2020 Renegade - Diesel - Control Arms

2020 Renegade - Diesel - Control Arms

The 2020 Renegade - Diesel Control Arms play a vital role in handling and maneuverability, ensuring smooth operation across rough terrain. Over time, control arms can wear out, affecting steering performance and stability. When replacement is necessary, trust Bad Boy Mower Parts for high-quality components that restore precision. At BadBoyMowerParts.com, we stock a full range of Bad Boy Lawn Mower Parts, including durable control arms designed for heavy-duty use. To find the exact fit for your mower, our Bad Boy Mower Part diagrams help simplify the selection and installation process. Ordering through Bad Boy Parts Online ensures you receive genuine parts built for longevity and peak performance. Plus, enjoy Free Shipping On Orders Over $100, making repairs more cost-effective. Keep your 2020 Renegade - Diesel handling like new with premium replacement control arms and other essential mower components from our trusted inventory.

Bad Boy Mower Parts Lookup

2020 Renegade - Diesel - Control Arms
  Position Number SKU Product Title Price
3 013-0021-00 013-0021-00 - Extruded Nut 3/8"-16 3/4"
$4.39
16 013-8043-00 013-8043-00 - 5/16-18 Hex Nut
$2.99
17 013-8047-00 013-8047-00 - 5/16-18 Nylon Insert Locknut - Zinc
$2.99
19 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
22 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
27 014-2052-00 014-2052-00 - 2 x .25 Rubber Grommet (See Models Used On For Details)
$12.83
32 014-9003-00 014-9003-00 - 1 1/2 x 3 Frame Plug
$2.99
60 018-1080-00 018-1080-00 - 12-24 x 1/2 HWH Bolt - Safety Switch
$2.99
63 018-2006-00 018-2006-00 - 5/16-18 X 1-1/4 Hex Bolt
$2.99
69 018-2020-18 018-2020-18 - 5/16-18 x 1 3/8" Button Head Torx Drive
$2.99
80 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
106 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
113 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
146 028-0051-00 028-0051-00 - Steering Actuator Rod 2019-2025 Rebel, Renegade & Rogue
$23.41
158.0 031-0030-19 031-0030-19 - R Series Right Arm Rod Assembly (See Models Used On For Details)
$85.17
158.1 031-0030-00 031-0030-00 - Bad Boy Max Right Drive Arm Actuator (See Models Used On For Detail)
$46.78
158.2 031-0014-00 031-0014-00 - Drive Arm Pivot 2019-2022 Rebel, Renegade & Rogue
$24.92
158.4 019-8054-00 019-8054-00 -.505 ID X 1 OD X.128 THK Flat Washer Nylon
$2.99
158.5 013-0017-00 013-0017-00 - 3/8-16 Half Jam Nut
$2.99
158.6 018-0063-00 018-0063-00 - 3/8-16 X 1 Socket Set Screw Cup Point
$2.99
158.7 018-0050-00 018-0050-00 - 1/2-13 X 3.25 Hex Bolt-
$2.99
159.0 031-0031-19 031-0031-19 - R Series Left Arm Rod Assembly, 2019-2023 Rebel/Renegade/Rogue
$85.17
159.1 031-0031-00 031-0031-00 - Left Drive Arm Actuator for Rebel, Renegade & Rogue
$46.78
162.0 031-9005-70 031-9005-70 - Left Hand Adjustable Steering Arm Kit 2019-2022 Rebel, Renegade & Rogue
$132.68
162.1 031-9006-00 031-9006-00 - Steering Arm Tube
$42.79
162.2 031-9005-00 031-9005-00 - Upper/Lower Steering Arm Casting 2019-2023 Rebel, Renegade & Rogue
$28.39
162.3 045-5000-00 045-5000-00 - Knob - Adjustable Steering Arm
$5.49
162.4 069-4010-00 069-4010-00 - Black Steering Grip
$8.12
162.6 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
163.0 031-9055-70 031-9055-70 - Right Hand Adjustable Steering Arm Kit 2019-2022 Rebel, Renegade & Rogue
$115.31
165 032-0002-00 032-0002-00 - Snap-In Bushing 2019-2022 Rebel, Renegade & Rogue
$15.55
174.0 035-0005-00 035-0005-00 - Push Rod Assembly 2019-2025 Renegade
$46.84
174.1 035-0005-01 035-0005-01 - 2019-2022 Renegade Horizontal Push Rod (obsolete)
use part #035-0005-00
$46.84
174.3 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
174.4 048-3003-00 048-3003-00 - Spherical Rod End - RH Thread (See Models Used On For Details)
$21.28
174.5 048-3002-00 048-3002-00 - Spherical Rod End - LH Thread (See Models Used On For Details)
$32.09
174.6 013-6050-00 013-6050-00 - 5/16 LH Nut For Push Rods
$4.39
174.7 013-6049-00 013-6049-00 - 5/16 RH Nut For Push Rods
$4.39
180 039-2160-00 039-2160-00 - Arm Switch Bracket (See Models Used On For More Detail)
$13.90
205 057-5800-00 057-5800-00 - Speed Limiting Knob 3/8-16X 3"
$6.41
231 070-5374-19 070-5374-19 - Horizontal Diesel Renegade Frame
$1299.99
244 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
257 087-0002-00 087-0002-00 - Steering Rod Damper With Spherical Rod Ends For Renegade/Rogue (See Models Used On For Details)
$62.46
