2019 ZT Elite - Steering Arm - Detail

2019 ZT Elite - Steering Arm - Detail

The 2019 ZT Elite Steering Arm - Detail system ensures smooth and responsive handling for optimal control. At BadBoyMowerParts.com, we offer high-quality Bad Boy Mower Parts, including steering arms, bushings, mounting hardware, and control levers for precise maneuverability. Our Bad Boy Lawn Mower Parts inventory guarantees factory-grade replacements designed for long-lasting reliability. Using our Bad Boy Mower Part diagrams, you can quickly identify and order the correct steering arm components for easy installation. Routine maintenance of the steering system enhances mower handling, prevents component wear, and ensures safe operation. We also offer Bad Boy Parts Online, making it simple to order essential replacements anytime. Plus, with Free Shipping On Orders Over $100, maintaining your 2019 ZT Elite Steering Arm - Detail is now more budget-friendly. Order today for superior control, stability, and long-term reliability.

Bad Boy Mower Parts Lookup

2019 ZT Elite - Steering Arm - Detail
  Position Number SKU Product Title Price
1A 031-9060-18 031-9060-18 - Adjustable Steering Arm Kit
$178.99
19 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
20 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
21 018-2050-00 018-2050-00 - 10mm Damper Ball Stud-Steering Damper, Outlaw Deck Damper
$2.99
22 019-8027-00 019-8027-00 -.515 ID Plastic Shoulder Washer
$2.99
23 019-8054-00 019-8054-00 -.505 ID X 1 OD X.128 THK Flat Washer Nylon
$2.99
24 031-0017-98 031-0017-98 - 2017-2023 Left Drive Lever Housing (See Models Used On For Details)
$31.23
25.0 031-0017-01 031-0017-01 - Left Steering Arm Assembly (See Models Used On for Details)
$145.99
25.1 018-2020-00 018-2020-00 - 5/16-18 x 1/2 HWH Bolt - Steering Arms
$2.99
25.2 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
25.3 031-8850-02 031-8850-02 - Steering Arm Left - Tubing (See Models Used On For Details)
$85.12
25.4 031-9020-70 031-9020-70 - Left Steering Arm Black Elbow (See Models Used On For Details)
$85.17
25.5 069-4007-00 069-4007-00 - Rubber Steering Arm USE 069-4010-00 (obsolete)
use part #069-4010-00
$8.12
26 034-8025-00 034-8025-00 - Drive Lever Housing Spring
$4.07
27 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
28.0 035-5450-00 035-5450-00 - Right Steering Push Rod (See Models Used On For Details)
$33.95
29 048-3000-00 048-3000-00 - Spherical Rod End (See Models Used On For Details)
$14.19
30 099-2009-00 099-2009-00 - Quick Release Ball Joint (See Models Used On For Details)
$9.89
36 031-0018-98 031-0018-98 - 2017-2023 Right Drive Lever Housing (See Models Used On For Details)
$23.42
37.0 031-0018-01 031-0018-01 - Right Steering Arm Assembly (See Models Used On for Details)
$145.99
37.3 031-8851-02 031-8851-02 - Steering Arm Right - 5" Tubing (See Models Used On For Details)
$85.12
37.4 031-9025-70 031-9025-70 - Right Steering Arm Black Elbow
$85.17
40.0 035-5451-00 035-5451-00 - Left Steering Push Rod (See Models Used On For Details)
$42.58
