2020 Diesel - 1500cc - Seat Frame

2020 Diesel - 1500cc - Seat Frame

The 2020 Diesel - 1500cc Seat Frame is designed to provide comfort and support during long hours of mowing. At BadBoyMowerParts.com, we offer a wide selection of Bad Boy Mower Parts, including seat frames and related components for this model. Whether you need a replacement frame, cushion, or any other seat-related parts, we have everything you need to ensure comfort on the job. Our detailed Bad Boy Mower Part diagrams help you easily identify and order the right parts. Shop for Bad Boy Lawn Mower Parts with confidence knowing that all our parts are durable and built to last. When you shop Bad Boy Parts Online, you’ll enjoy the convenience of fast, easy ordering and Free Shipping On Orders Over $100. Enhance your mower's comfort and performance by ordering your 2020 Diesel - 1500cc Seat Frame from BadBoyMowerParts.com.

Bad Boy Mower Parts Lookup

2020 Diesel - 1500cc - Seat Frame
  Position Number SKU Product Title Price
1A 085-4052-00 085-4052-00 - Pump/Wheel Motor Hydro Service Pack
$133.30
1 069-8054-00 069-8054-00 - Brake Handle Kit
$119.41
2 062-8013-00 062-8013-00 - Filter Head-Hydraulic Filter
$24.92
3 063-8014-00 063-8014-00 - Hydraulic Filter For Units with Pumps and Wheel Motors
$31.17
4 024-5050-00 024-5050-00 - Filter Head Fitting, 1/2 x 1/2 , 208-108
$8.01
5 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
6 018-8059-00 018-8059-00 - 5/16-18x1-3/4 Hex Bolt
$2.99
7 013-8051-00 013-8051-00 - 1/4-20 Wing Nuts Zinc
$2.99
8 080-7000-00 080-7000-00 - 2007 Diesel Seat Frame
$399.99
10 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
11 019-4008-00 019-4008-00 - 1/4 Lockwasher Zinc
$2.99
12 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
13 025-6041-00 025-6041-00 - Switch Block Plastic
$2.99
14 064-8055-00 064-8055-00 - Short Brake Cable
$51.47
15 018-8056-00 018-8056-00 - 10-24x1/2 Buttonhead SCS 18-8
$2.99
17 066-8050-00 066-8050-00 - Hydraulic Tank Cap w/Dipstick (See Models Used On For Details)
$31.22
18 064-8056-00 064-8056-00 - Long Brake Cable
$53.49
19 051-8063-00 051-8063-00 - 3/8 Clear Hose PRICED PER FOOT
$2.99
20 051-8064-00 051-8064-00 - 1/2 Clear Braided Hose PRICED/ FOOT
$2.99
21 055-2012-00 055-2012-00 - Universal Throttle/Brake Lever (Knob Not Included)
$25.54
22 077-6000-00 077-6000-00 - Momentary Start Switch Preheat Button for Diesel
$21.39
23 014-6000-00 014-6000-00 - Start Switch Boot - Diesel
$6.59
24 021-8059-00 021-8059-00 - Heat Warning Piezo Buzzer
$36.37
25 013-5019-00 013-5019-00 - 10-24 Nylon Insert Locknut Zinc
$2.99
26 018-5200-00 018-5200-00 - 10-24 X 5/8 BS C/S 18-8 SS
$2.99
27 072-8066-00 072-8066-00 - 1/2" Hose Clamp
$2.99
28 072-8065-00 072-8065-00 - 3/8" Hose Clamp - CTB-16-STFS
$2.99
29 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
30 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
31 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
32 043-8929-00 043-8929-00 - Battery Hold Down Kit
$17.49
33 064-4001-00 064-4001-00 - Black Battery Cable (See Models Used On For Details)
$22.31
34 064-4000-00 064-4000-00 - Red Battery Cable (See Models Used On For Details)
$23.53
35 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
36 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
37 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
39 026-2006-00 026-2006-00 - Seat Plate (See Models Used On For Details)
$99.32
40 071-4055-17 071-4055-17 - Black Grammer Seat w/Seatbelt Use w/seat with ROPS (obsolete)
use part #071-6065-22
$829.99
42 034-1075-00 034-1075-00 - Torsion Spring-Seat Latch
$5.49
44 031-0200-00 031-0200-00 - Seat Latch Lever
$2.99
45 018-0012-00 018-0012-00 - 5/16-18 X 2 HEX C/S (GR.5)
$2.99
46 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
47 018-4702-00 018-4702-00 - 1/4-20 X 1-1/4 Hex Bolt
$2.99
48 014-2009-00 014-2009-00 - Cooler Cover (See Models Used On For Details)
$117.94
49 030-7042-00 030-7042-00 - 5/16 x 3/4 Hex Washer Type F Thread Cutting Screw
$2.99
50 014-8047-00 014-8047-00 - Rubber Cap Cover
$2.99
51 034-8045-00 034-8045-00 - Seat Spring
$20.49
52 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
53 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
54 018-6012-00 018-6012-00 - 3/8 x 1 1/2 Bolt
$2.99
55 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
56 013-5300-00 013-5300-00 - 1/2-13 Hex Fange Nuts Zinc w/ Serrations
$2.99
57 070-2005-00 070-2005-00 - Pigtail for a Grammer Seat (See Models Used On For Details)
$42.58
58 064-8081-00 064-8081-00 - Seat Cable
$15.60
59 018-4007-00 018-4007-00 - 1/4-20 X 1 Hex Bolts Zinc
$2.99
60 013-8073-00 013-8073-00 - 1/4-20 Nylon Insert Locknut Zinc
$2.99
62 103-5300-00 103-5300-00 - Red Lug Boot
$5.82
63 103-5400-00 103-5400-00 - Black Cable Boot
$4.37
64 071-4051-00 071-4051-00 - Left Armrest Kit-Grammer Seat
$116.70
65 071-4052-00 071-4052-00 - Right Armrest Kit-Grammer Seat
$96.29
67 071-4054-00 071-4054-00 - Seat Rails for Grammer Seat(2)
$109.46
68 071-4060-00 071-4060-00 - Black/Orange Grammer Seat
$1060.21
69 071-4053-00 071-4053-00 - Seat Belt Kit-Grammer Seats (See Models Used On For Details)
$109.99
70 071-4059-00 071-4059-00 - Grey Handle for Grammer Seat
$60.98
71 071-4071-00 071-4071-00 - Black Seat Cushion for the 071-4055-17
$150.99
72 071-4072-00 071-4072-00 - Black Backrest Cushion for the 071-4055-17
$139.99
73 014-4050-00 014-4050-00 - Black Plastic Cover Kit forGrammer Seat (Both Sides)
$35.30
