2020 Revolt - Engine - Kawasaki FX850V

2020 Revolt - Engine - Kawasaki FX850V

For the 2020 Revolt Engine - Kawasaki FX850V, BadBoyMowerParts.com provides a full range of engine parts to help maintain optimal performance. From replacing air filters and spark plugs to upgrading carburetors and fuel systems, our extensive selection of Bad Boy Mower Parts ensures that your engine keeps running smoothly. The Kawasaki FX850V is known for its high-performance capabilities, and our Bad Boy Lawn Mower Parts are designed to support and enhance that performance. Using our Bad Boy Mower Part diagrams, you can easily find the correct parts for your engine. We also offer Free Shipping On Orders Over $100, making it even more convenient and cost-effective to maintain your 2020 Revolt. Shop Bad Boy Parts Online today for high-quality parts that will keep your engine running at its best, ensuring a long life and superior performance on your mower.

Bad Boy Mower Parts Lookup

2020 Revolt - Engine - Kawasaki FX850V
  Position Number SKU Product Title Price
1A 063-2000-02 063-2000-02 - Kawasaki FX850 Engine Service Kit
$124.74
1 013-0075-00 013-0075-00 - M8 - 1.25 Zinc Nut
$3.29
2A 055-8021-75 055-8021-75 - 52" Throttle Cable ONLY (See Models Used On - Engine Diagrams To Verify This Fits your Mower)
$28.88
2B 054-8017-00 054-8017-00 - 62" Choke Cable (See Models Used On - Engine Diagrams To Verify This Fits your Mower)
$25.80
2 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
3 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
4 013-9005-00 013-9005-00 - 5/16-18 Nylock Jam Nut
$2.99
5.1 015-0031-00 015-0031-00 - Kaw Engine FX-850V-AS15R
$3395.00
5.2 015-8001-00 015-8001-00 - Spark Plug-Kawasaki (NGK or Equivalent) - Not For FX781, FX820 or FX1000
$8.79
5.3 063-8017-00 063-8017-00 - Oil Filter for Kawasaki Fits FX850 and FX1000 and Liquid Cooled /31 KAW
$28.88
5.4 063-8020-00 063-8020-00 - Inner Canister Air Filter - Fits All except 23 Briggs/Diesel
$32.65
5.5 063-8019-00 063-8019-00 - Outer Air Filter, Fits all except 23 Briggs/Diesel
$35.84
5.6 063-6000-00 063-6000-00 - Universal Inline Fuel Filter
$14.19
6 015-1022-00 015-1022-00 - Revolt Kawasaki FX850 Exhaust
$163.90
7 015-2709-00 015-2709-00 - Exhaust Gasket (See Models Used On For Detail)
$8.01
8 018-1075-00 018-1075-00 - 3/8 x 1 1/8 Engine Mounting Bolt
$2.99
9 018-5006-00 018-5006-00 - 1/2-13 X 1-1/2 Hex Bolt, Coarse Thread Bolt (For Use On Spindles Please Refer To Item Details)
$2.99
10 018-5300-00 018-5300-00 - 7/16-20 X 2-1/2 Hex Bolt
$2.99
11 018-5321-00 018-5321-00 - M8 x 1.25 x 20MM Hex Head Bolt
$2.99
12 018-5350-00 018-5350-00 - 5/16-18 X 5-1/2 Hex Bolt
$2.99
13 018-7016-00 018-7016-00 - 1/2-13 X 3 Hex Bolts Zinc
$2.99
14 019-6029-00 019-6029-00 - 1.140x1.750x.132 Flat Washer
$2.99
15 019-8051-00 019-8051-00 - 5/16" Lockwasher Zinc
$2.99
16 019-8053-00 019-8053-00 - 7/16 Lockwasher zinc
$2.99
17 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
18 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
19 033-5035-00 033-5035-00 - 4 3/4 Motor Pulley - Extended Shaft (See Models Used On For Details)
$42.58
20 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
21 033-7201-00 033-7201-00 - 5 3/4 Idler Pulley
$35.48
22 039-0089-00 039-0089-00 - Idler Pulley Bracket Weldment 2019-2022 Revolt
$28.39
23 039-0119-00 039-0119-00 - Clutch Stop Bracket 2019-2022 Revolt
$10.21
24 041-8052-00 041-8052-00 - 2019-2025 Revolt Drive Belt, 48", 54", 61" Decks Only
$80.24
25 042-5020-00 042-5020-00 - 1/4 X 2 Square Key Stock
$2.99
26 051-5407-00 051-5407-00 - 12" Kawasaki Oil Drain FX850 / FX1000/ FX730
$42.58
27 064-0030-00 064-0030-00 - 24 inch Black Battery Cable
$18.72
28 070-1000-00 070-1000-00 - PTO Clutch (See Models Used On For Details)
$279.99
29 070-2000-00 070-2000-00 - Clutch Pigtail
$21.24
30 070-5220-19 070-5220-19 - 2019-2022 Revolt Frame
$1149.99
31 086-9002-19 086-9002-19 - Wiring Harness Adaptor-All Kawasaki FX (See Models Used On For Details)
$20.29
