2021 Compact Outlaw - Transaxle Assembly

2021 Compact Outlaw - Transaxle Assembly

The 2021 Compact Outlaw Transaxle Assembly is an essential part of your mower's drivetrain, responsible for controlling the power transfer from the engine to the wheels. If you need to replace your transaxle assembly, BadBoyMowerParts.com has a wide selection of Bad Boy Mower Parts that are designed to fit your 2021 Compact Outlaw. Our detailed Bad Boy Mower Part diagrams make it easy to locate the exact parts you need for your transaxle assembly, ensuring that your mower continues to operate smoothly. Whether you're replacing the entire assembly or specific components, you can trust that our Bad Boy Lawn Mower Parts will be of the highest quality. Shopping for Bad Boy Parts Online is easy, and with Free Shipping On Orders Over $100, you’ll receive your parts quickly and without any additional shipping charges.

Bad Boy Mower Parts Lookup

2021 Compact Outlaw - Transaxle Assembly
  Position Number SKU Product Title Price
1.0 085-4051-00 085-4051-00 - Hydro Service Package for 2020 and Older Models with Expansion Tanks - ZT2800, ZT3100, ZT3200, and all ZT3400
$104.74
1 013-2050-00 013-2050-00 - 1/4-20 Nylon Insert Flange Nut
$2.99
2 013-3000-00 013-3000-00 - Acorn Lug Nut
$3.29
3 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zinc
$2.99
4 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
5 013-9003-00 013-9003-00 - 3/8 Nylock Jam Nut 1/2 Nut
$2.99
6 018-2071-00 018-2071-00 - 3/8 x 2 1/2 Hex Tap Bolt - Ful l Thread - ACS
$2.99
7 018-4701-00 018-4701-00 - 5/16-18 X 3 Hex Bolt Zinc
$2.99
8 018-5344-00 018-5344-00 - 5/16 x 2 1/2 Bolt
$2.99
9 018-5355-00 018-5355-00 - 5/16-18 X 6 Hex Bolt Zinc
$2.99
10 018-8052-00 018-8052-00 - 1/4-20 X 3/4 Hex Bolt
$2.99
11 019-8044-00 019-8044-00 - 5/16 USS Flat Washer Zinc
$2.99
12.1 022-3011-00 022-3011-00 - 12x7" Black Wheel-48" EZT Only
$109.99
12.2 022-4035-00 022-4035-00 - 23x9 - 12 Reaper Turf Tire Only
$201.99
12 022-4040-00 022-4040-00 - 23x9-12 Reaper Turf (See Models Used On for Details)
$329.99
13 024-1200-00 024-1200-00 - Fitting, 3/8 x 3/8 45 Degree, 4603-6-6 (See Models Used On For Details)
$19.93
14 025-0070-00 025-0070-00 - Transaxle Spacer
$6.41
15 028-4801-00 028-4801-00 - Crossover Bar (See Models Used On For Detail)
$28.10
16 034-1025-00 034-1025-00 - Brake Spring (See Models Used On For Detail)
$12.48
17 034-9080-00 034-9080-00 - Gold Transaxle Spring
$14.89
18 041-6400-00 041-6400-00 - Pump Belt (See Models Used On For Details)
$58.84
19 050-2012-00 050-2012-00 - Transaxle Wheel Studs/ Drum Brake Studs
$5.61
20 050-2072-00 050-2072-00 - Fan/Pulley Kit
$63.96
21 050-2076-00 050-2076-00 - Transaxle Wheel Hub (See Models Used On For Details)
$90.56
22 050-6000-00 050-6000-00 - ZT3400 Transaxle - Left (obsolete)
use part #050-6000-02
$819.99
23 050-6001-00 050-6001-00 - ZT3400 Transaxle - Right (obsolete)
use part #050-6001-02
$819.99
24 063-1050-00 063-1050-00 - ZT Hydraulic Filter
$22.71
25 064-3050-00 064-3050-00 - Brake Cable - 18.50"
$51.47
26 064-3051-00 064-3051-00 - Brake Cable-24.50" (See Models Used On For Details)
$57.72
27 092-8000-00 092-8000-00 - Transaxle Brake Lever
$21.28
