2019 Revolt - Spindle, Turnbuckle, Idler & Chute

2019 Revolt - Spindle, Turnbuckle, Idler & Chute

The 2019 Revolt Spindle, Turnbuckle, Idler & Chute system is critical for smooth blade operation and efficient grass dispersal. At BadBoyMowerParts.com, we offer top-quality Bad Boy Mower Parts, including spindles, idler pulleys, turnbuckles, and durable discharge chutes to optimize mowing performance. Our Bad Boy Lawn Mower Parts inventory ensures factory-grade replacements designed for precision. Using our Bad Boy Mower Part diagrams, you can quickly locate and order the correct spindle, turnbuckle, idler, and chute components for easy installation. Routine maintenance prevents belt slippage, enhances blade rotation, and ensures even grass dispersal. We provide Bad Boy Parts Online for quick replacements and convenient ordering. Plus, with Free Shipping On Orders Over $100, maintaining your 2019 Revolt Spindle, Turnbuckle, Idler & Chute is now more budget-friendly. Order today for superior cutting efficiency and long-lasting durability.

Bad Boy Mower Parts Lookup

2019 Revolt - Spindle, Turnbuckle, Idler & Chute
  Position Number SKU Product Title Price
1.0 037-6015-50 037-6015-50 - Spindle Assembly (See Models Used On For Detail)
$199.99
1 037-6017-50 037-6017-50 - Compact Outlaw / Maverick / Walkbehind / ZT & 2007 Pup Aluminum Spindle Housing (obsolete)
use part #037-6015-50
$199.99
2 037-6023-00 037-6023-00 - Spindle Bearing (See Models Used On For Details) (obsolete)
use part #037-6029-00
$42.58
3 037-6026-00 037-6026-00 - Short Spindle Shaft - No Grooved Shaft
$83.77
4 037-8002-00 037-8002-00 - Dust Cover (Used on 037-4000-00 & 037-6015-50)
$11.76
5 037-8050-00 037-8050-00 - Tube Spacer For Spindle Shaft - Small Spindle
$8.69
6 037-9050-00 037-9050-00 - Collar Spacer - Top of Spindle (See Models Used On For Details)
$7.28
7.0 039-6945-19 039-6945-19 - Revolt Deck Idler Assembly
$70.97
7 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
8 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
9 025-5337-00 025-5337-00 -.502x.750x1.125 Length Spacer
$4.39
10 033-8050-00 033-8050-00 - 2017-2025 5" Split Idler Pulley-Tensioner Only
$35.48
11 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
12 013-0007-00 013-0007-00 - 11/16-12 Hex Nut Toplink
$2.99
13.0 048-7000-00 048-7000-00 - Toplink-Outlaw Decks (See Models Used On For Details) (obsolete)
use part #048-8000-00
$80.24
13 013-0008-00 013-0008-00 - 11/16-12 Lefthand Hex Nut-Topl ink
$2.99
14 024-6034-00 024-6034-00 - 1/4 Drive-in Grease Fitting
$2.99
15 032-2000-00 032-2000-00 - Toplink Bushing (See Models Used On For Detail)
$4.37
16 032-2001-00 032-2001-00 - Toplink Sleeve (See Models Used On For Detail)
$4.37
17 048-7020-00 048-7020-00 - Outlaw Toplink Body (See Models Used On For Details)
$28.32
18 048-7021-00 048-7021-00 - Outlaw Toplink RH End (See Models Used On For Details) (obsolete)
use part #048-8000-00
$80.24
19 048-7022-00 048-7022-00 - Outlaw Toplink LH End (See Models Used On For Details) (obsolete)
use part #048-8000-00
$80.24
20.0 210-7000-98 210-7000-98 - Chute Assembly (See Models Used On for Detail)
$159.22
20 039-4894-00 039-4894-00 - Lower Chute Bracket (See Models Used On For Details)
$43.72
21 210-6025-00 210-6025-00 - Belted Chute with Logo 2019-& Up Rebel, Revolt, Renegade & Rogue
$62.40
22 039-4893-00 039-4893-00 - Upper Chute Bracket (See Models Used On For Details)
$46.84
23 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
24 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
25 018-8066-00 018-8066-00 - 5/16 x 7/8 Carriage Bolt
$2.99
26 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
27 206-6018-00 206-6018-00 - Chute Hanger 2019-2025 Rebel, Revolt, Renegade & Rogue
$9.67
