2020 Walk Behind - Upper Frame

2020 Walk Behind - Upper Frame

The 2020 Walk Behind Upper Frame is a key component that supports your mower’s structure and overall integrity. At BadBoyMowerParts.com, you can find premium Bad Boy Mower Parts to replace or maintain your upper frame. Whether you need a complete replacement or individual components such as brackets or reinforcement parts, we have everything you need. Our Bad Boy Mower Part diagrams make identifying the correct parts for your mower simple. With a wide range of Bad Boy Lawn Mower Parts available, your mower will stay in top condition and continue to perform at its best. Ordering Bad Boy Parts Online is easy and convenient, and don’t forget the added benefit of Free Shipping On Orders Over $100, ensuring you get your parts delivered at no extra cost. Ensure the durability of your mower by upgrading or replacing your 2020 Walk Behind Upper Frame with high-quality parts today.

Bad Boy Mower Parts Lookup

2020 Walk Behind - Upper Frame
  Position Number SKU Product Title Price
2 013-0004-00 013-0004-00 - Acorn Nut-Pulley Cover
$3.29
12 013-7018-00 013-7018-00 - 1/2-13 Hex Nuts Zinc
$2.99
16 013-8073-00 013-8073-00 - 1/4-20 Nylon Insert Locknut Zinc
$2.99
19 014-3580-00 014-3580-00 - Walk Behind Bolt On Fan Cover
$10.99
20 014-3590-18 014-3590-18 - 2018-2022 Walk Behind Cover
$32.09
22 014-9002-00 014-9002-00 - 1 1/2 X 2 Plug For .120 Tubing
$2.99
35 018-2004-50 018-2004-50 - All Thread (See Models Used On For Details)
$12.94
41 018-4010-00 018-4010-00 - 1/2-13 Nylon Insert Jam Locknut Zinc Orange Nylon
$2.99
64 019-6050-00 019-6050-00 -.360 ID Black Plastic Washer
$2.99
66 019-8040-00 019-8040-00 - 1/4 x 3/4 Carriage Bolt
$2.99
78 025-0031-00 025-0031-00 - Deck Hanger Insert (Walk Behind)
$10.21
103 034-2009-00 034-2009-00 - Deck/Pump Idler Spring (See Models Used On For Detail)
$18.18
113.1 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
113.2 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
113.3 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
113.4 018-6036-00 018-6036-00 - 1/2-13 X 2-3/4 Bolt Zinc
$2.99
113.5 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
113.6 025-7036-00 025-7036-00 - 1/2 Set Collar w/set screw
$4.60
113.7 033-6001-00 033-6001-00 - 4 3/4 Idler Pulley (See Models Used On For Details)
$31.22
113.8 039-5944-00 039-5944-00 - Pump Idler Bracket
$42.58
114.0 039-5944-01 039-5944-01 - Pump Idler Bracket Assy (See Models Used On For Details)
$62.46
117 040-6060-00 040-6060-00 - Seat Latch Pin (See Models Used On For Details)
$2.99
133.0 051-8067-15 051-8067-15 - 15" Revolt Fuel Line Assembly
$8.79
133.1 051-8067-00 051-8067-00 - 1/4 Fuel Line Hose (Priced by the Foot)
$6.41
133.2 072-8069-00 072-8069-00 - 1/4 Fuel Line Clamp
$2.99
142 066-8083-00 066-8083-00 - 3.5" Tethered Fuel Cap
$23.53
143 067-0003-00 067-0003-00 - 2017-2024 Walk Behind Black Fuel Tank
$300.99
145.0 067-8090-04 067-8090-04 - Walk Behind Hydro Tank Assembly No Longer Available
Obsolete.
145.1 051-8063-00 051-8063-00 - 3/8 Clear Hose PRICED PER FOOT
$2.99
145.2 066-5050-00 066-5050-00 - Hydraulic Tank Cap (See Models Used On For Details)
$15.60
145.3 067-8090-00 067-8090-00 - Hydraulic Expansion Tank (See Models Used On For Details)
$31.22
145.4 072-8065-00 072-8065-00 - 3/8" Hose Clamp - CTB-16-STFS
$2.99
145.5 072-8066-00 072-8066-00 - 1/2" Hose Clamp
$2.99
151 072-0050-00 072-0050-00 - Fuel Tank Clamp (See Models Used On For Details)
$11.34
172 091-0902-00 091-0902-00 - 2013-2021 Logo Decal - Floorboard
$17.16
177 091-3150-00 091-3150-00 - Outlaw Warning Decal (See Models Used On For Details)
$10.91
