2020 Rebel - Seat Detail

2020 Rebel - Seat Detail

The 2020 Rebel Seat Detail is an often-overlooked component that plays a significant role in comfort during long mowing sessions. A damaged or worn-out seat can make mowing uncomfortable, but luckily, replacing the seat or related components is easy with Bad Boy Mower Parts. The Bad Boy Mower Part diagrams provide a detailed look at the seat assembly, including the seat pan, cushions, and mounting hardware. Whether you need a full replacement or just a cushion, Bad Boy Parts Online has everything you need. All Bad Boy Lawn Mower Parts are designed to be durable and comfortable, ensuring your seat stands up to the test of time. When shopping at BadBoyMowerParts.com, you also get the benefit of Free Shipping On Orders Over $100, which helps reduce your overall costs. Visit BadBoyMowerParts.com for the best options on the 2020 Rebel Seat Detail and more.

Bad Boy Mower Parts Lookup

2020 Rebel - Seat Detail
  Position Number SKU Product Title Price
14 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
17 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
19 013-9005-00 013-9005-00 - 5/16-18 Nylock Jam Nut
$2.99
42 018-0024-00 018-0024-00 - M6-1.0 X 16MM HEX BOLT
$2.99
62 018-4703-00 018-4703-00 - 5/16-18 X 1-1/4 Carriage Bolt
$2.99
73 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
79 019-6042-00 019-6042-00 -.360 ID Plastic Washer
$2.99
95 026-2019-00 026-2019-00 - Seat Plate 2019-2024 Rebel, Renegade & Rogue
$99.32
105 028-0090-00 028-0090-00 - Seat Latch Rod Assembly (See Models Used On For Detail)
$38.97
124 034-1025-00 034-1025-00 - Brake Spring (See Models Used On For Detail)
$12.48
156.0 067-0020-19 067-0020-19 - EPA Cannister Assembly Rebel/Renegade Gas/Rogue (See Models Used On For Details)
$47.62
156.1 067-0020-00 067-0020-00 - Carbon Canister
$62.40
156.2 072-8073-00 072-8073-00 - 3/16" Vinyl Hose Clamp
$2.99
156.3 072-8070-00 072-8070-00 - Tank Hose Clamp 3/16 (See Models Used On For Detail)
$2.99
156.4 051-2025-66 051-2025-66 - 66" 3/16 Vinyl EPA Line
$13.26
156.5 051-8072-38 051-8072-38 - 38" 1/4 Vinyl Tubing
$28.39
156.6 073-8068-00 073-8068-00 - Fuel Line T
$9.70
166.0 071-5060-00 071-5060-00 - 2011-2018 Outlaw Models & 2019-2020 Rebel Seat
$699.99
166.1 071-5015-00 071-5015-00 - Seat Rails
$93.69
166.2 071-5061-00 071-5061-00 - Pair of Armrest for the 071-5060-00 2016 - 2018 Outlaw, Outlaw/XP, 2019-2021 Rebel
$119.99
166.3 071-5063-00 071-5063-00 - Seat Cover for 071-5060-00 for the 2016 - 2018 Outlaw, Outlaw/XP, 2019-2021 Rebel
$134.99
166.4 071-5064-00 071-5064-00 - Back Cover for 071-5060-00 Used on 2016- 2018 Outlaw, Outlaw/XP, 2019 - 2021 Rebel
$160.49
166.5 071-8061-00 071-8061-00 - Seat Switch (See Models Used On For Detail)
$19.14
166 071-5060-18 071-5060-18 - 2019 - 2021 Rebel Seat w/ Seatbelt
$599.99
167.0 071-5065-00 071-5065-00 - 2019 - 2021 Seat with Seatbelt with ROPS (See Models Used On For Details)
$899.99
167.1 071-5065-02 071-5065-02 - Seatbelt for 2019-2021 Rebel & Renegade
$132.68
167.2 071-5065-03 071-5065-03 - Backrest Cushion fits the 071-5065-00 for 2019-2021 Rebel & Renegade
$180.99
167.3 071-5065-04 071-5065-04 - Seat Cushion fits the 071-5065-00 for 2019-2021 Rebel & Renegade
$191.99
167.4 071-5065-05 071-5065-05 - Seat Rail Kit fits the 071-5065-00 (See Models Used On For Details)
$85.17
167.5 071-5065-06 071-5065-06 - Armrest Kit fits the 071-5065-00 for 2019-2021 Rebel & Renegade
$139.99
167.6 071-5065-07 071-5065-07 - Seat Switch fits the 071-5065-00 (See Models Used On For Details)
$42.58
