2019 Diesel - 1500cc - Seat Frame

2019 Diesel - 1500cc - Seat Frame

The 2019 Diesel - 1500cc Seat Frame is a crucial component for operator comfort and mower stability. At BadBoyMowerParts.com, we provide premium Bad Boy Mower Parts, including replacement seat frames, brackets, cushioning, and securing hardware for durability and comfort. Our Bad Boy Lawn Mower Parts inventory ensures factory-grade replacements designed for long-term use. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the necessary seat frame components for seamless installation. A well-maintained seat frame enhances operator comfort, reduces vibration, and improves control during mowing. We stock Bad Boy Parts Online for quick replacements and convenient ordering. Plus, with Free Shipping On Orders Over $100, maintaining your 2019 Diesel - 1500cc Seat Frame is now more affordable. Order today for a more comfortable and efficient mowing experience.

Bad Boy Mower Parts Lookup

2019 Diesel - 1500cc - Seat Frame
  Position Number SKU Product Title Price
1A 085-4052-00 085-4052-00 - Pump/Wheel Motor Hydro Service Pack
$133.30
1 069-8054-00 069-8054-00 - Brake Handle Kit
$119.41
2 062-8013-00 062-8013-00 - Filter Head-Hydraulic Filter
$24.92
3 063-8014-00 063-8014-00 - Hydraulic Filter For Units with Pumps and Wheel Motors
$31.17
4 024-5050-00 024-5050-00 - Filter Head Fitting, 1/2 x 1/2 , 208-108
$8.01
5 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
6 018-8059-00 018-8059-00 - 5/16-18x1-3/4 Hex Bolt
$2.99
7 013-8051-00 013-8051-00 - 1/4-20 Wing Nuts Zinc
$2.99
8 080-7000-00 080-7000-00 - 2007 Diesel Seat Frame
$399.99
10 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
11 019-4008-00 019-4008-00 - 1/4 Lockwasher Zinc
$2.99
12 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
13 025-6041-00 025-6041-00 - Switch Block Plastic
$2.99
14 064-8055-00 064-8055-00 - Short Brake Cable
$51.47
15 018-8056-00 018-8056-00 - 10-24x1/2 Buttonhead SCS 18-8
$2.99
17 066-8050-00 066-8050-00 - Hydraulic Tank Cap w/Dipstick (See Models Used On For Details)
$31.22
18 064-8056-00 064-8056-00 - Long Brake Cable
$53.49
20 051-8064-00 051-8064-00 - 1/2 Clear Braided Hose PRICED/ FOOT
$2.99
21 055-2012-00 055-2012-00 - Universal Throttle/Brake Lever (Knob Not Included)
$25.54
22 077-6000-00 077-6000-00 - Momentary Start Switch Preheat Button for Diesel
$21.39
23 014-6000-00 014-6000-00 - Start Switch Boot - Diesel
$6.59
24 021-8059-00 021-8059-00 - Heat Warning Piezo Buzzer
$36.37
25 013-5019-00 013-5019-00 - 10-24 Nylon Insert Locknut Zinc
$2.99
26 018-5200-00 018-5200-00 - 10-24 X 5/8 BS C/S 18-8 SS
$2.99
27 072-8066-00 072-8066-00 - 1/2" Hose Clamp
$2.99
28 072-8065-00 072-8065-00 - 3/8" Hose Clamp - CTB-16-STFS
$2.99
29 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
30 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
31 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
32 043-8929-00 043-8929-00 - Battery Hold Down Kit
$17.49
33 064-4001-00 064-4001-00 - Black Battery Cable (See Models Used On For Details)
$22.31
34 064-4000-00 064-4000-00 - Red Battery Cable (See Models Used On For Details)
$23.53
35 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
36 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
37 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
39 026-2006-00 026-2006-00 - Seat Plate (See Models Used On For Details)
$99.32
40 071-4055-17 071-4055-17 - Black Grammer Seat w/Seatbelt Use w/seat with ROPS (obsolete)
use part #071-6065-22
$829.99
42 034-1075-00 034-1075-00 - Torsion Spring-Seat Latch
$5.49
44 031-0200-00 031-0200-00 - Seat Latch Lever
$2.99
45 018-0012-00 018-0012-00 - 5/16-18 X 2 HEX C/S (GR.5)
$2.99
46 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
47 018-4702-00 018-4702-00 - 1/4-20 X 1-1/4 Hex Bolt
$2.99
48 014-2009-00 014-2009-00 - Cooler Cover (See Models Used On For Details)
$117.94
49 030-7042-00 030-7042-00 - 5/16 x 3/4 Hex Washer Type F Thread Cutting Screw
$2.99
50 014-8047-00 014-8047-00 - Rubber Cap Cover
$2.99
51 034-8045-00 034-8045-00 - Seat Spring
$20.49
52 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
53 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
54 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
55 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
56 013-5300-00 013-5300-00 - 1/2-13 Hex Fange Nuts Zinc w/ Serrations
$2.99
57 070-2005-00 070-2005-00 - Pigtail for a Grammer Seat (See Models Used On For Details)
$42.58
58 064-8081-00 064-8081-00 - Seat Cable
$15.60
59 018-4007-00 018-4007-00 - 1/4-20 X 1 Hex Bolts Zinc
$2.99
60 013-8073-00 013-8073-00 - 1/4-20 Nylon Insert Locknut Zinc
$2.99
62 103-5300-00 103-5300-00 - Red Lug Boot
$5.82
63 103-5400-00 103-5400-00 - Black Cable Boot
$4.37
64 071-4051-00 071-4051-00 - Left Armrest Kit-Grammer Seat
$116.70
65 071-4052-00 071-4052-00 - Right Armrest Kit-Grammer Seat
$96.29
67 071-4054-00 071-4054-00 - Seat Rails for Grammer Seat(2)
$109.46
68 071-4060-00 071-4060-00 - Black/Orange Grammer Seat
$1060.21
69 071-4053-00 071-4053-00 - Seat Belt Kit-Grammer Seats (See Models Used On For Details)
$109.99
70 071-4059-00 071-4059-00 - Grey Handle for Grammer Seat
$60.98
71 071-4071-00 071-4071-00 - Black Seat Cushion for the 071-4055-17
$150.99
72 071-4072-00 071-4072-00 - Black Backrest Cushion for the 071-4055-17
$139.99
73 014-4050-00 014-4050-00 - Black Plastic Cover Kit forGrammer Seat (Both Sides)
$35.30
