2020 Maverick - Idler Arm & Foot Pedal

2020 Maverick - Idler Arm & Foot Pedal

The 2020 Maverick Idler Arm & Foot Pedal are essential for smooth maneuverability and operation. If you need to replace or repair these components, BadBoyMowerParts.com offers the Bad Boy Mower Parts you need. From idler arms to foot pedal assemblies, we carry a wide range of Bad Boy Lawn Mower Parts to keep your 2020 Maverick performing at its best. Use our Bad Boy Mower Part diagrams to ensure you’re ordering the right parts for a perfect fit. Plus, enjoy the convenience of Free Shipping On Orders Over $100, making it easier and more affordable to maintain your mower. Shop for all your parts online with Bad Boy Parts Online.

Bad Boy Mower Parts Lookup

2020 Maverick - Idler Arm & Foot Pedal
  Position Number SKU Product Title Price
1.0 017-9076-00 017-9076-00 - Pillow Block Assembly
$23.41
1 017-9077-00 017-9077-00 - Pillow Block-Male
$21.28
2 017-9078-00 017-9078-00 - Pillow Block-Female (obsolete)
use part #017-9077-00
$21.28
3 017-9079-00 017-9079-00 - Pillow Block-Metal Plate
$21.28
4.0 026-0019-01 026-0019-01 - Foot Pedal Assembly (See Models Used On For Details)
$93.69
4 031-0500-00 031-0500-00 - 2017-2024 Deck Pedal Lever (See Models Used On For Detail)
$31.22
5 026-0019-00 026-0019-00 - Shallow Foot Pedal (See Models Used On For Detail)
$31.22
6 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
7 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
8.0 039-5944-05 039-5944-05 - Pump Idler Bracket Assy-EZT
$70.97
8 013-5300-00 013-5300-00 - 1/2-13 Hex Fange Nuts Zinc w/ Serrations
$2.99
9 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
10 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
11 018-0015-00 018-0015-00 - 1/2-13 x 2 1/2 Hex Bolt
$2.99
12 018-6016-00 018-6016-00 - 5/8 x 5 1/2 Bolt
$2.99
13 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
14 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
15 025-5203-00 025-5203-00 - Spacer 3/4" OD x 1/2" ID x 0.75"
$3.29
16 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
17 033-8000-00 033-8000-00 - 5 3/4 Pump Idler Pulley-5/8 Bore 2016-2025 Maverick
$35.48
18 039-6945-00 039-6945-00 - Idler Arm Bracket
$40.53
