2019 Diesel - 1500cc - 61" Deck Assembly

2019 Diesel - 1500cc - 61" Deck Assembly

The 2019 Diesel - 1500cc 61" Deck Assembly delivers precision cutting and durability for large mowing areas. At BadBoyMowerParts.com, we offer high-quality Bad Boy Mower Parts, including deck spindles, cutting blades, idler pulleys, and belt kits to keep your mower deck operating smoothly. Our Bad Boy Lawn Mower Parts inventory ensures factory-grade replacements for long-term performance. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the necessary deck components for easy installation. Proper deck maintenance improves cutting efficiency, reduces vibration, and extends the lifespan of critical mower components. We stock Bad Boy Parts Online for quick replacements and fast shipping. Plus, with Free Shipping On Orders Over $100, keeping your 2019 Diesel - 1500cc 61" Deck Assembly in excellent condition is now more cost-effective. Order today for superior cutting performance and durability.

Bad Boy Mower Parts Lookup

2019 Diesel - 1500cc - 61" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6000-00 088-6000-00 - Advanced Chute System for Select 2007-2025 Models with 60", 61", and 72" Decks & 2014-Newer ZT/CZT/Maverick 54" Decks (Will Not Work on 54" Outlaw)
$249.00
1B 210-0261-50 210-0261-50 - 2017-2018 61" Mulch Kit w/Blades (obsolete)
use part #210-0361-00
$318.45
1 060-6130-00 060-6130-00 - 2012-2018 61" AOS Diesel (35hp, 1500CC) Deck Shell
$1199.99
2 033-5000-00 033-5000-00 - 5 3/4" Double Bearing Flat Idler Pulley (See Description For Details)
$56.77
3 033-6004-00 033-6004-00 - 6 1/4" Spindle Deck Pulley (without set screw) (See Models Used On For Detail)
$35.48
4 034-2020-00 034-2020-00 - Idler Spring (See Models Used On For Detail)
$17.11
5 039-4863-00 039-4863-00 - Discharge Lower Bracket Rubber Chute (See Models Used On For Detail)
$32.65
6 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
7 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
8 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
9 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
10.1 210-6005-98 210-6005-98 - Chute Assembly (See Models Used On For Detail)
$149.99
10 210-6005-00 210-6005-00 - Rubber Discharge Chute (See Models Used On For Detail)
$59.91
11 060-6220-00 060-6220-00 - 61 Adjustable Deck Front (Left Gate) (See Models Used On For Detail)
$103.99
12 060-6210-00 060-6210-00 - 61 Adjustable Deck Front (Right Gate) (See Models Used On For Detail)
$103.99
13 206-6017-00 206-6017-00 - Discharge Chute Hanger-Deck (See Models Used On For Detail)
$39.03
14 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
15 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
16 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
17 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
18 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
19 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
20 018-2007-00 018-2007-00 - 5/16-18 X 1 Hex Bolt Zinc
$2.99
21 022-1000-00 022-1000-00 - Deck Wheel Only
$17.11
22 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
23 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
24 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
25 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
26 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
27 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
28 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
29 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
30 018-3003-00 018-3003-00 - 1/2 x 1 1/4 Carriage Bolt
$2.99
31 018-1050-00 018-1050-00 - 1/2 x 2 Carriage Bolt
$2.99
32 019-0007-00 019-0007-00 -.517 Square Hole Round Washer
$2.99
33 018-1090-00 018-1090-00 - 1/2-13x5 1/2 Hex Bolt
$3.29
34 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
35 047-4000-00 047-4000-00 - 4 - Link Adjustable Deck Hanger - Pup Models (obsolete)
use part #046-6048-98
$32.09
36 041-0236-00 041-0236-00 - B236 Deck Belt for 61" 35hp Diesel (2012-2020 Only)
$109.99
37 037-4000-50 037-4000-50 - Outlaw/XP/Diesel Spindle (obsolete)
use part #037-4000-00
$291.91
38.1 038-6081-00 038-6081-00 - 61" Gator Blade for Outlaw
$22.99
38 038-6080-00 038-6080-00 - 61" High Lift Fusion Blade
$22.99
39 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
40 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
41 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
42 039-4864-00 039-4864-00 - Discharge Chute Upper Hanger Plate (See Models Used On For Detail)
$42.52
43 048-6056-00 048-6056-00 - Toplink/Turnbuckle-Deck Adjust (See Models Used On For Details)
$53.49
44 018-6059-00 018-6059-00 - 5/8-11 X 2-1/2 Hex Bolts
$2.99
45 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
46 032-5056-00 032-5056-00 - Flange Bushing-Deck Arms EF081108 - Frame Mounted
$5.82
47 032-5057-00 032-5057-00 - Flange for Lower Deck Arm SF-1622-5
$9.89
48 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
49 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
50 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
51 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
52 018-0010-00 018-0010-00 - Deck Wheel Bolt
$6.48
53 013-0004-00 013-0004-00 - Acorn Nut-Pulley Cover
$3.29
54 019-6050-00 019-6050-00 -.360 ID Black Plastic Washer
$2.99
55 031-6020-00 031-6020-00 - Deck Hanger-Black
$132.68
56 018-0015-00 018-0015-00 - 1/2-13 x 2 1/2 Hex Bolt
$2.99
57 033-7201-25 033-7201-25 - 5 3/4 Idler Pulley
$35.48
58 039-6945-98 039-6945-98 - Deck Idler Assy
$78.08
59 019-5702-00 019-5702-00 - 1/2 SAE Flat Washer GR 8
$2.99
60 014-5000-00 014-5000-00 - Pulley Cover (See Models Used On For Details)
$15.60
