2020 Revolt - Transaxle Assembly

2020 Revolt - Transaxle Assembly

The 2020 Revolt Transaxle Assembly plays a crucial role in the power transmission system of your Bad Boy Mower, providing the necessary torque to drive the wheels efficiently. If you need to replace or repair this essential part, we’ve got you covered with a range of options. Our Bad Boy Mower Part diagrams make it easy to locate the exact transaxle assembly you need for your mower. Browse through our extensive catalog of Bad Boy Mower Parts, and you'll find everything from small components to large assemblies. Whether you're maintaining your current machine or upgrading parts, we offer the best selection of Bad Boy Lawn Mower Parts. With Free Shipping On Orders Over $100, it’s easier than ever to shop Bad Boy Parts Online. Let BadBoyMowerParts.com be your go-to resource for keeping your mower’s transaxle assembly in optimal working condition.

Bad Boy Mower Parts Lookup

2020 Revolt - Transaxle Assembly
  Position Number SKU Product Title Price
1A 085-4051-00 085-4051-00 - Hydro Service Package for 2020 and Older Models with Expansion Tanks - ZT2800, ZT3100, ZT3200, and all ZT3400
$104.74
1 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
2 013-3000-00 013-3000-00 - Acorn Lug Nut
$3.29
3 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
4 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
5 013-7021-00 013-7021-00 - 5/8-11 Nylon Insert Locknut Zinc
$2.99
6 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
7 013-8073-00 013-8073-00 - 1/4-20 Nylon Insert Locknut Zinc
$2.99
8 013-9001-00 013-9001-00 - 1/4-20 Hex Flange Nuts Zinc w/Serrations
$2.99
9 014-9003-00 014-9003-00 - 1 1/2 x 3 Frame Plug
$2.99
10 018-0011-00 018-0011-00 - 1/4-20 x 2 Hex Bolt
$2.99
11 018-0056-00 018-0056-00 - 5/16x6 Carriage Bolt
$2.99
12 018-2004-50 018-2004-50 - All Thread (See Models Used On For Details)
$12.94
13 018-3000-00 018-3000-00 - 3/8-16 X 2 Hex Bolts Zinc
$2.99
14 018-4007-00 018-4007-00 - 1/4-20 X 1 Hex Bolts Zinc
$2.99
15 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknut Zinc Orange Nylon
$2.99
16 018-6049-00 018-6049-00 - 3/8-16 X 1 Hex Bolts Zinc
$2.99
17 018-5344-00 018-5344-00 - 5/16 x 2 1/2 Bolt
$2.99
19 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
20 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
21 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
22 019-7040-00 019-7040-00 - 1/4 USS Flat Washer Zinc
$2.99
23 019-8044-00 019-8044-00 - 5/16 USS Flat Washer Zinc
$2.99
24 022-4040-00 022-4040-00 - 23x9-12 Reaper Turf (See Models Used On for Details)
$329.99
25 022-4041-00 022-4041-00 - 36" Revolt Reaper Wheel Assy. 21x7x10
$195.99
26 024-1200-00 024-1200-00 - Fitting, 3/8 x 3/8 45 Degree, 4603-6-6 (See Models Used On For Details)
$19.93
27 025-0070-00 025-0070-00 - Transaxle Spacer
$6.41
28 025-2004-00 025-2004-00 - ACS Spacer 3/4x3/8x1/2
$15.60
29 025-7020-00 025-7020-00 - 5/8 Set Collar w/One Set Screw
$4.37
31 028-0071-00 028-0071-00 - Neutral Release Rod 2019-2024 Revolt
$29.95
32 034-1025-00 034-1025-00 - Brake Spring (See Models Used On For Detail)
$12.48
33 034-2020-00 034-2020-00 - Idler Spring (See Models Used On For Detail)
$17.11
34 035-0006-19 035-0006-19 - Push-Rod Assembly
$46.84
35 039-0151-00 039-0151-00 - 2020 36" Brake Bracket--Black
$14.11
36 039-0212-00 039-0212-00 - Brake Bracket (See Models Used On For Details)
$25.54
37 039-6945-09 039-6945-09 - Pump Idler Assembly
$58.84
38 041-8000-00 041-8000-00 - Pump Belt (See Models Used On For Detail)
$80.24
39 041-8052-00 041-8052-00 - 2019-2025 Revolt Drive Belt, 48", 54", 61" Decks Only
$80.24
40 044-2004-00 044-2004-00 - Bow Pin
$2.99
41 050-2096-00 050-2096-00 - 2017-2021 Left ZT Elite Transaxle & 36" 2020-2021 Revolt (obsolete)
use part #050-2096-01
$729.99
43 050-6000-00 050-6000-00 - ZT3400 Transaxle - Left (obsolete)
use part #050-6000-02
$819.99
44 050-6001-00 050-6001-00 - ZT3400 Transaxle - Right (obsolete)
use part #050-6001-02
$819.99
45 064-3000-00 064-3000-00 - 44" Brake Cable
$31.22
46 070-5220-19 070-5220-19 - 2019-2022 Revolt Frame
$1149.99
47 070-5221-20 070-5221-20 - 2020 36" Revolt Frame
$1299.99
