2018 Walk Behind - Spindle, Idler Arm, Chute Assembly

2018 Walk Behind - Spindle, Idler Arm, Chute Assembly

The 2018 Walk Behind Spindle, Idler Arm, Chute Assembly is a critical part of your mower’s cutting system, ensuring smooth operation of the blades. If any of these parts wear out or become damaged, BadBoyMowerParts.com offers high-quality Bad Boy Mower Parts to get your mower back in working order. Our Bad Boy Mower Part Diagrams make it easy to locate and order the specific spindle, idler arm, or chute you need. We also stock a full selection of Bad Boy Lawn Mower Parts to help maintain your mower’s entire cutting system. Ordering Bad Boy Parts Online ensures quick and hassle-free access to replacement components. Plus, with Free Shipping On Orders Over $100, you save while keeping your mower in peak condition. Restore the functionality of your 2018 Walk Behind Spindle, Idler Arm, Chute Assembly with premium parts from BadBoyMowerParts.com.

Bad Boy Mower Parts Lookup

2018 Walk Behind - Spindle, Idler Arm, Chute Assembly
  Position Number SKU Product Title Price
1.0 037-6015-50 037-6015-50 - Spindle Assembly (See Models Used On For Detail)
$199.99
1 037-6017-50 037-6017-50 - Compact Outlaw / Maverick / Walkbehind / ZT & 2007 Pup Aluminum Spindle Housing (obsolete)
use part #037-6015-50
$199.99
2 037-6023-00 037-6023-00 - Spindle Bearing (See Models Used On For Details) (obsolete)
use part #037-6029-00
$42.58
3 037-6026-00 037-6026-00 - Short Spindle Shaft - No Grooved Shaft
$83.77
4 037-8002-00 037-8002-00 - Dust Cover (Used on 037-4000-00 & 037-6015-50)
$11.76
5 037-8050-00 037-8050-00 - Tube Spacer For Spindle Shaft - Small Spindle
$8.69
6 037-9050-00 037-9050-00 - Collar Spacer - Top of Spindle (See Models Used On For Details)
$7.28
7.0 039-6945-05 039-6945-05 - Deck Idler Assembly
$68.47
7 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
8 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
9 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
10 033-5000-00 033-5000-00 - 5 3/4" Double Bearing Flat Idler Pulley (See Description For Details)
$56.77
11 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
12.0 039-6945-17 039-6945-17 - Deck Idler Assembly
$70.97
13 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
15 033-8050-00 033-8050-00 - 2017-2025 5" Split Idler Pulley-Tensioner Only
$35.48
17.0 210-6005-48 210-6005-48 - Chute Assembly (See Models Used On For Detail)
$169.99
17 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
18 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
19 039-4870-00 039-4870-00 - Discharge Top Bracket, Rubber Chute Assembly (See Models Used On For Details)
$42.52
20 039-4871-00 039-4871-00 - 48/52 Discharge Lower Bracket Rubber Chute
$32.65
21 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
