolt
$2.99
49 019-5010-00 019-5010-00 -.565x1.25x.095 Washer Brass
$2.99
50 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknut Zinc Orange Nylon
$2.99
51 025-7020-00 025-7020-00 - 5/8 Set Collar w/One Set Screw
$4.37
52 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
53 039-6945-04 039-6945-04 - Pump Idler Assy-Base Outlaw
$53.45
56 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
62 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
64 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
65 039-6945-03 039-6945-03 - Pump Idler Assembly
$53.45
