2021 Maverick - Drive Arm Assembly

2021 Maverick - Drive Arm Assembly

The 2021 Maverick Drive Arm Assembly is responsible for controlling the movement of your mower’s wheels, ensuring smooth operation. If you need a replacement, BadBoyMowerParts.com offers a wide range of Bad Boy Mower Parts for the 2021 Maverick. Our detailed Bad Boy Mower Part diagrams help you easily find the drive arm assembly or its individual components for replacement. We carry Bad Boy Lawn Mower Parts that fit perfectly, ensuring your mower works at its best. Shopping for Bad Boy Parts Online is quick and simple, and with Free Shipping On Orders Over $100, your parts will be delivered directly to your home without any extra shipping charges.

Bad Boy Mower Parts Lookup

2021 Maverick - Drive Arm Assembly
  Position Number SKU Product Title Price
7 013-5041-00 013-5041-00 - 3/8-16 Nylon Insert Locknut Zinc
$2.99
11 013-6014-00 013-6014-00 - 3/8-16 Hex Nuts Zinc
$2.99
12 013-6051-00 013-6051-00 - 3/8-24 Hex Jam Nut Zinc
$2.99
16 013-8050-00 013-8050-00 - 1/2-13 Nylon Insert Flange Nut Zinc Orange Nylon
$2.99
18 013-9002-00 013-9002-00 - 5/16-18 Hex Flange Nuts Zinc w /Serrations
$2.99
51 018-1080-00 018-1080-00 - 12-24 x 1/2 HWH Bolt - Safety Switch
$2.99
57 018-2050-00 018-2050-00 - 10mm Damper Ball Stud-Steering Damper, Outlaw Deck Damper
$2.99
62 018-5040-00 018-5040-00 - 3/8-16 X 1-1/4 Hex Bolt
$2.99
63 018-5043-00 018-5043-00 - 3/8-16 X 1-1/4 Carriage Bolt
$2.99
85 019-5029-00 019-5029-00 - 3/8 USS Flat Washer Zinc
$2.99
86 019-5037-00 019-5037-00 - 3/8" Lockwasher Zinc
$2.99
92 019-8027-00 019-8027-00 -.515 ID Plastic Shoulder Washer
$2.99
96 019-8054-00 019-8054-00 -.505 ID X 1 OD X.128 THK Flat Washer Nylon
$2.99
115 028-0049-00 028-0049-00 - 2021 Maverick Steering Actuator Rod
$21.39
125 031-0053-21 031-0053-21 - 2021-2022 Maverick Drive Arm Actuator RH Assembly
$42.79
126 031-0054-21 031-0054-21 - 2021-2022 Maverick Drive Arm Actuator LH Assembly
$42.79
128 031-9000-18 031-9000-18 - Left Adjustable Steering Arm (See Models Used On For Details)
$144.50
129 031-9050-18 031-9050-18 - 2017 - 2022 Right Adjustable Steering Arm Black
$144.50
142 034-8025-00 034-8025-00 - Drive Lever Housing Spring
$4.07
144 035-5450-00 035-5450-00 - Right Steering Push Rod (See Models Used On For Details)
$33.95
145 035-5451-00 035-5451-00 - Left Steering Push Rod (See Models Used On For Details)
$42.58
199 070-5491-00 070-5491-00 - 2021 Maverick Frame--Painted
$1199.99
201 077-8073-00 077-8073-00 - Safety Switch (See Models Used On For Detail)
$10.99
210 087-0001-00 087-0001-00 - Steering Damper (See Models Used On For Details)
$62.40
