2020 Rebel - Deck Control Assembly

2020 Rebel - Deck Control Assembly

The 2020 Rebel Deck Control Assembly is vital for adjusting the height and position of your mower’s cutting deck. A malfunctioning deck control can make mowing difficult and inefficient, so it's crucial to replace any damaged components with the correct Bad Boy Mower Parts. For clear identification, use the Bad Boy Mower Part diagrams, which show each part of the deck control assembly. Whether you need a replacement cable, pulley, or lever, Bad Boy Parts Online provides all the necessary components to restore your mower’s functionality. These Bad Boy Lawn Mower Parts are designed for long-term durability, ensuring your mower continues to perform optimally. With Free Shipping On Orders Over $100, you can save on shipping costs while purchasing quality parts for your mower. Visit BadBoyMowerParts.com to find the 2020 Rebel Deck Control Assembly and any other parts needed to keep your mower in top working condition.

Bad Boy Mower Parts Lookup

2020 Rebel - Deck Control Assembly
  Position Number SKU Product Title Price
9 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
15 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
17 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
39 017-9075-00 017-9075-00 - Pillow Block Assembly (See Models Used On For Details)
$38.51
40 018-0004-00 018-0004-00 - 1/2-13 X 7" Hex Bolt -
$5.49
56 018-2049-00 018-2049-00 - 13mm Ball Stud for 72" Deck Damper (See Models Used On For Details)
$4.83
57 018-2050-00 018-2050-00 - 10mm Damper Ball Stud-Steering Damper, Outlaw Deck Damper
$2.99
58 018-2055-00 018-2055-00 - 10mm Damper Stud-XP Linkage
$2.99
59 018-3001-00 018-3001-00 - 5/8 x 5/8 Shoulder Bolt
$15.61
60 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknut Zinc Orange Nylon
$2.99
63 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
65 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
77 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
92 025-0033-00 025-0033-00 - Deck Stop Spacer (See Models Used On For Details)
$8.79
94 026-0026-00 026-0026-00 - Knurled Foot Pedal
$39.03
102 028-0026-00 028-0026-00 - Front Actuator Bar 2019-2022 Rebel, Renegade & Rogue
$119.41
103 028-0027-00 028-0027-00 - Rear Actuator Bar 2019-2022 Rebel, Renegade & Rogue
$82.38
106 028-6075-00 028-6075-00 - Actuator Linkage-Right 2019-2021 Rebel, Renegade & Rogue
$53.49
107 028-6076-00 028-6076-00 - Actuator Linkage-Left 2019-2021 Rebel, Renegade & Rogue
$12.94
116 031-0120-00 031-0120-00 -2019-2021 Rebel/Rogue/Renegade Foot Lift Upright Lever (obsolete)
use part #031-0003-00
$17.11
122 032-5052-00 032-5052-00 - Bronze Bushing
$4.81
137 045-6044-00 045-6044-00 - Foot Pedal Knob 1/2-13
$12.48
179 087-5400-00 087-5400-00 - 200lb Gas Spring - 54" Outlaw Deck Damper
$62.40
180 087-6100-00 087-6100-00 - 250lb Gas Spring - 61" Outlaw Deck Damper
$78.01
181 087-7200-00 087-7200-00 - 300 lb Gas Spring -72" Deck Damper
$62.40
