2020 Rogue - Deck Height Control

2020 Rogue - Deck Height Control

Achieve precise cutting with the 2020 Rogue Deck Height Control, an essential feature for maintaining your lawn’s appearance. At BadBoyMowerParts.com, we provide top-quality Bad Boy Mower Parts to ensure your deck height control operates smoothly. Whether you need a complete system replacement or individual components, we have the Bad Boy Lawn Mower Parts necessary for your 2020 Rogue. Our detailed Bad Boy Mower Part diagrams allow you to identify the right parts quickly and easily. Shop Bad Boy Parts Online to find everything you need for your mower’s deck height control system, and enjoy Free Shipping On Orders Over $100. By keeping your deck height control in optimal condition, you ensure your mower delivers even, consistent cuts across your lawn, helping you achieve professional-grade results.

Bad Boy Mower Parts Lookup

2020 Rogue - Deck Height Control
  Position Number SKU Product Title Price
9 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
18 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
21 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
44 017-9075-00 017-9075-00 - Pillow Block Assembly (See Models Used On For Details)
$38.51
65 018-2049-00 018-2049-00 - 13mm Ball Stud for 72" Deck Damper (See Models Used On For Details)
$4.83
66 018-2050-00 018-2050-00 - 10mm Damper Ball Stud-Steering Damper, Outlaw Deck Damper
$2.99
67 018-2055-00 018-2055-00 - 10mm Damper Stud-XP Linkage
$2.99
68 018-3001-00 018-3001-00 - 5/8 x 5/8 Shoulder Bolt
$15.61
69 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknut Zinc Orange Nylon
$2.99
72 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
74 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
93 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
118 026-0026-00 026-0026-00 - Knurled Foot Pedal
$39.03
125 028-0026-00 028-0026-00 - Front Actuator Bar 2019-2022 Rebel, Renegade & Rogue
$119.41
126 028-0027-00 028-0027-00 - Rear Actuator Bar 2019-2022 Rebel, Renegade & Rogue
$82.38
129 028-6075-00 028-6075-00 - Actuator Linkage-Right 2019-2021 Rebel, Renegade & Rogue
$53.49
130 028-6076-00 028-6076-00 - Actuator Linkage-Left 2019-2021 Rebel, Renegade & Rogue
$12.94
139 031-0003-00 031-0003-00 - Foot Lift Upright Lever
$17.11
145 032-5052-00 032-5052-00 - Bronze Bushing
$4.81
164 045-6044-00 045-6044-00 - Foot Pedal Knob 1/2-13
$12.48
221 087-5400-00 087-5400-00 - 200lb Gas Spring - 54" Outlaw Deck Damper
$62.40
222 087-6100-00 087-6100-00 - 250lb Gas Spring - 61" Outlaw Deck Damper
$78.01
223 087-7200-00 087-7200-00 - 300 lb Gas Spring -72" Deck Damper
$62.40
