2021 Maverick - 60" Deck Assembly

2021 Maverick - 60" Deck Assembly

The 2021 Maverick 60" Deck Assembly is perfect for those who need a wider cutting width for large areas. If you’re looking to replace or repair any components of the deck, BadBoyMowerParts.com offers an extensive selection of Bad Boy Mower Parts. Our Bad Boy Mower Part diagrams make it easy to find the specific components needed for the 2021 Maverick 60" deck assembly. Whether you need to replace spindles, blades, or other deck-related parts, we have high-quality Bad Boy Lawn Mower Parts for the job. Shopping for Bad Boy Parts Online is quick and efficient, and with Free Shipping On Orders Over $100, you can get all your parts delivered directly to your home without any extra shipping charges.

Bad Boy Mower Parts Lookup

2021 Maverick - 60" Deck Assembly
  Position Number SKU Product Title Price
1A 088-6000-00 088-6000-00 - Advanced Chute System for Select 2007-2025 Models with 60", 61", and 72" Decks & 2014-Newer ZT/CZT/Maverick 54" Decks (Will Not Work on 54" Outlaw)
$249.00
1B 210-0260-50 210-0260-50 - 2017-2025 60" Mulch Kit w/Blades (Not for MZ or Avenger)
$318.45
1 013-0004-00 013-0004-00 - Acorn Nut-Pulley Cover
$3.29
8 013-5201-00 013-5201-00 - 3/8-16 Hex Flange Nuts Zinc w/ Serrations
$2.99
9 013-5202-00 013-5202-00 - 3/8 Nylock Flange Nut
$2.99
10 013-5301-00 013-5301-00 - 5/8-11 Nylon Insert Jam Locknut Zinc
$2.99
16 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
24 014-5020-00 014-5020-00 - 2021-2022 Maverick 54"/60" RH Pulley Cover
$28.39
25 014-5021-00 014-5021-00 - 2021-2022 Maverick 54"/60" LH Pulley Cover
$28.39
42 018-0010-00 018-0010-00 - Deck Wheel Bolt
$6.48
47 018-0075-00 018-0075-00 - 3/8-16 x 1-3/4 Hex C/S () ZC
$3.29
48 018-1050-00 018-1050-00 - 1/2 x 2 Carriage Bolt
$2.99
56 018-2018-00 018-2018-00 - 1/2 x 3 1/2 Flange Bolt - Gr 8
$3.62
61 018-5019-00 018-5019-00 - 1/2-13 X 4 GR 8 Hex Bolt
$4.39
65 018-5250-00 018-5250-00 - 3/8-16 X 3/4 Hex Bolts
$2.99
67 018-5311-00 018-5311-00 - 5/8-11 X 4" Hex Bolts Zinc
$4.06
73 018-6019-00 018-6019-00 - 1/2-20 X 1-1/2 Bolt Zinc, Fine Thread Bolt
$2.99
74 018-6020-00 018-6020-00 - 5/8-18 X 1-1/2 GR 8 Hex Bolts Zinc Yellow for Blade Spindle
$2.99
75 018-6054-00 018-6054-00 - 1/2-13 X 3-1/2 Hex Bolts
$2.99
76 018-7060-00 018-7060-00 - 3/8-16 x 5 1/2 Hex Bolt -
$2.99
80 019-0007-00 019-0007-00 -.517 Square Hole Round Washer
$2.99
84 019-5007-00 019-5007-00 - 1/2 Lockwasher Zinc
$2.99
87 019-5038-00 019-5038-00 - 5/8 Flat Washer
$2.99
89 019-6017-00 019-6017-00 -.630 ID X 1.122 OD X.142 THK Flat Washer Nylon
$2.99
90 019-6020-00 019-6020-00 - 1/2 Belleville Washer #K2000-G -150
$5.16
94 019-8044-00 019-8044-00 - 5/16 USS Flat Washer Zinc
$2.99
97 022-1000-00 022-1000-00 - Deck Wheel Only
$17.11
105 025-5338-00 025-5338-00 -.502 ID X.750 OD X 1.500" Spacer Zinc
$3.62
106 025-5339-00 025-5339-00 - .502 ID X 1.00 OD X 1.750 Length Spacer Zinc
$5.36
109 026-0025-00 026-0025-00 - Deck Spindle Support Plate
$14.19
121 030-0050-00 030-0050-00 - 5/16 Set Screw
$2.99
136 033-6004-00 033-6004-00 - 6 1/4" Spindle Deck Pulley (without set screw) (See Models Used On For Detail)
$35.48
138 033-7201-25 033-7201-25 - 5 3/4 Idler Pulley
$35.48
141 034-2020-00 034-2020-00 - Idler Spring (See Models Used On For Detail)
$17.11
146.1 037-6015-50 037-6015-50 - Spindle Assembly (See Models Used On For Detail)
$199.99
149 038-6060-00 038-6060-00 - 60" High Lift Fusion Blade & 2023-2025 Revolt SD 42"
$22.99
150 038-6003-00 038-6003-00 - 60" Gator Mulching Blade & 2023-2025 Revolt SD 42"
$22.99
154 039-2127-17 039-2127-17 - Deck Hanger Assy. (See Models Used On For Details)
$15.60
156 039-6945-17 039-6945-17 - Deck Idler Assembly
$70.97
160 041-1650-00 041-1650-00 - B165 Deck Belt (See Models Used On For More Details, Not For 54" ZT/CZT/Maverick)
$90.94
163 042-6030-00 042-6030-00 - 1/4" x 1" Square Key
$4.81
168 048-6000-00 048-6000-00 - Maverick/Compact Outlaw/Revolt Toplink
$80.24
181 060-6017-00 060-6017-00 - 60" Deck Shell 2017-2022 ZT & 2018-2022 Maverick
$1399.99
221 091-0905-18 091-0905-18 - 2018-2023 60" Deck Decal
$6.41
222 091-3012-00 091-3012-00 - Danger Decal-Spindle/Discharge
$2.99
225 091-3309-00 091-3309-00 - Deck Belt Route Decal
$6.41
229 091-8001-00 091-8001-00 - Impact Absorption Patent Decal
$2.99
234 210-6005-98 210-6005-98 - Chute Assembly (See Models Used On For Detail)
$149.99
