2020 ZT Elite - Transaxle Assembly

2020 ZT Elite - Transaxle Assembly

The 2020 ZT Elite Transaxle Assembly is a vital part of your mower’s drive system, providing power to the wheels for smooth operation. At BadBoyMowerParts.com, we offer a comprehensive range of Bad Boy Mower Parts for the transaxle, including replacement gears, seals, and complete assemblies. Whether you're replacing a damaged transaxle or performing routine maintenance, our Bad Boy Mower Part diagrams make it easy to identify the necessary components. Our Bad Boy Lawn Mower Parts are engineered for durability and performance, ensuring that your mower continues to run at its best. Bad Boy Parts Online offers a quick and easy shopping experience, and with Free Shipping On Orders Over $100, you’ll save on delivery costs. Get your 2020 ZT Elite Transaxle Assembly parts today and keep your mower running smoothly for years to come.

Bad Boy Mower Parts Lookup

2020 ZT Elite - Transaxle Assembly
  Position Number SKU Product Title Price
1.0 085-4051-00 085-4051-00 - Hydro Service Package for 2020 and Older Models with Expansion Tanks - ZT2800, ZT3100, ZT3200, and all ZT3400
$104.74
1 019-8044-00 019-8044-00 - 5/16 USS Flat Washer Zinc
$2.99
2 063-1050-00 063-1050-00 - ZT Hydraulic Filter
$22.71
3 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
4 018-5355-00 018-5355-00 - 5/16-18 X 6 Hex Bolt Zinc
$2.99
5 025-0017-00 025-0017-00 - Transaxle Spacer (See Models Used On For Detail)
$14.04
6 025-0070-00 025-0070-00 - Transaxle Spacer
$6.41
7 018-4701-00 018-4701-00 - 5/16-18 X 3 Hex Bolt Zinc
$2.99
9 024-1200-00 024-1200-00 - Fitting, 3/8 x 3/8 45 Degree, 4603-6-6 (See Models Used On For Details)
$19.93
10 034-9080-00 034-9080-00 - Gold Transaxle Spring
$14.89
11 050-2071-00 050-2071-00 - ZT Transaxle Charge Plate
$98.43
12 013-3000-00 013-3000-00 - Acorn Lug Nut
$3.29
13 018-3000-00 018-3000-00 - 3/8-16 X 2 Hex Bolts Zinc
$2.99
14 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
15 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
16 050-2095-00 050-2095-00 - 2017-2021 Right ZT Elite Transaxle & 36" 2020-2021 Revolt (obsolete)
use part #050-2095-01
$729.99
17 050-2096-00 050-2096-00 - 2017-2021 Left ZT Elite Transaxle & 36" 2020-2021 Revolt (obsolete)
use part #050-2096-01
$729.99
18 064-3050-00 064-3050-00 - Brake Cable - 18.50"
$51.47
19 064-3051-00 064-3051-00 - Brake Cable-24.50" (See Models Used On For Details)
$57.72
20 018-5344-00 018-5344-00 - 5/16 x 2 1/2 Bolt
$2.99
21 022-2015-00 022-2015-00 - ZT Black Assy 22x11-10 (See Models Used On For Details)
$320.99
22 050-2070-00 050-2070-00 - 2020 -2024 ZT Avenger/ ZT/Maverick Transaxle Fan/Pulley Kit
$85.17
23 050-2076-00 050-2076-00 - Transaxle Wheel Hub (See Models Used On For Details)
$90.56
24 050-2012-00 050-2012-00 - Transaxle Wheel Studs/ Drum Brake Studs
$5.61
25 092-8000-00 092-8000-00 - Transaxle Brake Lever
$21.28
26 022-2015-50 022-2015-50 - ZT Wheel for 54" and 60" decks, fits 022-2015-00 & 022-2215-00
$114.99
27 022-2020-00 022-2020-00 - ZT Tire Only 22x11-10 Carlisle
$289.99
28 022-2018-00 022-2018-00 - ZT Black Assy 22x10-10 48" Deck (See Models Used On For Details)
$320.99
29 022-2019-17 022-2019-17 - 10" Black Wheel for 48" ZT
$99.50
30 022-2024-17 022-2024-17 - 22x10-10 Tire for the 48" ZT fits the 022-2018-00
$175.99
