Click Image to Change Diagram
The 2020 Walk Behind Front End plays a crucial role in the stability and steering of your mower. If you're looking to maintain or replace components for this area, BadBoyMowerParts.com is your one-stop shop for high-quality Bad Boy Mower Parts. Whether you're replacing a wheel or upgrading the front-end components, we provide a comprehensive range of parts that will fit your 2020 Walk Behind perfectly. With Bad Boy Mower Part diagrams available, it’s easier than ever to identify the parts you need to keep your mower in optimal condition. Our selection of Bad Boy Lawn Mower Parts ensures that your mower operates smoothly. When you shop Bad Boy Parts Online, you’ll find a wide array of front-end components and more, plus the added benefit of Free Shipping On Orders Over $100. Keep your 2020 Walk Behind Front End performing like new with durable and affordable parts.
![]() |
Position Number | SKU | Product Title | Price | ||
---|---|---|---|---|---|
1 | 010-1050-00 | 010-1050-00 - Front Fork Caster Bearing (See Models Used On For Details) |
$18.39
|
||
15 | 013-8050-00 | 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon |
$2.99
|
||
17 | 013-9004-00 | 013-9004-00 - 1" Nylock Nut 1/2 Nut - Fine Thread |
$3.62
|
||
18 | 014-2025-00 | 014-2025-00 - Caster Bearing Cover (See Models Used On For Details) |
$2.99
|
||
26 | 018-0005-00 | 018-0005-00 - 1-14 X 5 BOLT GR 8 Zinc |
$7.69
|
||
30 | 018-0035-00 | 018-0035-00 - 1/2-13 x 7 1/2 Hex Bolt |
$4.83
|
||
72.1 | 022-2013-00 | 022-2013-00 - Front Wheel Only (See Models Used On For Detail) |
$42.79
|
||
72.2 | 022-8049-00 | 022-8049-00 - 11x6.00-5 Front Assembly (One Tire and Rim Assy) |
$99.39
|
||
72.3 | 022-7009-00 | 022-7009-00 - 1 3/8" Small Bore Bearing-Hoosier |
$13.36
|
||
73 | 023-0002-00 | 023-0002-00 - 2017-2025 Walkbehind & MZ Front Fork |
$31.23
|
||
75 | 025-0003-00 | 025-0003-00 - Front Bearing Spacer |
$14.04
|
||
76 | 025-0008-00 | 025-0008-00 - Front Wheel Spanner - MZ |
$15.60
|
||
137 | 058-1000-00 | 058-1000-00 - MZ Bar Stop |
$6.41
|
