Position Number |
SKU |
Product Title |
Price |
|
|
|
1A |
034-9000-00 |
034-9000-00 - SPRING (See Models Used On For Details) |
$15.55
|
|
|
|
1 |
072-2003-00 |
072-2003-00 - 1 1/8" Hose Clamp |
$5.82
|
|
|
|
2A |
055-8018-75 |
055-8018-75 - Diesel Thottle Cable ONLY |
$32.09
|
|
|
|
2 |
072-2002-00 |
072-2002-00 - 2-1/2 Hose Clamp |
$11.34
|
|
|
|
8 |
013-0054-00 |
013-0054-00 - 1/4-20 Cage Nut |
$2.99
|
|
|
|
12 |
013-5201-00 |
013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations |
$2.99
|
|
|
|
13 |
013-5202-00 |
013-5202-00 - 3/8 Nylock Flange Nut |
$2.99
|
|
|
|
15 |
013-6014-00 |
013-6014-00 - 3/8-16 Hex Nuts Zinc |
$2.99
|
|
|
|
18 |
013-8043-00 |
013-8043-00 - 5/16-18 Hex Nut |
$2.99
|
|
|
|
20 |
013-8049-00 |
013-8049-00 - 5/16-18 Nylon Flange Nut |
$2.99
|
|
|
|
21 |
013-8050-00 |
013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon |
$2.99
|
|
|
|
24 |
013-9002-00 |
013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations |
$2.99
|
|
|
|
27 |
014-1053-00 |
014-1053-00 - Plastic Mesh Hose Loom |
$9.89
|
|
|
|
30 |
014-5060-00 |
014-5060-00 - 2019-2021 Renegade Pump Cover-RH |
$21.39
|
|
|
|
31 |
014-5061-00 |
014-5061-00 - 2019-2021 Renegade Pump Cover-LH |
$32.09
|
|
|
|
36 |
015-0010-50 |
015-0010-50 - 35/28 CAT Muffler Gasket |
$17.02
|
|
|
|
38.5 |
015-0096-08 |
015-0096-08 - Starter for the Perkins 1100cc Diesel |
$699.99
|
|
|
|
38.16 |
015-0096-09 |
015-0096-09 - Alternator for the Perkins 1100cc Diesel |
$829.99
|
|
|
|
38.17 |
041-0010-00 |
041-0010-00 - Caterpillar/Perkins Fan Belt |
$85.17
|
|
|
|
38.23 |
015-0096-06 |
015-0096-06 - Oil Pressure Sensor for the Perkins 1100cc Diesel |
$125.99
|
|
|
|
38.24 |
015-0096-07 |
015-0096-07 - Coolant Temperature Sensor for the Perkins 1100cc Diesel |
$212.99
|
|
|
|
38.26 |
015-0096-05 |
015-0096-05 - Fuel Shutdown Solenoid for the Perkins 1100cc Diesel |
$1499.99
|
|
|
|
38.27 |
015-0096-04 |
015-0096-04 - Barometric Pressure Sensor Bracket for Perkins 1100cc Diesel |
$32.09
|
|
|
|
38.28 |
015-0096-03 |
015-0096-03 - Barometric Pressure Sensor for the Perkins 1100cc Diesel |
$219.99
|
|
|
|
38.29 |
013-4000-00 |
013-4000-00 - Pressure Sensor Nut |
$8.79
|
|
|
|
38.30 |
015-0096-01 |
015-0096-01 - Crank Sensor w/Nut for the Perkins 1100cc Diesel |
$158.99
|
|
|
|
38.31 |
015-0096-02 |
015-0096-02 - Crank Sensor bracket for the Perkins 1100cc Diesel |
$53.49
|
|
|
|
38.32.1 |
015-0070-00 |
015-0070-00 - Thermostat for Diesel |
$85.59
|
|
|
|
38.32.2 |
015-0071-00 |
015-0071-00 - Gasket for CAT Thermostat |
$21.39
|
|
|
|
40 |
015-1019-00 |
015-1019-00 - 2019-2024 Renegade Diesel Muffler Catalytic# MUF1693 |
$175.99
|
|
|
|
45 |
017-3001-00 |
017-3001-00 - 2019-2024 Renegade Diesel Stub Shaft Double V |
$150.99
|
|
|
|
47 |
018-0007-00 |
018-0007-00 - 7/16-20 x 3 Hex C/S GR 8 |
$2.99
|
|
|
|
48 |
018-0015-00 |
018-0015-00 - 1/2-13 x 2 1/2 Hex Bolt |
$2.99
|
|
|
|
49 |
018-0016-00 |
018-0016-00 - 5/16-18 x 1 Button Head Torx Drive Bolt |
$2.99
|
|
|
|
50 |
018-0024-00 |
018-0024-00 - M6-1.0 X 16MM HEX BOLT |
$2.99
|
|
|
|
61 |
018-2000-00 |
018-2000-00 - M6x1.0x20MM 8.8 Hex Bolts Zinc |
$2.99
|
|
|
|
62 |
018-2001-00 |
018-2001-00 - M8 X 1.25 X 25MM Class 10.9 He x Bolts Zinc |
$2.99
|
|
|
|
63 |
018-2006-00 |
018-2006-00 - 5/16-18 X 1-1/4 Hex Bolt |
$2.99
|
|
|
|
64 |
018-2007-00 |
018-2007-00 - 5/16-18 X 1 Hex Bolt Zinc |
$2.99
|
|
|
|
78 |
018-4706-00 |
018-4706-00 - 3/8 x 1 1/2 Carriage Bolt |
$2.99
|
|
|
|
84 |
018-5320-00 |
018-5320-00 - M8 x 1.25 x 30MM Hex Head Bolt |
$2.99
|
|
|
|
85 |
018-5321-00 |
018-5321-00 - M8 x 1.25 x 20MM Hex Head Bolt |
$2.99
|
|
|
|
87 |
018-6014-00 |
018-6014-00 - 1/4-20 x 1" BS C/S 18-8 SS |
$5.82
|
|
|
|
88 |
018-6022-00 |
018-6022-00 - 12mm Bolt - Diesel |
$2.99
|
|
|
|
90 |
018-6049-00 |
018-6049-00 - 3/8-16 X 1 Hex Bolts Zinc |
$2.99
|
|
|
|
94 |
018-7060-00 |
018-7060-00 - 3/8-16 x 5 1/2 Hex Bolt - |
$2.99
|
|
|
|
99 |
018-8065-00 |
018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc |
$2.99
|
|
|
|
100 |
018-8066-00 |
018-8066-00 - 5/16 x 7/8 Carriage Bolt |
$2.99
|
|
|
|
103 |
019-4008-00 |
019-4008-00 - 1/4 Lockwasher Zinc |
$2.99
|
|
|
|
104 |
019-5007-00 |
019-5007-00 - 1/2 Lockwasher Zinc |
$2.99
|
|
|
|
105 |
019-5029-00 |
019-5029-00 - 3/8 USS Flat Washer Zinc |
$2.99
|
|
|
|
106 |
019-5037-00 |
019-5037-00 - 3/8" Lockwasher Zinc |
$2.99
|
|
|
|
110 |
019-7040-00 |
019-7040-00 - 1/4 USS Flat Washer Zinc |
$2.99
|
|
|
|
112 |
019-8044-00 |
019-8044-00 - 5/16 USS Flat Washer Zinc |
$2.99
|
|
|
|
113 |
019-8051-00 |
019-8051-00 - 5/16" Lockwasher Zinc |
$2.99
|
|
|
|
114 |
019-8053-00 |
019-8053-00 - 7/16 Lockwasher zinc |
$2.99
|
|
|
|
116 |
020-2000-00 |
020-2000-00 - 3/32 X 1/2 Cotter Pins Zinc |
$2.99
|
|
|
|
122 |
024-0070-00 |
024-0070-00 - 8mm x 1/8 mpt Adaptor - All Di esel Models |
$50.28
|
|
|
|
123 |
024-2052-00 |
024-2052-00 - 2019-2022 Renegade Horizontal Pump Fitting 90 Degree # 6801-10-8 |
$12.48
|
|
|
|
125 |
024-5002-00 |
024-5002-00 - 90 Degree Fitting, 1/2 x 3/4, 986741 |
$17.63
|
|
|
|
126 |
024-5206-00 |
024-5206-00 - 90 Degree Fitting, 3/8 x 9/16, 4601-6-6 |
$12.42
|
|
|
|
132 |
025-2001-00 |
025-2001-00 - ACS Spacer 3/4x3/8x1/4 |
$15.60
|
|
|
|
152 |
030-0075-00 |
030-0075-00 - 5/16-24 X 3/8 Set Screw |
$2.99
|
|
|
|
164 |
032-4050-00 |
032-4050-00 - Rubber Compression Mount Side Motor Mount-Diesel |
$76.53
|
|
|
|
165 |
032-4051-00 |
032-4051-00 - Snubbing Washer for Rubber Compression Mount |
$17.02
|
|
|
|
170 |
033-1875-00 |
033-1875-00 - Renegade Horizontal Pump Idler Pulley |
$10.99
|
|
|
|
171 |
033-5011-00 |
033-5011-00 - Cast Pump Pulley - 17mm AOS/Diesel Models |
$35.48
|
|
|
|
176 |
039-1010-00 |
039-1010-00 - Diesel Throttle Bracket 4 Tier |
$5.49
|
|
|
|
177 |
039-1015-00 |
039-1015-00 - Radiator Hose Clamp Bracket |
$2.99
|
|
|
|
178 |
039-1025-00 |
039-1025-00 - 2019 Diesel Muffler Bracket |
$13.90
|
|
|
|
181 |
039-5900-00 |
039-5900-00 - 2019 Renegade Pump Belt Tensioner Only (No Pulley) |
$54.64
|
|
|
|
183 |
041-8000-00 |
041-8000-00 - Pump Belt (See Models Used On For Detail) |
$80.24
|
|
|
|
184 |
042-5012-00 |
042-5012-00 - 5MM X 1.25 Square Key (obsolete)
use part #042-5013-00 |
$2.99
|
|
|
|
186 |
044-2006-00 |
044-2006-00 - 1/4 X 5/8 Clevis Pin |
$2.99
|
|
|
|
191.0 |
050-3001-00 |
050-3001-00 - Rogue/Renegade Left Pump 16cc Hydro-Gear# PR-2KCC-GB1C-XXXX (See Models Used On For Details) |
$699.99
|
|
|
|
191.2 |
015-9999-00 |
015-9999-00 - Hydro Fan - Fits Hydraulic Pumps |
$28.88
|
|
|
|
191.3 |
014-5600-00 |
014-5600-00 - Fan Guard 6.5" - Fits Wheel Motor Pumps |
$39.81
|
|
|
|
192.0 |
050-3003-00 |
050-3003-00 - 2019-2024 Renegade Right Pump 16cc Hydro-Gear # PR-2HCC-GA1C-XXXX |
$649.99
|
|
|
|
193 |
051-3003-00 |
051-3003-00 - Diesel Radiator Hose-Upper |
$49.63
|
|
|
|
194 |
051-3004-00 |
051-3004-00 - 2019 Diesel Air intake Hose |
$14.97
|
|
|
|
195 |
051-3005-00 |
051-3005-00 - Diesel Radiator Hose-Lower |
$44.93
|
|
|
|
196 |
051-6007-00 |
051-6007-00 - 2019-& Up Renegade Hydro Hose |
$54.64
|
|
|
|
202 |
051-8076-00 |
051-8076-00 - 3/8 Fuel Line-Priced per Foot |
$6.59
|
|
|
|
205 |
057-5915-00 |
057-5915-00 - Pump Plate Clip Nut Holder |
$17.11
|
|
|
|
206 |
057-5919-00 |
057-5919-00 - Renegade Clutch Bracket |
$28.39
|
|
|
|
210 |
063-2010-00 |
063-2010-00 - Caterpillar Oil Filter |
$34.23
|
|
|
|
228 |
070-2000-00 |
070-2000-00 - Clutch Pigtail |
$21.24
|
|
|
|
229 |
070-5040-00 |
070-5040-00 - Diesel/Vanguard PTO Clutch |
$399.00
|
|
|
|
233 |
072-5000-00 |
072-5000-00 - Diesel Hydraulic Hose Clamp |
$7.28
|
|
|
|
238 |
072-8090-00 |
072-8090-00 - Diesel Clamp - 1 3/4 Vinyl |
$3.63
|
|
|
|
250 |
086-0003-00 |
086-0003-00 - Alternator to Starter Cable |
$7.79
|
|
|
|
252 |
086-7003-00 |
086-7003-00 - Temperature Sender- 2012 Gauge |
$31.17
|
|
|
|
253 |
086-7004-00 |
086-7004-00 - Oil Pressure Sender- For 2012 and Newer Units |
$119.99
|
|
|
|
256 |
088-1010-50 |
088-1010-50 - Enginaire Canister VLR-Complete Diesel Models |
$229.99
|
|
|
|
266 |
201-8030-00 |
201-8030-00 - 2019 Diesel Motor Mount Weldment |
$11.76
|
|
