2021 MZ & MZ Magnum - Deck Height Control - Detail

2021 MZ & MZ Magnum - Deck Height Control - Detail

The 2021 MZ & MZ Magnum Deck Height Control - Detail is a vital feature that lets you adjust your mower’s cutting height with precision. If you’re looking for replacement parts or need to repair this system, BadBoyMowerParts.com offers a wide selection of Bad Boy Mower Parts specifically designed for the 2021 MZ & MZ Magnum. Our Bad Boy Mower Part diagrams make it easy to locate the exact parts you need for the deck height control system. We offer high-quality Bad Boy Lawn Mower Parts that will keep your mower performing at its best. Shopping for Bad Boy Parts Online is straightforward, and with Free Shipping On Orders Over $100, you’ll get your parts delivered to your door quickly, without the added cost of shipping.

Bad Boy Mower Parts Lookup

2021 MZ & MZ Magnum - Deck Height Control - Detail
  Position Number SKU Product Title Price
1A 017-9076-00 017-9076-00 - Pillow Block Assembly
$23.41
1B 028-0007-17 028-0007-17 - 2018-2022 MZ Magnum Deck Height Rod Assy.
$28.88
1C 026-0019-01 026-0019-01 - Foot Pedal Assembly (See Models Used On For Details)
$93.69
18 017-9077-00 017-9077-00 - Pillow Block-Male
$21.28
19 017-9078-00 017-9078-00 - Pillow Block-Female (obsolete)
use part #017-9077-00
$21.28
20 017-9079-00 017-9079-00 - Pillow Block-Metal Plate
$21.28
21 031-0500-00 031-0500-00 - 2017-2024 Deck Pedal Lever (See Models Used On For Detail)
$31.22
22 026-0019-00 026-0019-00 - Shallow Foot Pedal (See Models Used On For Detail)
$31.22
23 013-8049-00 013-8049-00 - 5/16-18 Nylon Flange Nut
$2.99
24 018-8065-00 018-8065-00 - 5/16-18 X 1 Carriage Bolt Zinc
$2.99
25 028-0007-00 028-0007-00 - 2017-2024 MZ Deck Height Dial Rod
$31.17
26 026-1100-00 026-1100-00 - 2017-Newer CAM Plate Use With Deck Adjuster (See Models Used On For Detail)
$15.55
27 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
28 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
29 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
