2019 Compact Outlaw - Lower Frame Assembly

2019 Compact Outlaw - Lower Frame Assembly

The 2019 Compact Outlaw Lower Frame Assembly provides the foundation for structural durability and mower stability. At BadBoyMowerParts.com, we stock top-quality Bad Boy Mower Parts, including frame reinforcements, mounting brackets, and securing bolts to keep your mower sturdy. Our Bad Boy Lawn Mower Parts inventory ensures factory-grade replacements for long-lasting performance. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the correct lower frame components for easy installation. A well-maintained lower frame absorbs vibrations, prevents misalignment, and enhances durability. We offer Bad Boy Parts Online for quick replacements and convenient ordering. Plus, with Free Shipping On Orders Over $100, maintaining your 2019 Compact Outlaw Lower Frame Assembly is now more affordable. Order today for enhanced stability and a longer-lasting mower.

Bad Boy Mower Parts Lookup

2019 Compact Outlaw - Lower Frame Assembly
  Position Number SKU Product Title Price
1A 088-3500-00 088-3500-00 - Mount Assist Handle
$58.84
1 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
2 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
3 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
4.0 017-9076-00 017-9076-00 - Pillow Block Assembly
$23.41
4.1 017-9077-00 017-9077-00 - Pillow Block-Male
$21.28
4.2 017-9078-00 017-9078-00 - Pillow Block-Female (obsolete)
use part #017-9077-00
$21.28
4.3 017-9079-00 017-9079-00 - Pillow Block-Metal Plate
$21.28
5 018-0028-00 018-0028-00 - 3/8x2 1/2" Hex Bolt
$4.39
6 018-1080-00 018-1080-00 - 12-24 x 1/2 HWH Bolt - Safety Switch
$2.99
7 018-2004-50 018-2004-50 - All Thread (See Models Used On For Details)
$12.94
8 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
9 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
10 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
11.0 026-0019-01 026-0019-01 - Foot Pedal Assembly (See Models Used On For Details)
$93.69
11.1 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
11.2 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
11.3 026-0019-00 026-0019-00 - Shallow Foot Pedal (See Models Used On For Detail)
$31.22
11.4 031-0500-00 031-0500-00 - 2017-2024 Deck Pedal Lever (See Models Used On For Detail)
$31.22
12 028-0002-00 028-0002-00 - Actuator Bar-Front (See Models Used On For Detail)
$78.08
13 028-0003-00 028-0003-00 - Actuator Bar-Rear (See Models Used On For Detail)
$78.08
14 031-0060-00 031-0060-00 - 2012-2016 CZT/ZT, 2016-2018 Maverick, 2016-2021 Compact Outlaw Neutral Lever/Rod
$14.19
15 031-0510-00 031-0510-00 - Actuator Linkage (See Models Used On For Details)
$46.84
16 034-2020-00 034-2020-00 - Idler Spring (See Models Used On For Detail)
$17.11
17.1 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
17.2 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
17.3 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
17.4 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
17.5 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
17.6 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
17.7 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
17.8 039-5944-00 039-5944-00 - Pump Idler Bracket
$42.58
17 039-5944-01 039-5944-01 - Pump Idler Bracket Assy (See Models Used On For Details)
$62.46
18 044-2004-00 044-2004-00 - Bow Pin
$2.99
19 044-2008-00 044-2008-00 - Neutral Rod Clip
$2.99
20 070-5500-18 070-5500-18 - 2018-2021 Compact Outlaw Frame
$1099.99
21 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
